USER INSTRUCTION MANUAL
SRL SELF-RETRACTABLE LIFELNE
WITH LEADING EDGE
MODELS: 2408-SSH-LE, 2408-ARH-LE,
2430-SSH-LE, 2450-SSH-LE, 2465-SSH-LE
WARNING:
This product is part of a personal fall arrest, work positioning, or rescue system.
The user must follow the manufacturer's instruction for each component of the system.
This instruction must be provided to the user of this equipment.
Manufacturer's instructions must be followed for proper use and maintenance of this
equipment. Alterations or misuse of this product or failure to follow instructions may result in
serious injury or death. This equipment is intended to be used by persons trained in its correct
application and use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2408-SSH-LE and is the answer not in the manual?

Questions and answers

Summary of Contents for ironwear 2408-SSH-LE

  • Page 1 USER INSTRUCTION MANUAL SRL SELF-RETRACTABLE LIFELNE WITH LEADING EDGE MODELS: 2408-SSH-LE, 2408-ARH-LE, 2430-SSH-LE, 2450-SSH-LE, 2465-SSH-LE WARNING: This product is part of a personal fall arrest, work positioning, or rescue system. The user must follow the manufacturer's instruction for each component of the system.
  • Page 2 If you have questions on the use, care, or suitability of this equipment for your application, contact Ironwear: 800-329-2235, 2020 Seabird Way, Riviera Beach, FL 33404 Before using this equipment, record the product identification information from the ID label and RFID tag in the inspection and maintenance log of this manual.
  • Page 3 Connector: Connectors must be compatible in size, shape, and strength. Self-closing, self-locking connectors are required by ANSI and OSHA. -5000 lbs. (22.2 KN) for non-certified anchorages. -Two times the maximum arrest force permitted when certification exists Compatibility: Connecting Component Limitations: A Competent Person must ensure the compatibility of all connections and that of the system.
  • Page 4: Inspection Frequency

    INSPECTION FREQUENCY: SRL-LEs shall be inspected by the authorized person or rescuer before each use. Inspection shall be conducted by a competent person other than the user. The competent person shall use Inspection Schedule and checking list for appropriate inspection intervals and procedures.
  • Page 5 Angle of Redirection: The angle of redirection is the angle of the lifeline over an edge during a fall event. Install the SRL so that the angle of the two parts of the lifeline are at least 90∘, or more, but never less. The lifeline must never rise up to the edge as it may bend the lifeline in too small a radius and/ or severely abrade, or otherwise compromise, the lifeline.
  • Page 6 Drawing 2. Swing Fall Hazards Non- Leading Edge Anchorage Self-Retracting Lifeline Walking/ Working Surface Swing Fall impact after fall event Next Lower Level or Obstruction Fall Clearance: Calculate SRL-LE MRFC Anchorage: 5' Setback From Leading Edge 5' Below the Dorsal D-ring. With the anchor set back and below the D-ring, there are seven variables to consider when calculating the MRFC.
  • Page 7 Drawing 3. Calculating Minimum Required Fall Clearance SRL-LE Anchorage: 5' Minimum Setback from Leading Edge and 5' below Dorsal D-ring A- 5ft: Free fall Distance- due to Below D-ring E- 1 ft: Safety Factor- Added length to account for Anchorage other factors such as an improperly adjusted harness, actual worker height or worker weight.
  • Page 8 Drawing 4. Swing Fall Hazard: Leading Edge Condition with 5' Setback Walking/ Working Surface Foot Level Anchorage with 5' Setback from Leading Edge. Expanded Lateral Work Zone with Leading Edge Condition. See Chart 1 for instruction on how to determine a safe lateral travel distance. Using Chart 1 to Find Additional Fall Clearance: Leading Edge Conditions 2 foot increments along the X-Axis represent the 5 foot increments up the Y-Axis represent the SRL...
  • Page 9 If the user needs to expand the work zone to 12', the SRL must be anchored 15' above the Dorsal D-ring to remain in the allowed and cautionary areas. This change also indicates 4' of additional fall clearance to be added to Drawing 3. If the user cannot anchor the SRL above the Dorsal D-ring but still must expand the work zone, the SRL will need to be anchored with more than 5' of setback distance from the leading edge.
  • Page 10 B- 3ft: SRL Deceleration Distance F- 17 ft: Sub Total- Minimum Required Fall Clearance for Below D-ring Anchorage of SRL with No Swing Fall (sum of A thru E only) C-1ft: Dorsal D-ring Shift and FBH Stretch G* Additional Fall Clearance Calculation due to Combined amount of Dorsal D-ring up-shift and Swing Fall (using Chart 2) harness webbing elongation during entire fall...
  • Page 11 Key to Work Zone Areas: □=Allowable Use Area ■=Cautionary Use Area ■= Not Allowed Use Area Compatibility of Components & Connectors: ironwear equipment is designed for use with ironwear approved components and subsystems only. Non- approved components or subsystems may jeopardize compatibility of equipment and may affect complete system.
  • Page 12: Installation

    INSTALLATION: Anchorage: For users exceeding 310 lbs. (141kg), anchorage point must not be more than 5ft(1.52m) below the Dorsal D-Ring. For users exceeding 310 lbs. (141kg), up to 420 lbs. (191kg), the anchorage point must not be more than 2ft.(0.6m) below the Dorsal D-Ring and higher when connecting off to the user's left or right side. Harness Mounting: To mount the Anchor on a full body harness.
  • Page 13: Operation

    Consult your doctor if there is reason to doubt your fitness to safely absorb the shock from a fall arrest. Age and fitness seriously affect a worker's ability to withstand falls. Pregnant women or minors must not use ironwear self-retracting lifelines. Failure to heed this warning may result in serious injury or death. Operation: Prior to use, inspect the SRL-LE as described in Inspection sentence.
  • Page 14: Making Connections

    Do not use equipment that is not compatible. Ensure all connectors are fully closed and locked, ensure unintended disengagement cannot occur. ironwear connectors (snap hooks and carabiners) are designed to be used only as specified in each product’s user’s instruction.
  • Page 15: Maintenance, Servicing, And Storage

    Inspection: Before each use of this fall protection equipment carefully inspect it to assure it is in good working condition. Check for worn or damaged parts. Ensure all bolts are present and secure. Check that the lifeline is retracting properly by pulling out the line and allowing it to slowly retract. If there is any hesitation in retraction, remove the SRL-LE from service, mark "...
  • Page 16: Specifications

    2430-SSH-LE are 30 ft (9.1m), 2450-SSH-LE is 50ft (15.2m), and the 2465-SSH-LE is 65ft (19.8m), but will vary slightly with length differences in the various End Connector options. Labeling: Illustrates the SRL-LEs labeling. All labels on the SRL-LE must be present and fully legible. 2408-SSH-LE...
  • Page 17 2408D-SSH-LE 2408-ARH-LE 2408D-ARH-LE...
  • Page 18 2430-SSH-LE 2450-SSH-LE 2465-SSH-LE...
  • Page 19 Drawing 8. Anchorage Range of Leading Edge SRL-LE 1. Anchorage of SRL at Foot Level with 0' Setback from Leading Edge. 2. Anchorage of SRL at Foot Level with 5' Setback from Leading Edge. 3. Overhead Anchorage of SRL Above Dorsal D-ring with 0' Setback from Leading Edge. 4.
  • Page 20 Incorrect Use of Leading Edge SRL A. Heat Damage from Weld Spatter or Slag C. Broken Wires within Strands. B. Bird Caged D. Curled, Bent or Kinked Indicator A. The warning label is exposed at outside- immediately remove from service. B.
  • Page 21 Notes: (1) Failure of a worker to perform [before each use] inspection or failure of an inspection by a worker shall initiate the requirement for inspection by a competent person. (2) Failure of a competent person to perform inspections as specified in this Table, or failure of an inspection by the competent person shall initiate product revalidation or disposal.
  • Page 22 Inspection and Maintenance Log Serial Number: Model Number: Date Purchased: Date of First Use: Inspection Date Inspection Items Noted Corrective Action Maintenance Performed Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By:...
