Summary of Contents for QuickLink Studio-in-a-box ST500
- Page 1 Quicklink Studio-in-a-box (ST500) User Guide Rev 2...
- Page 2 Studio-in-a-box/ST500 user Power options Network settings User accounts Video settings Audio settings Show/hide preview Studio/Skype TX settings Record settings Show/hide settings menu quicklink.tv...
- Page 3 Ethernet ports. The inbuilt Wi-Fi or a USB dongle can also be used for internet connectivity Next, plug in your headphone/earpiece into the green 3.5mm socket and a microphone into the Power 12v Power XLR audio connector connector connector lighting connector Power on the unit by pressing the power switch. quicklink.tv...
- Page 4 Talk into the microphone, ensuring there is a green light flashing when you speak. If this is not flashing, please increase the microphone level until the light flashes green. If the light is flashing red, please decrease the microphone level until the light flashes green. quicklink.tv...
- Page 5 Plug your earpiece into the headphone port. Headphone port Ensure the headphone volume level is set to roughly 50%. This can be adjusted when in call if needed. quicklink.tv...
- Page 6 On first use, you will need to sign into Quicklink Studio. Using the ST500’s screen, tap the flashing icon to open the login. Under the Studio section, tap ‘Login’. Enter your sign in credentials that have been provided to you by the Administrator.
- Page 7 When this is enabled, the Studio-in-a-box will automatically frame the user in the shot. Alternatively, the camera controls, inbuilt lighting and focus can be controlled remotely by the Administrator from the Quicklink Manager. From the menu, you can also open the audio settings by tapping icon.
- Page 8 To begin recording, tap the icon. Once your recording has started, a recording icon and time indicator will appear at the top of the screen. To stop the recording, tap the icon. quicklink.tv...
- Page 9 You will receive a prompt to delete or save the recorded clip. Select ‘Save’, then tap ‘Execute’. Your clip is now ready to transfer to a USB. Plug a USB drive/external storage device into one of the USB ports in the rear of the ST500 (Studio-in-a-box). quicklink.tv...
- Page 10 USB drive/external storage device. You will now receive a prompt that the recorded file is moving to the USB drive. Please wait. The time to complete the movement of the file will depend on the length of the recorded clip. quicklink.tv...
- Page 11 When the recorded clip has transferred you will receive a prompt to confirm. Tap ‘OK’. Your recorded clip will now be available on your USB drive for use. Quicklink Customer Portal Please visit the for more information. quicklink.tv...
