BR100-SSR-R AND BR100-SSR-SM
MACDONALD STAINLESS STEEL HORIZONTAL
BABY CHANGE TABLE
897 (SM)
862 (R)
845
902
!
WARNING:
• Failure to follow these warnings and the installation instructions could result in
serious injury or death.
• Read all instructions before installing diaper changing station. Keep these
instructions. DO NOT discard.
FFL
MACDONALD INDUSTRIES LIMITED
INSTALLATION INSTRUCTIONS
13 (R)
452(R)
541(SM)
90 (SM)
www.macdonaldindustries.co.nz
1
Advertisement
Table of Contents
Summary of Contents for Macdonald BR100-SSR-R
- Page 1 MACDONALD INDUSTRIES LIMITED INSTALLATION INSTRUCTIONS BR100-SSR-R AND BR100-SSR-SM MACDONALD STAINLESS STEEL HORIZONTAL BABY CHANGE TABLE 897 (SM) 862 (R) 13 (R) 90 (SM) 452(R) 541(SM) WARNING: • Failure to follow these warnings and the installation instructions could result in serious injury or death.
- Page 2 ASSEMBLY INSTRUCTIONS ADULT INSTALLATION REQUIRED. TOOLS REQUIRED: Level (A) Measuring tape (B) Power drill (C) • READ ALL INSTRUCTIONS BEFORE ASSEMBLY OF DIAPER CHANGING STATION. • Unpack carton and identify all parts. WARNING: • This changer has six (6) recess mounting holes. •...
- Page 3 MACDONALD INDUSTRIES LIMITED INSTALLATION INSTRUCTIONS OPERATION: Rotate base downward. Place infant on top of the changing surface. Use restraint system as described below. After child has been changed, remove restraint system and rotate base back up against the wall. USE OF RESTRAINT SYSTEM: Place child so restraint strap is located at abdomen.
- Page 4 INSTALLATION - SURFACE MOUNT Recommended Blocking: If the walls do not have studs on center, then additional blocking is necessary (Fig. d). Contact an architect or building contractor to make sure the blocking is adequate and complies with building codes. 813mm on centre 813mm on centre Fig.
