Summary of Contents for Sven RX-G970
- Page 1 Gaming Optical Mouse USER’S MANUAL RX-G970 www.sven.fi...
-
Page 2: Buyer Recommendations
• Dispose of in accordance with regulations for the disposal of household and computer equipment. APPOINTMENT RX-G970 gaming mouse is an input device. It is designed for entering (entering) information into the computer, as well as controlling the operation of the computer. -
Page 3: Special Features
(downloaded from the website www.sven.fi). Connect the mouse to the free USB port of your PC, run the previously downloaded SVEN RX-G970.exe file to install the driver, follow the installer’s advice. • After installation, the program will automatically detect the presence of the mouse. - Page 4 Gaming Optical Mouse Main Window By default, the keys are configured as in the picture below. Each mouse button is numbered and highlighted with a number from 1 to 7, hovering the cursor to the list on the left allowing the user to see the mouse button that needs to be reassigned.
- Page 5 User’s Manual RX-G970 • Back – previous browser page. • DPI – submenu, DPI + (resolution increase), DPI- (decrease resolution), DPI Loop (change resolution cyclically). • Three click – press the button three times. • Multimedia – opens a submenu. The standard commands for managing the media player are collected (detailed description below).
- Page 6 Gaming Optical Mouse "Fire key" settings The "Fire key" parameter allows you to assign keyboard functions with the mouse buttons. To select a keyboard key, click the area with the letter "A", select "Keystroke", a window with all displayed keystrokes will appear. Also you can adjust the input speed of "Intervals"...
- Page 7 User’s Manual RX-G970 Set the resolution of the sensor (DPI). In the "DPI Setting" menu, you can adjust the sensor resolution and the color of the mouse wheel backlight. 1. Click on the "DPI Setting" line (the setup menu will open).
- Page 8 Gaming Optical Mouse 1. In the "Effect" list, select one of the twelve light effects. 2. For some effects, you can adjust the speed of switching "Speed", the brightness of the illumination of the "Brightness", as well as the direction of switching effects "Direction"...
-
Page 9: Macro Editor
User’s Manual RX-G970 Macro editor. The macro editor allows you to create and edit macros. A macro is a sequence of events, consisting of pressing and releasing the keyboard keys, mouse buttons, and the time intervals between them. 1. In the main window on the left, click "Macro Editor", the window for creating and editing macros will open. - Page 10 Gaming Optical Mouse Profile settings function. The profile makes it very flexible to use the mouse settings for each application separately. For example, if you play different games, for each game you use convenient mouse settings, or work with documents, there is no need to change the mouse settings constantly: just set up the mouse once and save the settings for the selected profile.
-
Page 11: Troubleshooting
Weight, g Notes: • Technical specifications given in this table are supplemental information and cannot give occasion to claims. • Technical specifications are subject to change without notice due to the im- provement of SVEN production. Technical support is on www.sven.fi. - Page 12 Произведено под контролем «Свен Скандинавия Лимитед», 48310, Финляндия, Котка, Котолахдентие, 15. Сделано в Китае. Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road, № 02-02, Singapore, 427447. Produced under the control of Oy Sven Scandinavia Ltd. 15, Kotolah- dentie, Kotka, Finland, 48310. Made in China.
