EL.MO. Spa e-Vision PROIPF01TC User Manual

Temperature screening and face recognition terminal

Advertisement

USER MANUAL
PROIPF01TC
Temperature screening and
face recognition terminal
Disclaimer
With regard to the product with internet access, the use of product shall be wholly at
your own risks. Our company shall be irresponsible for abnormal operation, privacy
leakage or other damages resulting from cyber attack, hacker attack, virus inspection, or
other internet security risks; however, our company will provide timely technical
support if necessary.
Surveillance laws vary from country to country. Check all laws in your local region
before using this product for surveillance purposes. We shall not take the responsibility
for any consequences resulting from illegal operations.
Regulatory Information
FCC Marking
The products have be tested and found in compliance with the council FCC
rules and regulations part 15 subpart B. Operation of this product is subject the
following two conditions: (1) this device may not cause harmful interface, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
CE Marking
The products have been manufactured to comply with the following directives.
EMC Directive 2014/30/EU
RoHS
The products have designed and manufactured in accordance with Directive EU RoHS
Directive 2011/65/EU and its amendment Directive EU 2015/863 on the restriction of the
use of certain hazardous substances in electrical and electronic equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the e-Vision PROIPF01TC and is the answer not in the manual?

Questions and answers

Summary of Contents for EL.MO. Spa e-Vision PROIPF01TC

  • Page 1 USER MANUAL PROIPF01TC Temperature screening and face recognition terminal Disclaimer  With regard to the product with internet access, the use of product shall be wholly at your own risks. Our company shall be irresponsible for abnormal operation, privacy leakage or other damages resulting from cyber attack, hacker attack, virus inspection, or other internet security risks;...
  • Page 2 Temperature Screening & Face Recognition Terminal User Manual Notes on Safety  This product is intended to be supplied by a Listed Power Unit, marked with 'Limited Power Source', 'LPS' on unit, output rated minimum 12V/2 A or POE 48V/ 350mA or AC24V (depending on models), no more than 2000m altitude of operation and Tma=60 Deg.C.
  • Page 3: Table Of Contents

    Temperature Screening & Face Recognition Terminal User Manual Table of Contents Introduction ........................1 Network Connection ......................2 LAN .......................... 2 1.1.1 Access through IP-Tool ..................2 1.1.2 Directly Access through IE ................4 WAN ......................... 5 TEM Screening & FR Config ................... 9 3.1 Temperature Screening Settings ..................
  • Page 4 Temperature Screening & Face Recognition Terminal User Manual 6.3.5 Cable Disconnection ....................33 6.3.6 Alarm In ......................... 33 6.3.7 Alarm Out....................... 34 6.4 Network Configuration ....................35 6.4.1 TCP/IP ........................35 6.4.2 Port ......................... 37 6.4.3 Server Configuration ....................37 6.4.4 DDNS ........................
  • Page 5: Introduction

    Temperature Screening & Face Recognition Terminal User Manual Introduction Main Features  8 inch LCD screen  Support IR high-accuracy body temperature measurement; non-contact screening  The face wearing masks also can be recognized  It will trigger voice alarm when abnormal/normal body temperature and no mask are detected ...
  • Page 6: Network Connection

    Temperature Screening & Face Recognition Terminal User Manual Network Connection Connect IP-Cam via LAN or WAN. Here only take IE browser for example. The details are as follows: 1.1 LAN In LAN, there are two ways to access IP-Cam: 1. access through IP-Tool; 2. directly access through IE browser.
  • Page 7 Temperature Screening & Face Recognition Terminal User Manual of your device according to the practical situation. For example, the IP address of your computer is 192.168.1.4. So the IP address of the camera shall be changed to 192.168.1.X. After modification, please enter the password of the administrator and click the “Modify”...
  • Page 8: Directly Access Through Ie

    Temperature Screening & Face Recognition Terminal User Manual The system will pop up the above-mentioned textbox to ask you to change the default password. It is strongly recommended to change the default password for account security. If “Do not show again” is checked, the textbox will not appear next time. 1.1.2 Directly Access through IE The default network settings are as shown below: IP address: 192.168.226.201...
  • Page 9: Wan

    Temperature Screening & Face Recognition Terminal User Manual Select “Properties” and then select internet protocol according to the actual situation (for example: IPv4). Next, click the “Properties” button to set the network of the PC. ② Open the IE browser and enter the default address of IP-CAM and confirm. ③...
  • Page 10 Temperature Screening & Face Recognition Terminal User Manual ① Make sure the camera is connected to the local network and then log in the camera via LAN and go to ConfigNetworkPort menu to set the port number. Port Setup ② Go to Config NetworkTCP/IP menu to modify the IP address. IP Setup ③...
  • Page 11 Temperature Screening & Face Recognition Terminal User Manual Router Setup ④ Open the IE browser and enter its WAN IP and http port to access. (for example, if the http port is changed to 81, please enter “192.198.1.201:81” in the address bar of web browser to access).
  • Page 12 Temperature Screening & Face Recognition Terminal User Manual  Access through static IP Network connection The setup steps are as follow: ① Go to ConfigNetworkPort menu to set the port number. ② Go to Config NetworkTCP/IP menu to set the IP address. Check “Use the following IP address”...
  • Page 13: Tem Screening & Fr Config

    Temperature Screening & Face Recognition Terminal User Manual TEM Screening & FR Config 3.1 Temperature Screening Settings After the network is connected, go to the web client. Click ConfigTemperature Screening to go to the following interface. Enable Temperature Screening and then set the high temperature threshold and the low temperature threshold.
  • Page 14: Face Match Configuration

    Temperature Screening & Face Recognition Terminal User Manual temperature alarm and save the images on an SD card. Trigger SD Recording: If selected, video will be recorded on an SD card on detecting abnormal temperature alarm. Trigger Email: If “Trigger Email” and “Attach Picture” are checked (email address must be set first in the Email configuration interface), the captured pictures and triggered event will be sent into those addresses.
  • Page 15: Face Database Management

    Temperature Screening & Face Recognition Terminal User Manual Deduplication Period: In the set period, delete the repeated comparison results. Similarity threshold: When the similarity of the captured face picture and the face picture added into the face database exceeds the similarity threshold, alarms will be triggered. 3.3 Face Database Management Click “Face Database Management”...
  • Page 16: Mask Detection

    Temperature Screening & Face Recognition Terminal User Manual After adding face pictures, you can search them by name, gender, ID number and so on. Click “Modify” to change people information and click “Delete” to delete this face picture. 3.4 Mask Detection Click ConfigAlarmMask Detection to go to the following interface.
  • Page 17 Temperature Screening & Face Recognition Terminal User Manual Enable “Mask Detection” as needed. Set the alarm holding time. Set the alarm trigger options. Alarm Out: If enabled, alarm output will be triggered when the detected person doesn't wear a mask. Trigger Audio Alarm: If enabled, the alarm voice will be broadcasted when the detected person doesn’t wear a mask.
  • Page 18: Live View

    Temperature Screening & Face Recognition Terminal User Manual Live View 4.1 Temperature Screening & Face Recognition View 4.1.1 Temperature Screening Requirements For accuracy temperature screening, here are some recommendations. The detected person shall place his/her face within the pre-defined face detection area. His/her forehead shall be in the middle of the “Temp zone”...
  • Page 19: Temperature Screening & Face Recognition View

    Temperature Screening & Face Recognition Terminal User Manual Please have a rest after strenuous exercise and then test the temperature. If there is sweat on the forehead, please wipe it and take a rest and then test the temperature. The installation height shall fit the height of the detected people. Note that the temperature measurement module shall not be higher than the height of the detected people.
  • Page 20: Live View Via Web

    Temperature Screening & Face Recognition Terminal User Manual The system will measure the temperature and compare the captured face at the same time as shown below. When the captured face is not added to the face database or the similarity is lower than the pre-defined value, it will display “Match Failure”...
  • Page 21 Temperature Screening & Face Recognition Terminal User Manual The following table is the instructions of the icons on the live view interface. Icon Description Icon Description Original size Start/stop local recording Fit correct scale Zoom in Auto (fill the window) Zoom out Full screen SD card recording indicator...
  • Page 22 Temperature Screening & Face Recognition Terminal User Manual  View the comparison details In area ②, click the compared face picture to bring up the following window. In this interface, you can view the detailed comparison information.  Add captured face pictures to the face database Click a captured picture in area ①.
  • Page 23: Access Control Settings

    Temperature Screening & Face Recognition Terminal User Manual Access Control Settings 5.1 Door Lock Settings Click ConfigAccess ControlDoor Lock to go to the following interface. After the access control device is connected to the terminal, you can set opening mode in this interface. Opening Mode: Opening the door by face recognition or by password can be selected.
  • Page 24: Tampering Alarm Settings

    Temperature Screening & Face Recognition Terminal User Manual reader is connected to the Wiegand interface, please select “Wiegand Input”. If the access controller is connected to the Wiegand interface, please select “Wiegand Output”. You can also select the alarm output as needed. 5.3 Tampering Alarm Settings In order to avoid the removal or damage by the external force, the tampering alarm can be set for the terminal.
  • Page 25: Other Configurations

    Temperature Screening & Face Recognition Terminal User Manual Other Configurations In the Webcam client, choose “Config” to go to the configuration interface. Note: Wherever applicable, click the “Save” button to save the settings. 6.1 System Settings 6.1.1 Basic Information In the “Basic Information” interface, the system information of the device is listed. Some versions may support device ID and QR code.
  • Page 26: Local Config

    Temperature Screening & Face Recognition Terminal User Manual Select the time zone and DST as required. Click the “Date and Time” tab to set the time mode. 6.1.3 Local Config Go to ConfigSystemLocal Config to set up the storage path of captured pictures and recorded videos on the local PC.
  • Page 27 Temperature Screening & Face Recognition Terminal User Manual  SD Card Management Click the “Format” button to format the SD card. All data will be cleared by clicking this button. Click the “Eject” button to stop writing data to SD card. Then the SD card can be ejected safely.
  • Page 28 Temperature Screening & Face Recognition Terminal User Manual Weekly schedule Set the alarm time from Monday to Sunday for a single week. Each day is divided in one hour increments. Green means scheduled. Blank means unscheduled. “Add”: Add the schedule for a special day. Drag the mouse to set the time on the timeline. “Erase”: Delete the schedule.
  • Page 29: Image Configuration

    Temperature Screening & Face Recognition Terminal User Manual Set the format, resolution and quality of the image saved on the SD card and the snapshot interval and quantity and the timing snapshot here. Snapshot Quantity: The number you set here is the maximum quantity of snapshots. The actual quantity of snapshots may be less than this number.
  • Page 30 Temperature Screening & Face Recognition Terminal User Manual Brightness: Set the brightness level of the camera’s image. Contrast: Set the color difference between the brightest and darkest parts. Hue: Set the total color degree of the image. Saturation: Set the degree of color purity. The purer the color, the brighter the image is. Sharpness: Set the resolution level of the image plane and the sharpness level of the image edge.
  • Page 31: Video / Audio Configuration

    Temperature Screening & Face Recognition Terminal User Manual can be adjusted. Gain Mode: Choose “Auto” or “Manual”. If “Auto” is selected, the gain value will be automatically adjusted according to the actual situation. If “Manual” is selected, the gain value shall be set manually. The higher the value is, the brighter the image is. Schedule Settings of Image Parameters: Click the “Schedule”...
  • Page 32: Osd Configuration

    Temperature Screening & Face Recognition Terminal User Manual Three video streams can be adjustable. Resolution: The size of image. Frame rate: The higher the frame rate, the video is smoother. Bitrate type: CBR and VBR are optional. Bitrate is related to image quality. CBR means that no matter how much change is seen in the video scene, the compression bitrate will be kept constant.
  • Page 33: Screen Brightness

    Temperature Screening & Face Recognition Terminal User Manual Set time stamp, device name, OSD content and picture overlap here. After enabling the corresponding display and entering the content, drag them to change their position. Then click the “Save” button to save the settings. Picture Overlap Settings: Check “OSD Content1”, choose “Picture Overlay”...
  • Page 34: Face Exposure

    Temperature Screening & Face Recognition Terminal User Manual White Light Mode: “OFF”, “Manual” or “Auto” is optional. In low illumination condition, this mode can be enabled. 6.2.6 Face Exposure To enable and set face exposure, please go to ConfigImageFace Exposure interface. When the brightness of the captured face is not enough, it can be enabled.
  • Page 35 Temperature Screening & Face Recognition Terminal User Manual 1. Enable the applicable detection that’s desired. Scene Change Detection: Alarms will be triggered if the scene of the monitor video has changed. Video Blur Detection: Alarms will be triggered if the video becomes blurry. Enable Video Color Cast Detection: Alarms will be triggered if the video becomes obscured.
  • Page 36: Sd Card Full

    Temperature Screening & Face Recognition Terminal User Manual the system responds to the blurriness of the image. The sensitivity value of Video Color Cast Detection: The higher the value is, the more sensitive the system responds to the obscuring of the image. 6.3.2 SD Card Full 1.
  • Page 37: Ip Address Conflict

    Temperature Screening & Face Recognition Terminal User Manual 3. Set alarm trigger options. Trigger alarm out, Email and FTP. The setup steps are the same as temperature screening settings. Please refer to temperature screening settings chapter for details. 6.3.4 IP Address Conflict 1.
  • Page 38: Alarm Out

    Temperature Screening & Face Recognition Terminal User Manual 1. Select the sensor ID, click “Enable” and set the alarm type, alarm holding time and sensor name. 2. Set alarm trigger options. The setup steps are the same as temperature screening settings. Please refer to temperature screening settings chapter for details.
  • Page 39: Network Configuration

    Temperature Screening & Face Recognition Terminal User Manual Day/Night Switch Linkage: Having selected this mode, select the alarm type and then choose to open or close alarm out when the camera switches to day mode or night mode. Timing: Select the alarm type. Then click “Add” and drag the mouse on the timeline to set the schedule of alarm out;...
  • Page 40 Temperature Screening & Face Recognition Terminal User Manual Use IP address (take IPv4 for example)-There are two options for IP setup: obtain an IP address automatically by DHCP and use the following IP address. Please choose one of the options as needed. Test: Test the effectiveness of the IP address by clicking this button.
  • Page 41: Port

    Temperature Screening & Face Recognition Terminal User Manual 6.4.2 Port Go to ConfigNetworkPort interface as shown below. HTTP port, Data port and RTSP port can be set. HTTP Port: The default HTTP port is 80. It can be changed to any port which is not occupied.
  • Page 42 Temperature Screening & Face Recognition Terminal User Manual 2. Apply for a domain name. Take www.dvrdyndns.com for example. Enter www.dvrdydns.com in the IE address bar to visit its website. Then Click the “Registration” button. Create domain name. After the domain name is successfully applied for, the domain name will be listed as below. 3.
  • Page 43: Rtsp

    Temperature Screening & Face Recognition Terminal User Manual 4. Click the “Save” button to save the settings. 6.4.5 RTSP Go to ConfigNetworkRTSP. Select “Enable” to enable the RTSP function. Port: Access port of the streaming media. The default number is 554. RTSP Address: The RTSP address (unicast) format that can be used to play the stream in a media player.
  • Page 44: Upnp

    Temperature Screening & Face Recognition Terminal User Manual 5. If the coding format of the video of the main stream is MJPEG, the video may be disordered at some resolutions. 6.4.6 UPnP If this function is enabled, the camera can be quickly accessed through the LAN. Go to ConfigNetworkUPnP.
  • Page 45: Ftp

    Temperature Screening & Face Recognition Terminal User Manual what’s required. SMTP Port: The SMTP port. Send Interval(S): The time interval of sending email. For example, if it is set to 60 seconds and multiple motion detection alarms are triggered within 60 seconds, they will be considered as only one alarm event and only one email will be sent.
  • Page 46 Temperature Screening & Face Recognition Terminal User Manual There is a certificate installed by default as shown above. Enable this function and save it. Then the camera can be accessed by entering https://IP: https port via the web browser (eg. https://192.168.226.201:443).
  • Page 47: P2P (Optional)

    Temperature Screening & Face Recognition Terminal User Manual Click “Create” to create the certificate request. Then download the certificate request and submit it to the trusted certificate authority for signature. After receiving the signed certificate, import the certificate to the device. 6.4.10 P2P (Optional) If this function is enabled, the network camera can be quickly accessed by adding the device ID in mobile surveillance client or CMS/NVMS client via WAN.
  • Page 48 Temperature Screening & Face Recognition Terminal User Manual 2. Enter user name in “User Name” textbox. 3. Enter the password in the “Password” and “Confirm Password” textbox. Please set the password according to the requirement of the password security level (Go to ConfigSecuritySecurity ManagementPassword Security interface to set the security level).
  • Page 49: Online User

    Temperature Screening & Face Recognition Terminal User Manual 2. Click the “Delete” button to delete the user. Note: The default administrator account cannot be deleted. 6.5.2 Online User Go to ConfigSecurityOnline User to view the user who is viewing the live video. An administrator user can kick out all the other users (including other administrators).
  • Page 50: Maintenance Configuration

    Temperature Screening & Face Recognition Terminal User Manual  Password Security Please set the password level and expiration time as needed. Password Level: Weak, Medium or Strong. Weak level: Numbers, special characters, upper or lower case letters can be used. You can choose one of them or any combination of them when setting the password.
  • Page 51: Reboot

    Temperature Screening & Face Recognition Terminal User Manual  Import & Export Settings Configuration settings of the camera can be exported form a camera into another camera. 1. Click “Browse” to select the save path for import or export information on the PC. 2.
  • Page 52: Operation Log

    Temperature Screening & Face Recognition Terminal User Manual 1. Click the “Browse” button to select the save path of the upgrade file 2. Click the “Upgrade” button to start upgrading the firmware. 3. The device will restart automatically Caution! Do not close the browser or disconnect the camera from the network during the upgrade.
  • Page 53: Search

    Temperature Screening & Face Recognition Terminal User Manual Search 7.1 Image Search Click Search to go to the interface as shown below. Images that are saved on the SD card can be found here.  Local Image Search Choose “Picture”—“Local”. Set time: Select date and choose the start and end time.
  • Page 54 Temperature Screening & Face Recognition Terminal User Manual Click to return to the previous interface.  SD Card Image Search Choose “Picture”—“SD Card”. Set time: Select date and choose the start and end time. Choose the alarm events at the bottom of the interface. Click to search the images.
  • Page 55: Video Search

    Temperature Screening & Face Recognition Terminal User Manual Icon Description Icon Description Close: Select an image and click this Close all: Click this button to button to close the image. close all images. Save all: Click this button to Save: Click this button to select the select the path for saving all path for saving the image on the PC.
  • Page 56: Sd Card Video Search

    Temperature Screening & Face Recognition Terminal User Manual Icon Description Icon Description Play button. After pausing the video, click this button Pause button to continue playing. Stop button Speed down Speed up Watermark display Enable / disable audio; drag the slider to adjust the volume after enabling audio.
  • Page 57 Temperature Screening & Face Recognition Terminal User Manual Select the alarm events at the bottom of the interface. Select mix stream (video and audio stream) or video stream as needed. Double click on a file name in the list to start playback. The time table can be shown in 24H/12H/2H/1H format by clicking the corresponding buttons.
  • Page 58 Temperature Screening & Face Recognition Terminal User Manual Click “Set up” to set the storage directory of the video files. Click “Open” to play the video. Click “Clear List” to clear the downloading list. Click “Close” to close the downloading window.
  • Page 59: Face Match Result Search

    Temperature Screening & Face Recognition Terminal User Manual Face Match Result Search Click “Face Log” tab to go to the face recognition result search interface. Set the start time and end time and click “Search” to view the face recognition result. Red time tag means no comparison result.
  • Page 60: Appendix

    Temperature Screening & Face Recognition Terminal User Manual Appendix Appendix 1 Troubleshooting How to find the password? A:Reset the device to the default factory settings. Default IP: 192.168.226.201; User name: admin; Password: 123456 Fail to connect devices through IE browser. A: Network is not well connected.
  • Page 61 Temperature Screening & Face Recognition Terminal User Manual No sound can be heard. A:Audio input device is not connected. Please connect and try again. B: Audio function is not enabled at the corresponding channel. Please enable this function.
  • Page 62: Appendix 2 Specifications

    Temperature Screening & Face Recognition Terminal User Manual Appendix 2 Specifications Mode 2MP Temperature Screening & Face Recognition Terminal Performance Embedded Linux Storage 8Gb DDR3 +16GB EMMC Screen Display Screen 8inch LCD screen; resolution: 1280x800; contrast: 500:1 Brightness 500 lux Control Interface Temperature Measurement Temperature...
  • Page 63 Temperature Screening & Face Recognition Terminal User Manual Alarm Input Alarm Output 2 CH Wiegand input/output(26/34) Wiegand Interface RS485 RS485x1 (half duplex) Door Lock Output Relay output, NO/NC(optional), delay setting supported SD Card Interface 1 micro SD card slot, up to 128G USB Interface USB x1 Anti-Tamper Interface...
  • Page 64 Information and product features herein are not binding and may be changed without prior notice. EL.MO. Spa | Via Pontarola, 70 | 35011 Campodarsego (PD) - Italy Tel. +39 049 9203333 | Fax +39 049 9200306 | Help Desk +39 049 9200426 | www.elmospa.com | international@elmospa.com...
