Summary of Contents for FAR EAST IN8
- Page 1 ™ www.FarEastWok.com Installation & user Induction cooking operation guide Version 1, December 2019...
-
Page 2: Safety
do not use in hot, humid or dusty places, or near acidic or explosive materials. Parts which have been protected by the manufacturer shall not be adjusted by the user or installer Far East Kitchen Solutions Installation & user operation guide induction cooking Page 2 of 20... - Page 3 You should ensure the engineer provides a completed service record as evidence of having the appropriate work performed. Far East Kitchen Solutions Installation & user operation guide induction cooking...
-
Page 4: Table Of Contents
Error codes ................................15 Floor standing inductionappliancewith Sliding or rotating controls............... 15 Table top induction appliance with Push button controls ................17 Warranty and guarantee ..............................18 Far East Kitchen Solutions Installation & user operation guide induction cooking Page 4 of 20... -
Page 5: Description And Specification
DESCRIPTION AND SPECIFICATION Far East Kitchen Solutions range of commercial heavy duty, high efficiency induction cooking appliances are constructed in easy clean stainless steel external finish except for certain parts such as the controls. They may be supplied with either standard splashback or low back option and are available on industrial adjustable feet or with caster wheels. -
Page 6: A) Dimensions And Technical Data
Relative humidity: 10% to 90% non-condensing Ambient temperature during operation: 0°c to +40°c Ambient temperature during storage: -20°c to +70°c Voltage tolerance: -10% to +6% Far East Kitchen Solutions Installation & user operation guide induction cooking Page 6 of 20... -
Page 7: B) Electrical Connection
Refer to the appropriate wiring stand for the size of cable that is to be supplied to an appliance for the current drawn on that line. This will typically be 4 mm per conductor for 400V and 2.5mm per conductor for 230V. Far East Kitchen Solutions Installation & user operation guide induction cooking Page 7 of 20... -
Page 8: Installation
19) Correctly locate the appliance into its final operating position and using a spirit level, adjust the legs so that the appliance is level and at the correct height. 20) Connect the power supply to the appliance. Far East Kitchen Solutions Installation & user operation guide induction cooking Page 8 of 20... -
Page 9: D) Waste Drainage Connection (If Equipped)
Operation on page 11 onwards and on page 14 onwards. Ensure that the electrical isolator location is known to user and that the procedure to follow in event of emergency is demonstrated. Far East Kitchen Solutions Installation & user operation guide induction cooking... - Page 10 Installation and Serial Number of Unit recorded and kept with this manual. (These details can be found on the Rating Plate attached to the inner R/H side panel. Refer to the ‘Dimensions’ section for rating plate location). Far East Kitchen Solutions Installation & user operation guide induction cooking Page 10 of 20...
-
Page 11: Operation
B) FLOOR STANDING INDUCTION APPLIANCES WITH ROTARY OR SLIDING CONTROLS I) TYPE I DISPLAY Power level 0-5 or 0-8 Error code flashing Power indicator lamp (Red) Heating zone on (Green) Far East Kitchen Solutions Installation & user operation guide induction cooking Page 11 of 20... -
Page 12: Ii) Type Ii Display
(2) Press and hold ☼ for two seconds (3) 0 will flash. Press and to adjust desired cooking time. Then press ☼. (4) Now press ⌽ and lift will descend Far East Kitchen Solutions Installation & user operation guide induction cooking Page 12 of 20... -
Page 13: C) Table Top Induction Appliances With Push Button Controls
C) TABLE TOP INDUCTION APPLIANCES WITH PUSH BUTTON CONTROLS IV) TYPE III DISPLAY Power level mode On/off Function selection Temperature Power mode °F indicator Countdown timer with auto off V) TYPE IV DISPLAY Far East Kitchen Solutions Installation & user operation guide induction cooking Page 13 of 20... -
Page 14: Cleaning And Routine Maintenance
Once per month the grease filter should be removed and cleaned. This is located on the underside of the appliance. Slide out the filter and clean it by immersing in detergent and hot water, then rinse with hot water. Far East Kitchen Solutions Installation & user operation guide induction cooking... -
Page 15: Troubleshooting
200K position, measurement Whether the resistance of the thermistor is normal (the thermistor resistance is 100K minus the ambient temperature = actual resistance) Far East Kitchen Solutions Installation & user operation guide induction cooking Page 15 of 20... - Page 16 2 Check if the distance between the reel and the pan is appropriate. open or 3. Check whether the output transformer resistance is matched, or the damaged transformer Whether the terminal of the connection between the cable Far East Kitchen Solutions Installation & user operation guide induction cooking Page 16 of 20...
-
Page 17: Ii) Table Top Induction Appliance With Push Button Controls
1. Check whether the distance between the coil and the pot is too good, cannot detect the pot, The distance between the plate and the pan is 10mm-12mm. 2. The motherboard drive is damaged, and the motherboard driver is replaced. Far East Kitchen Solutions Installation & user operation guide induction cooking Page 17 of 20... -
Page 18: Warranty And Guarantee
Far East. 13. Any third party or contractor selling or installing the cooker shall not be an agent of Far East and hence have no authority or right whatsoever to make a representation on behalf of Far East with regard to this guarantee or to amend its terms. - Page 19 Far East Kitchen Solutions Installation & user operation guide induction cooking Page 19 of 20...
- Page 20 Chesterfield, Derbyshire S45 9NE. United Kingdom. Far East Kitchen Solutions™ is a trading style of Far East Europe Limited, registered in the United Kingdom, company № 4513486 and Far East Industries Limited, registered in the United Kingdom, company № 01736291.
