TABLE OF CONTENT Safety Instructions Warnings and Precautionary Measures Disposing of Old Devices and Electronic Devices FCC Compliance and Advisory Statement CE Compliance Statement Legal Notices and Trademarks Qualcomm Quick Charge™ 3.0 ® Charging Ports Battery LED Status Evergreen Product Includes Product Description Further Details Product Overview...
Page 6
Getting Started Charging the Battery Checking the Battery Life Information on Charging Devices Warning Functions Fast Charging Notes on Quick Charging Care and Maintenance Troubleshooting Product Details Identification & Serial Number Need more Information?
SAFETY INSTRUCTIONS » Before using your Evergreen, please read the user manual carefully and keep it somewhere safe for your later reference. » Do not use your Evergreen if the product is clearly defective. » This product is not a toy and is not intended for use by children under 14 years of age. Warnings and Precautionary Measures »...
Disposing of Old Devices and Electronic Devices This symbol means the product must not be discarded as household waste, and should be delivered to an appropriate collection facility for recycling. Proper disposal and recycling helps protect natural resources, human health and the environment. For more information on disposal and recycling of this product, contact your local municipality, disposal service, or the shop where you bought this product.
CE Compliance Statement Vonmählen hereby declares that this product complies with all applicable EU directive requirements. The complete declaration of conformity can be found at service.vonmaehlen.com/hc/en. LEGAL NOTICES AND TRADEMARKS Qualcomm Quick Charge™ 3.0 ® Qualcomm Quick Charge™ is a product of Qualcomm Technologies, Inc. Qualcomm is a ®...
Battery Battery type Integrated rechargeable lithium polymer battery 37 Wh Battery capacity 10,000 mAh / 3.7 V Battery life Normal charging: 6 hours Fast charging: 3.5 hours LED Status Power on The white LED display on the top of the powerbank lights up depending on the battery level.
EVERGREEN Product Includes 1. Evergreen Powerbank 4. Travel charger (18 W) 2. Pouch 5. User manual 3. USB-C charging cable Product Description Evergreen gives your devices the energy they need for the day. The powerbank allows you to charge three devices at the same time.
PRODUCT OVERVIEW 1. Power button 2. LED indicator 3. Micro-USB Port (input) 4. USB-C dual port (input and output) 5. USB-A Port (1) (output) 6. USB-A Port (2) (output)
GETTING STARTED Fully charge the battery before using the powerbank for the first time. After the first charging, the powerbank has sufficient battery power to charge different devices several times. Charging the Battery If the battery is weak, the powerbank can be charged from a power source using the USB-C or Micro-USB port within 3-4 hours.
Information on Charging Devices » Devices should be disconnected as soon as they are fully charged to avoid further draining of the powerbank. » If no device is connected to the powerbank when it is switched on, the powerbank switches off automatically after 35 seconds to save energy.
FAST CHARGING The powerbank has the quick charge feature using Qualcomm Quick Charge™ 3.0 (QC 3.0) and Power Delivery ® (PD). Depending on the device and the connected charging cable (and power supply), the powerbank automati- cally activates the respective quick charge mode. Notes on Quick Charging »...
TROUBLESHOOTING Problem Possible Cause Possible Solution Powerbank does not ∙ Battery is empty ∙ Charge the powerbank turn on The device does ∙ Battery is empty ∙ Charge the powerbank not charge ∙ Devices are not properly ∙ Disconnect the devices and reconnect connected the device to the powerbank ∙...
Problem Possible Cause Possible Solution The powerbank does ∙ Powerbank and power source ∙ Disconnect the devices and reconnect not charge are not properly connected the powerbank to the power source. ∙ Input and output of the power- ∙ Make sure that the powerbank is con- bank were switched nected to the power source using one of the USB-C or Micro-USB inputs...
NEED MORE INFORMATION? Visit service.vonmaehlen.com/hc/en for detailed product information regarding Evergreen. You will also find information about current orders and promotions as well as the FAQ section about Vonmählen products and services. service@vonmaehlen.com Product Care +49 (0) 4131 22 09 50 (9 a.m. to 5 p.m. CET) Instruction Manual vonmaehlen @vonmaehlen...
Page 21
INHALTSVERZEICHNIS Sicherheitshinweise Warnungen und Vorsichtsmaßnahmen Entsorgung von Altgeräten und elektronischen Geräten FCC-Konformitäts- und Beratungserklärung CE-Konformitätserklärung Rechtliche Hinweise und Warenzeichen Qualcomm Quick Charge™ 3.0 ® Ladeanschlüsse Akku LED-Status Evergreen Zubehör / Lieferumfang Produktbeschreibung Weitere Details Produktübersicht...
Page 22
Erste Schritte Laden des Akkus Überprüfung der Akkulaufzeit Hinweise zum Laden von Geräten Warnung Funktionen Schnellladen Hinweise zum Schnellladen Pflege und Wartung Problembehebung Produktdetails Identifikations- & Seriennummer Weitere Informationen?
SICHERHEITSHINWEISE » Vor dem Gebrauch von Evergreen bitte sorgfältig die Bedienungsanleitung durchlesen und diese zum späteren Nachschlagen aufbewahren. » Evergreen nicht verwenden, wenn das Produkt offensichtlich defekt ist. » Dieses Produkt ist kein Spielzeug und nicht für die Verwendung von Kindern unter 14 Jahren bestimmt. Warnungen und Vorsichtsmaßnahmen »...
Entsorgung von Altgeräten und elektronischen Geräten Dieses Symbol bedeutet, dass das Produkt nicht mit dem Hausmüll entsorgt werden darf, sondern bei einer geeigneten Sammelstelle für das Recycling abgegeben werden muss. Die ordnungsgemäße Entsorgung und das Recycling tragen dazu bei, die natürlichen Ressourcen, die Gesundheit und die Umwelt zu schützen.
CE-Konformitätserklärung Vonmählen erklärt hiermit, dass dieses Produkt allen anwendbaren EU-Richtlinienanforderungen entspricht. Die vollständige Konformitätserklärung ist abrufbar unter service.vonmaehlen.com. RECHTLICHE HINWEISE UND WARENZEICHEN Qualcomm Quick Charge™ 3.0 ® Qualcomm Quick Charge™ ist ein Produkt von Qualcomm Technologies, Inc. Qualcomm ® ® ist eine Handelsmarke von Qualcomm Incorporated, registriert in den Vereinigten Staaten und anderen Ländern.
Akku Akkutyp Integrierter wiederaufladbarer Lithium-Polymer Akku 37 Wh Akkukapazität 10.000 mAh / 3,7 V Akkuladedauer Normalladen: 6 Stunden Schnellladen: 3,5 Stunden LED-Status Angeschaltet Die weiße LED-Anzeige auf der Oberseite der Powerbank leuchtet abhängig vom Akkustand. Ausgeschaltet Die LED-Anzeige erlischt. Akkustand Die weiße LED-Anzeige zeigt im angeschalteten Zustand ohne Verbindung eines Endgeräts den aktuellen Akkustand der Powerbank an.
EVERGREEN Zubehör / Lieferumfang 1. Evergreen Powerbank 4. Reiseladegerät (18 W) 2. Schutztasche 5. Benutzerhandbuch 3. USB-C Ladekabel Produktbeschreibung Evergreen gibt deinen Endgeräten die nötige Energie für den Tag. Die Powerbank bietet die Möglichkeit, drei Endgeräte gleichzeitig zu laden. So kannst du nicht nur deinen Akku immer mit voller Power ausstatten, sondern zusätzlich die Akkus deiner Freunde oder Kollegen.
ERSTE SCHRITTE Vor dem ersten Gebrauch der Powerbank den Akku vollständig aufladen. Nach dem ersten Laden hat die Powerbank ausreichend Akkuleistung für mehrmaliges Laden unterschiedlicher Endgeräte. Laden des Akkus Wenn der Akku schwach ist, kann die Powerbank über den USB-C- oder den Micro-USB-Anschluss innerhalb von 3-4 Stunden an einer Stromquelle geladen werden.
Hinweise zum Laden von Geräten » Endgeräte sollten getrennt werden, sobald diese vollständig aufgeladen sind, um eine weitere Entladung der Powerbank zu vermeiden. » Ist im angeschalteten Zustand kein Endgerät zum Laden mit der Powerbank verbunden, schaltet sich die Powerbank nach 35 Sekunden automatisch ab, um Energie zu sparen. Warnung 1.
SCHNELLLADEN Die Powerbank verfügt über die Schnellladefunktion mithilfe von Qualcomm Quick Charge™ 3.0 (QC 3.0) und ® Power Delivery (PD). Abhängig von dem jeweiligen Endgerät und dem verbundenen Ladekabel (und Netzteil) aktiviert die Powerbank automatisch den jeweiligen Schnelllademodus. Hinweise zum Schnellladen »...
PROBLEMBEHEBUNG Problem Mögliche Ursache Mögliche Lösung Powerbank lässt sich ∙ Akku der Powerbank ist leer ∙ Powerbank aufladen nicht einschalten Das Endgerät lädt nicht ∙ Akku der Powerbank ist leer ∙ Powerbank aufladen ∙ Geräte sind nicht richtig ∙ Verbindung der Geräte trennen und verbunden das Endgerät nochmal neu mit der Powerbank verbinden...
Problem Mögliche Ursache Mögliche Lösung Die Powerbank lädt nicht ∙ Powerbank und Stromquelle ∙ Verbindung der Geräte trennen und sind nicht richtig verbunden die Powerbank nochmal neu mit der Stromquelle verbinden ∙ Input und Output der Power- ∙ Sicherstellen, dass die Powerbank über bank wurden vertauscht einen der USB-C- bzw.
WEITERE INFORMATIONEN? Jetzt auf service.vonmaehlen.com detaillierte Produktinformationen zu Evergreen nachlesen. Dort ist neben Informationen rund um aktuelle Bestellungen und Aktionen auch das Vonmählen Produkt FAQ zu finden. service@vonmaehlen.com Produktpflege +49 (0) 4131 22 09 50 (9 bis 17 Uhr MEZ ) Bedienungsanleitung vonmaehlen @vonmaehlen...
Page 37
ÍNDICE DE CONTENIDOS Instrucciones de seguridad Advertencias y precauciones Eliminación de equipos y dispositivos electrónicos antiguos Declaración de advertencia y de conformidad con la FCC Declaración de conformidad CE Indicaciones legales y marcas registradas Qualcomm Quick Charge™ 3.0 ® Conexiones de carga Batería Estado del LED Evergreen...
Page 38
Primeros pasos Carga Estado de la batería Indicaciones para la carga de dispositivos Advertencias Funciones Carga rápida Indicaciones para la carga rápida Cuidados y Mantenimento Resolución de problemas Detalles del producto Números de identificación y de serie ¿Necesitas más información?
INSTRUCCIONES DE SEGURIDAD » Antes de utilizar Evergreen lee atentamente las instrucciones de uso y guárdalas para futuras consultas. » No utilices tu Evergreen si está claramente dañado. » Este producto no es un juguete y no deben emplearlo niños menores de 14 años. Advertencias y precauciones »...
Eliminación de equipos y dispositivos electrónicos antiguos Este símbolo significa que el producto no debe desecharse como residuo doméstico y que debe entregarse a un centro de recolección apropiado para reciclaje. La eliminación y el reciclado adecuados ayudan a proteger los recursos naturales, la salud de las personas y el medioambiente. Para obtener más información sobre la eliminación y el reciclado de este producto, póngase en contacto con su municipio, el servicio de gestión de residuos o el comercio donde haya comprado este producto.
Declaración de conformidad CE Vonmählen declara que este producto cumple con todos los requisitos aplicables de la directiva de la UE. La Declaración de Conformidad completa está disponible en service.vonmaehlen.com/hc/en INDICACIONES LEGALES Y MARCAS REGISTRADAS Qualcomm Quick Charge™ 3.0 ® Qualcomm Quick Charge™...
Batería Tipo de batería Batería de polímeros de litio de 37 Wh, recargable e integrada Capacidad de la batería 10.000 mAh / 3,7 V Tiempo de carga de la batería Carga normal: 6 horas Carga rápida: 3,5 horas Estado del LED Encendido El indicador LED blanco en la parte superior de la batería externa se ilumina en función del estado de la batería.
EVERGREEN Elementos incluidos 1. Evergreen Batería externa 4. Cargador de viaje (18 W) 2. Funda protectora 5. Manual de instrucciones 3. Cable de carga USB-C Descripción del producto Evergreen da a tus terminales la energía necesaria para todo el día. La batería externa ofrece la posibilidad de cargar tres dispositivos terminales de manera simultánea.
VISTA GENERAL DEL PRODUCTO 1. Botón de encendido 2. Indicador LED 3. Conexión Micro-USB (entrada) 4. Puerto doble USB-C (entrada y salida) 5. Conexión USB-A (1) (salida) 6. Conexión USB-A (2) (salida)
PRIMEROS PASOS Antes de utilizar la batería externa por primera vez, carga completamente la batería. Después de la primera carga, la batería externa cuenta con potencia suficiente para varias cargas de diferentes dispositivos. Carga Cuando queda poca batería, la batería externa se puede cargar en unas 3-4 horas conectándola a una toma de corriente a través de la conexión USB-C o Micro-USB.
Indicaciones para la carga de dispositivos » Los dispositivos terminales se deberán desconectar tan pronto como estén completamente cargados para evitar que la batería externa se siga descargando. » Si mientras la batería externa está encendida no hay ningún terminal conectado para cargarse, la batería externa se desconecta automáticamente al cabo de 35 segundos para ahorrar energía.
CARGA RÁPIDA La batería externa dispone de una función de carga rápida con ayuda de Qualcomm Quick Charge™ 3.0 ® (QC 3.0) y Power Delivery (PD). Independientemente del dispositivo terminal y del cable de carga conectado (y fuente de alimentación), la batería externa activa automáticamente el modo de carga rápida correspondiente. Indicaciones para la carga rápida »...
RESOLUCIÓN DE PROBLEMAS Problema Posible causa Posible solución La batería externa no se ∙ La batería está vacía ∙ Cargar la batería externa enciende El dispositivo terminal ∙ La batería externa está vacía. ∙ Carga la batería externa no carga ∙...
Problema Posible causa Posible solución La batería externa no ∙ La batería externa no está co- ∙ Desconecta los dispositivos y vuelve se carga nectada a la toma de corriente a conectar la batería externa con la toma de corriente ∙...
¿NECESITAS MÁS INFORMACIÓN? Reciben ahora en service.vonmaehlen.com/hc/en información detallada del producto sobre Evergreen. Allí encontrará información sobre los pedidos actuales y las promociones, así como las preguntas frecuentes sobre los productos de Vonmählen. service@vonmaehlen.com Cuidados del producto +49 (0) 4131 22 09 50 (de 9:00h a 17:00h PST) Manual de instrucciones vonmaehlen @vonmaehlen...
Page 53
TABLE DES MATIÈRES Consignes de sécurité Mises en garde et précautions Mise au rebut d’équipements et d’appareils électroniques usagés Déclaration de conformité FCC Déclaration de conformité CE Informations juridiques et marques déposées Qualcomm Quick Charge™ 3.0 ® Connecteurs de charge Batterie État de l’indicateur LED Evergreen...
Page 54
Première utilisation Charge de la batterie État de la batterie Remarques concernant la charge d’appareils Avertissement Fonctions Charge rapide Remarques concernant la charge rapide Entretien Résolution des Problèmes Détails du produit Numéro d’identification et de série Informations complémentaires...
CONSIGNES DE SÉCURITÉ » Avant d’utiliser Evergreen, veuillez lire attentivement le mode d’emploi et le conserver pour référence ultérieure. » Ne pas utiliser Evergreen en cas de défectuosité évidente. » Ce produit n’est pas un jouet et n’est pas destiné aux enfants de moins de 14 ans. Mises en garde et précautions »...
Mise au rebut d’équipements et d’appareils électroniques usagés Ce symbole signifie que le produit ne doit pas être jeté avec les déchets ménagers, mais doit être déposé dans un centre de collecte approprié pour recyclage. Une mise au rebut et un recyclage adé¬quats permettent de protéger les ressources naturelles, la santé...
Déclaration de conformité CE Vonmählen déclare par la présente que ce produit est conforme à toutes les exigences des directives euro- péennes applicables. La déclaration de conformité complète est disponible sur service.vonmaehlen.com/hc/en INFORMATIONS JURIDIQUES ET MARQUES DÉPOSÉES Qualcomm Quick Charge™ 3.0 ®...
Batterie Type de batterie Batterie au lithium polymère rechargeable intégrée 37 Wh Capacité de la batterie 10.000 mAh / 3,7 V Durée de vie de la batterie Charge standard : 6 heures Charge rapide : 3,5 heures État de l’indicateur LED Branché...
EVERGREEN Contenu du coffret 1. Evergreen Batterie externe 4. Chargeur de voyage (18 W) 2. Étui de protection 5. Manuel d’utilisation 3. Câble de chargement USB-C Description du produit Evergreen fournit à vos appareils toute l’énergie dont ils ont besoin pour la journée. La batterie externe permet de charger trois appareils simultanément.
PREMIÈRE UTILISATION Avant la première utilisation, chargez complètement la batterie externe. Après la première charge, la batterie externe dispose d’une puissance suffisante pour charger plusieurs appareils. Charge de la batterie Si la charge de la batterie externe est faible, celle-ci peut être chargée en 3-4 heures à partir d’une source d’alimentation via le connecteur USB-C ou Micro-USB.
Remarques concernant la charge d’appareils » Les appareils doivent être débranchés dès qu’ils sont complètement chargés pour éviter toute décharge supplémentaire de la batterie externe. » Si aucun appareil à recharger n’est raccordé à la batterie externe à la mise sous tension, la batterie externe s’éteint automatiquement après 35 secondes afin d’économiser de l’énergie.
CHARGE RAPIDE La batterie externe dispose d’une fonction de charge rapide grâce à Qualcomm Quick Charge™ 3.0 (QC 3.0) ® et Power Delivery (PD). En fonction de l’appareil et du câble de charge utilisés (et du bloc d’alimentation), la batterie externe active automatiquement le mode de charge rapide correspondant. Remarques concernant la charge rapide »...
RÉSOLUTION DES PROBLÈMES Problème Cause Possible Solution Possible La batterie externe ne ∙ La batterie est dechargée ∙ Chargez la batterie externe s’allume pas L’appareil ne se ∙ La batterie externe est vide ∙ Recharge de la batterie externe charge pas ∙...
Problème Cause Possible Solution Possible La batterie externe ne se ∙ La batterie externe et la source ∙ Débranchez les appareils et charge pas d’alimentation ne sont pas rebranchez la batterie externe correctement raccordées à la source d’alimentation ∙ L’entrée et la sortie de la batte- ∙...
INFORMATIONS COMPLÉMENTAIRES Visitez service.vonmaehlen.com/hc/en pour obtenir des informations detaillées sur le produit Evergreen. Vous y trouverez des informations sur les commandes en cours et les promotions ainsi que la section FAQ sur les produits et services Vonmählen. service@vonmaehlen.com Entretien produit +49 4131 22 09 50 ( 9 h 00 à...
