Power Broom™
The engine exhaust from this product contains chemicals
known to the State of California to cause cancer, birth defects,
or other reproductive harm.
Read and understand all provided literature before
use. Failure to do so could result in serious injury.
Note: This product complies with CAN ICES-2/NMB-2.
X7502342101
06/20
©
ECHO Incorporated
Operator's
Manual
PS262

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Broom PS262 and is the answer not in the manual?

Questions and answers

Related Manuals for Shindaiwa Power Broom PS262

Summary of Contents for Shindaiwa Power Broom PS262

  • Page 1 Operator’s Manual PS262 Power Broom™ The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. Read and understand all provided literature before use. Failure to do so could result in serious injury. Note: This product complies with CAN ICES-2/NMB-2.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PS262 TABLE OF CONTENTS Introduction ....................3 Servicing Information .................. 3 Parts/Serial Number................3 Service ....................4 Consumer Product Support ..............4 Product Registration ................4 Additional Literature ................4 Safety ......................5 International Symbols ................5 Equipment....................

  • Page 3: Introduction

    SERVICING INFORMATION Parts/Serial Number Genuine SHINDAIWA Parts and Assemblies for your SHINDAIWA products are available only from an Authorized SHINDAIWA Dealer. When you do need to buy parts always have the Model Number and Serial Number of the unit with you.

  • Page 4: Service

    Service Service of this product during the warranty period must be performed by an Authorized SHINDAIWA Service Dealer. For the name and address of the Authorized SHINDAIWA Service Dealer nearest you, ask your retailer or call: 1-877-986-7783. Dealer information is also available on WWW.SHINDAIWA-USA.COM.

  • Page 5: Safety

    PS262 SAFETY SAFETY International Symbols Symbol Description Symbol Description Warning, See Carburetor Operator’s Adjustment - High Manual Speed Mixture Wear Eye, Ear Carburetor and Head Adjustment - Idle Protection Speed Wear Hand Carburetor and Foot Adjustment - Low Protection Speed Mixture Safety/Alert Emergency Stop Fuel and Oil...
  • Page 6 SAFETY PS262 Symbol Description Symbol Description Keep Bystanders and Helpers Away 15 m (50 ft.) Rotating Cutting Thrown Objects Attachment Read the Manuals • Provide all users of this equipment with the Operator’s Manual for instructions on Safe Operation. Clear the Work Area •...

  • Page 7: Equipment

    Avoid contact during and immediately after operation. Equipment Use only SHINDAIWA attachments. Serious injury may result from the use of a non-approved attachment combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO.

  • Page 8: Emission Control (Exhaust & Evaporative)

    EMISSION CONTROL PS262 Periodically Check fuel system (fuel lines, vent, grommet, fuel tank, and fuel cap) for leaks especially if the unit is dropped. If damage or leaks are found, do not use unit, otherwise serious personal injury or property damage may occur. Have unit repaired by an authorized servicing dealer before using.

  • Page 9: Description

    PS262 DESCRIPTION DESCRIPTION Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and that you understand and follow the instructions on it. If a decal cannot be read, a new one can be ordered from your dealer. Safety label is for example only.

  • Page 10: Contents

    Due to packaging restrictions, some assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or SHINDAIWA Dealer of damaged or missing parts. Use the contents list to check for missing parts. Power Head / Drive Shaft Assembly...

  • Page 11: Assembly

    PS262 ASSEMBLY ASSEMBLY Support Handle If necessary, position support handle for comfortable operation and securely tighten screw. Note: Label shows minimum spacing for support handle location. Gear Housing to Lower Drive Shaft Assembly Parts Required: Gear Housing Assembly, Lower Drive Shaft Assembly, Tube Protector Remove vinyl cap from lower end of drive shaft tube (end...

  • Page 12: Drum Assembly

    ASSEMBLY PS262 Install and tighten alignment screw (B). Tighten gear housing shaft clamp bolt (C). Slide tube protector (A) flush against gear case housing. Drum Assembly Parts Required: 1 - Gear Housing/Lower Shaft Assembly 2 - Drums 2 - Plastic Drum Axles 2 - Clevis Pins 2 - Hitch Pins 2 - Split Pins...
  • Page 13 PS262 ASSEMBLY Insert hitch pins (G) through holes in tip of clevis pins to retain clevis pins. Slide recessed ends of sweeper drums (H) onto plastic axles, and secure with split pins (I). Spread tips of split pins out to retain pins in axles. Thrown objects hazard.

  • Page 14: Operation

    OPERATION PS262 OPERATION Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects away from all openings. Always stop engine, disconnect spark plug, and make sure all moving parts have come to a complete stop before removing obstructions, clearing debris, or servicing unit.

  • Page 15: Fuel

    2-stroke and 2/4-stroke hybrid engines. Two Stroke Oil - A 2-stroke engine oil, such as Shindaiwa branded 2-stroke oils, meeting ISO-L-EGD (ISO/CD 13738) and J.A.S.O. FD Standards must be used. Shindaiwa branded 2-stroke oils meet these standards. Engine problems due to inadequate lubrication caused by failure to use an ISO-L- EGD (ISO/CD 13738) and J.A.S.O.
  • Page 16 AVOID repeated or prolonged skin contact. ◆ AVOID inhaling oil mists or vapors. ◆ Shindaiwa branded 2-stroke oils may be mixed at 50:1 ratio for application in all Shindaiwa engines sold in the past, regardless of ratio specified in those manuals. Handling Fuel Fuel is VERY flammable.
  • Page 17 PS262 OPERATION Mixing Instructions Fuel to Oil Mix – 50:1 Ratio Fill an approved fuel container Metric with half of the required amount of gasoline. Add the proper amount of gal. fl. oz. engine oil to gasoline. Close container and shake to mix oil with gasoline.

  • Page 18: Starting Cold Engine

    OPERATION PS262 Starting Cold Engine The attachment will operate immediately when the engine starts, and could result in possible serious injury. Keep movable parts of the attachment away from objects that could become entangled or thrown, and surfaces that could cause loss of control.

  • Page 19: Starting Warm Engine

    PS262 OPERATION After engine fires (or 5 pulls), move choke (B) to the RUN ( ) (OPEN) position. Firmly grasp throttle handle and throttle trigger lockout with left hand and fully depress throttle trigger to wide open position. Pull starter handle/rope until engine starts and runs.

  • Page 20: Stopping Engine

    OPERATION PS262 Purge Bulb Pump purge bulb (C) until fuel is visible and flows freely in the clear fuel tank return line. Pump bulb an additional 4 or 5 times. Recoil Starter Lay the unit on a flat area and keep movable attachment parts clear of all obstacles.

  • Page 21: Sweeping Operation

    PS262 OPERATION Sweeping Operation Always beware of thrown debris. ◆ Do not operate with paddles close to your body, which ◆ could result in loss of control and possible serious injury. If drum assemblies jam, switch engine off and inspect ◆...
  • Page 22 OPERATION PS262 Debris may be swept out and away from corners by turning unit over to reverse paddle direction. Grip unit securely using both hands. Operate throttle trigger with thumb of right hand. For extended use, reposition front handle to allow comfortable grip.

  • Page 23: Maintenance

    Level 1 = Easy to do. Common tools may be required. Level 2 = Moderate difficulty. Some specialized tools may be required. Level 3 = See your dealer. Click HERE or go to http://www.echo-usa.com/products/maintenance-kit HERE https://www.shindaiwa-usa.com/you-can.aspx For information about maintenance kits. X7502342101 © 06/20 ECHO Incorporated...

  • Page 24: Maintenance Intervals

    MAINTENANCE PS262 Maintenance Intervals REQ’D MAINTENANCE COMPONENT/SYSTEM SKILL PROCEDURE LEVEL Daily or Before Use Air Filter Inspect/Clean * Choke Shutter Inspect/Clean * Fuel System Inspect Cooling System Inspect/Clean Recoil Starter Rope Inspect/Clean * Screws/Nuts/Bolts Inspect/Tighten/Replace * Every Refuel Fuel System Inspect 3 Months Air Filter...

  • Page 25: Air Filter

    PS262 MAINTENANCE Air Filter Level 1 Parts Required: Tune Up Kit. Close choke (COLD START position). This prevents dirt from entering the carburetor throat when the air filter is removed. Brush accumulated dirt from air cleaner area. Remove air filter cover. Brush dirt from inside cover. Assure throttle wire retaining clip (A) remains in place as shown when removing or installing air...

  • Page 26: Fuel Filter

    MAINTENANCE PS262 Assure air filter is assembled with pleats oriented vertically. Fuel Filter Level 1. Parts Required: Tune Up Kit. Fuel is VERY flammable. Use extreme care when mixing, storing or handling, or serious personal injury may result. Do not damage fuel line while removing Fuel Filter from tank. Use a clean rag to remove loose dirt from around fuel cap and empty fuel tank.

  • Page 27: Spark Plug

    PS262 MAINTENANCE When the inside of the fuel tank is dirty, rinse the tank out with gasoline to clean it. Note: Federal EPA regulations require all model year 2012 and later gasoline powered engines produced for sale in the United States to be equipped with a special low permeation fuel supply hose between the carburetor and fuel tank.

  • Page 28: Cooling System

    MAINTENANCE PS262 Cooling System Level 2. To maintain proper engine operating temperatures, cooling air must pass freely through the cylinder fin area. This flow of air carries combustion heat away from the engine. Overheating and engine seizure can occur when: •...

  • Page 29: Exhaust System

    PS262 MAINTENANCE Use brush to remove dirt from the cylinder fins. Remove grass and leaves from the grid (C) between the recoil starter and fuel tank. Assemble components in reverse order. Exhaust System Spark Arrestor Screen Level 2. Parts Required: Spark Arrestor Screen, Gasket Remove spark plug lead.
  • Page 30 MAINTENANCE PS262 Exhaust Port Cleaning Level 2. Parts Required: Heat Shield (as needed) Remove spark plug lead from spark plug, and remove muffler cover. Place piston at top dead center. Remove muffler (A) and heat shield (B). Use a wood or plastic scraping tool to clean deposits from cylinder exhaust port (C).

  • Page 31: Carburetor Adjustment

    PS262 MAINTENANCE Carburetor Adjustment Level 2. When carburetor adjustment is completed, the cutting attachment should not move at idle, otherwise serious personal injury may result. Engine Break-In New engines must be operated a minimum duration of two tanks of fuel break-in before carburetor adjustments can be made.

  • Page 32: Maintenance Intervals

    MAINTENANCE PS262 Check idle speed and reset if necessary. If a tachometer is available, idle speed screw (A) should be set to the specifications found on “Specifications” page of this manual. Turn idle screw (A) clockwise to increase idle speed; counterclockwise to decrease idle speed.

  • Page 33: Gear Case Lubrication

    PS262 MAINTENANCE REQ’D MAINTENANCE COMPONENT/SYSTEM SKILL PROCEDURE LEVEL Fuel Cap Gasket Replace * Gear Housing Grease IMPORTANT NOTE - Time intervals shown are maximum. Actual use and your experience will determine the frequency of required maintenance. MAINTENANCE PROCEDURE NOTES: 1 Apply Mobil SHC634 Synthetic Gear Oil every 300 hours of use. 2 Low evaporative fuel tanks DO NOT require regular maintenance to maintain emission integrity.
  • Page 34 MAINTENANCE PS262 Place the gear case on the RH side and supported so the outer tube is parallel to the ground. Refill the gear case with 60 cc (2.0 fl.oz) of Mobil SHC634 Synthetic Gear Oil to the bottom of the chamfer on the output gear.

  • Page 35: Troubleshooting

    PS262 TROUBLESHOOTING TROUBLESHOOTING ENGINE PROBLEM TROUBLESHOOTING CHART Problem Check Status Cause Remedy Fuel strainer or Clean or replace Fuel at No fuel at fuel line carburetor carburetor See your dealer obstructed No fuel at Carburetor See your dealer cylinder OPEN choke Fuel at Engine Clean or replace...

  • Page 36: Storage

    STORAGE PS262 ENGINE PROBLEM TROUBLESHOOTING CHART Problem Check Status Cause Remedy Engine Internal engine does not See your dealer problem crank Fuel vapors are extremely flammable and may cause fire and/or explosion. Never test for ignition spark by grounding spark plug near cylinder plug hole, otherwise serious personal injury may result.

  • Page 37: Specifications

    PS262 SPECIFICATIONS Drain fuel tank completely. Press purge bulb 6-7 times to remove remaining fuel from carburetor then drain the tank again. Close choke, start and run the engine until it stops due to lack of fuel. Allow engine to cool. Remove the spark plug lead from the spark plug. Remove the spark plug.

  • Page 38: Product Registration

    PRODUCT REGISTRATION Thank you for choosing Shindaiwa Power Equipment Please go to http://www.shindaiwa-usa.com to register your new product on- line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO, Inc. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.
  • Page 39 PS262 PRODUCT REGISTRATION X7502342101 © 06/20 ECHO Incorporated...
  • Page 40 T99715001001 - T99715999999 U45015001001 - U45015999999 ECHO INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 -usa www.shindaiwa .com...
