Summary of Contents for Aigis Mechtronics HS9303 Series
- Page 1 Corner Security Housings HS9303 S ERIES N S T A L L A T I O N A N D P E R A T I N G N S T R U C T I O N S...
- Page 2 IMPORTANT SAFEGUARDS where they exit from the appliance. Read Instructions - All the safety and operating instructions should be read before 12. Power Lines - An outdoor system should not be located in the vicinity of overhead power lines or other electric light or power circuits or where it can fall into such the unit is operated.
-
Page 3: Table Of Contents
• Installation and Operating Instructions. For maximum protection and durability, the light weight cast alu- minum design of the HS9303 Series housings provide the strength If an item appears to have been damaged in shipment, replace it of 12 gage steel with the superior strength-to-weight ratio of alu- minum. -
Page 4: Installation
5 INSTALLATION : Use the key provided to unscrew the lock. Remove the HS9303L access panel. See Figure 2 This installation should be made by qualified service personnel and conform to the National Electrical Code and applicable local codes. 5.1 Accessories HS9313: Sloped top cover for housings mounted below the ceil- ing line. -
Page 5: Mounting The Unit
5.3 Mounting the Unit 5. Mount the rear panel by installing only the right side anchor Position the rear panel in the corner against the walls and bolts. Start the left side bolts, but DO NOT tighten. ceiling. See Figure 5 Figures 7 and 8 Note: A smooth square surface is ideal for proper installation. -
Page 6: Camera/Lens Installation
5.4 Camera/Lens Installation 5.5 Final Assembly Reattach the camera mounting system to the rear panel using Mount the cover by aligning the studs with the slots on the two 6 mm flange nuts. See Figure 9 rear panel. Secure using the six flange nuts. See Figure 12 Cover Mount System... - Page 7 HS9303L: Attach the access panel to the housing by inserting the latch into the rear panel. Screw the lock down tight to the cover. If the rear of the access panel is not tight remove access panel and lower the latch by rotating it clockwise. Repeat until tight.
- Page 8 ©2002 Aigis Mechtronics 1124 Louise Road, Winston-Salem, NC 27107-5450 100 0028 001 AIG 10/02 Tel: 336.785.7740 Fax: 336.785.7744 Data subject to change without notice Printed in U.S.A.
