INSTRUCTION MANUAL
PORTABLE HAND WASH UNIT
These instructions cover the following Burco models:
444448591
111715
Glen Dimplex UK LTD, trading as,
Glen Dimplex Heating & Ventilation
Web: www.gdhv.co.uk
Millbrook House, Grange Drive, Hedge End, Southampton, SO30 2DF.
UK Customer Service Tel: +44 [0]344 879 3588
ROI Customer Service Tel: +353 [0]1 8424833
www.burco.co.uk
© Glen Dimplex. All rights reserved. Material contained in this publication may not be reproduced in whole or in
part, without prior permission in writing of Glen Dimplex
08/54669/0 (Issue 1)
Advertisement
Table of Contents
Summary of Contents for Burco HW0110
- Page 1 INSTRUCTION MANUAL PORTABLE HAND WASH UNIT These instructions cover the following Burco models: 444448591 111715 Glen Dimplex UK LTD, trading as, Glen Dimplex Heating & Ventilation Web: www.gdhv.co.uk Millbrook House, Grange Drive, Hedge End, Southampton, SO30 2DF. UK Customer Service Tel: +44 [0]344 879 3588 ROI Customer Service Tel: +353 [0]1 8424833 www.burco.co.uk...
-
Page 2: Table Of Contents
3.0 Warnings and Precautions ..........................4 4.0 Introduction ..............................6 5.0 Warranty Period ............................... 6 6.0 Technical Data ..............................7 7.0 Burco Handwash Installation ..........................8 7.1 Installation Requirements ..........................8 7.2 European Directives ............................. 8 7.3 Before Connection To Power Supply ......................8 7.4 Location ................................ -
Page 3: About My Product
In your instruction pack you will find a duplicate data badge, which contains all the critical information above. You can peel of the backing and stick in the box below: 2.0 Scope of Delivery The contents of this package include: • Burco handwash • Instruction Booklet... -
Page 4: Warnings And Precautions
3.0 Warnings and Precautions WARNING. THIS SYMBOL MEANS THERE IS A RISK OF PERSONAL INJURY. IMPORTANT. THIS SYMBOL MEANS THERE IS A RISK OF DAMAGING THE APPLIANCE. THIS APPLIANCE MUST BE INSTALLED, COMMISSIONED AND SERVICED BY A QUALIFIED PERSON IN ACCORDANCE WITH THE NATIONAL AND LOCAL REGULATIONS IN FORCE IN THE COUNTRY OF INSTALLATION. - Page 5 THIS APPLIANCE IS NOT SUITABLE FOR OUTDOOR USE OR AN AREA WHERE WATER JET COULD BE USED. TO AVOID DAMAGE OF SUFFOCATION PLEASE REMOVE ALL PACKAGING DO NOT USE PRODUCT IF THERE IS VISIBLE SIGNS OF DAMAGE THIS APPLICANCE IS NOT INTENDED FOR USE BY PERSONS INCLUDING CHILDREN WITH REDUCED PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LACK OF EXPERIENCE OR KNOWLEDGE, UNLESS THEY HAVE BEEN GIVEN SUPERVISOR OR INSTRUCTION CONCERNING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY...
-
Page 6: Introduction
• Consequential damage arising out of any failure acceptable under warranty. • Accidental damage or misuse as detailed in these instructions. • Unauthorised alterations made to the appliance that are not made by a Burco-approved engineer. • Any damage due to incorrect installation, or build-up of scale or food debris. -
Page 7: Technical Data
6.0 Technical Data Model HW0110 & HW0110-P SKU Number 444448591 & 111715 Height (mm) 1010 Tap Height (mm) Width (mm) Depth (mm) Clean Water Capacity (L) 10.0 Number of Handwashes per fill Water Temperature (°C) Water Inlet Pressure (Bar) Weight (kg) 9.30... -
Page 8: Burco Handwash Installation
7.0 Burco Handwash Installation 7.1 Installation Requirements It is essential that this appliance is installed correctly. Installation should comply with all local electrical, and health and safety requirements. WEEE directive registration no. WEE/598W At end of unit life, dispose of appliance and any replacement parts in a safe manner, via a licenced waste handler. -
Page 9: Electrical Connection
• The mains lead should reach from the mains socket without straining the connections or creating a trip hazard. • Keep the mains lead away from any hot surfaces. • Do not place the appliance near a hot gas or electric burner. 7.5 Electrical Connection •... -
Page 10: Important Safety Instructions
• Do not operate with a damaged lead or plug, or after an appliance has malfunctioned, or has been dropped or damaged in any way. • Contact Burco for advice on examination, repair, or electrical or mechanical adjustment. • Do not dismantle any part of the unit. Responsibility cannot be accepted if this instruction is ignored. -
Page 11: Operating Instructions
8.0 Operating Instructions 444448591 111715 14. Foot pedal (SKU 111715 only) 1. Waste Bucket and lid (Inside) 2. Water Spout 3. Sink Bowl 4. Latches connecting top and bottom sections together 5. Handles 6. Water feed tube (Inside) 7. Wheels 8. -
Page 12: Filling
TURN OFF THE POWER SUPPLY AND REMOVE THE PLUG WHEN NOT IN USE, BEFORE CLEANING, AND BEFORE REPLACING ANY PARTS. 8.1 Filling Important: Always put water in the unit before switching on. 1. Lift out the bowl by the edges. Raising it off the upper section and sliding it up the water spout. When it is high enough, rotate the bowl and spout until clear of the opening of the upper section. -
Page 13: Hand Washing
8. Relatch the catches ensuring the wire retainers are situated above the cleat 9. Plug into the supply. The indicator light will illuminate to indicate power to the unit and the water will start to heat up. 10. A) For IR senor version put your foot momentarily into the black plastic moulding at the bottom of the unit. -
Page 14: Descaling & Cleaning Advice And Information
If the cut-out operates, allow the unit to cool down, carefully tilt the unit as there may be water in either the top or bottom sections, then press the red reset button situated underneath the base. 9.0 Descaling & Cleaning Advice and Information ALWAYS TURN OFF THE POWER SUPPLY AND REMOVE THE PLUG BEFORE CLEANING, ALLOW THE HAND WASH TO COOL THIS HAND WASH IS NOT WATERPROOF... -
Page 15: Descaling
This will release the lock and allow the upper pipe to be removed. Then push the lower ring into the body of the fitting and remove the fitting from the lower pipe. • Release the catches and separate upper and lower sections. Note: Never clean the unit when it is still hot - wait for it to cool completely to avoid any chance of burns. -
Page 16: Troubleshooting
10.0 Troubleshooting Fault Possible Cause Remedy Check supply socket is switched No power to the appliance Check fuse and circuit breaker Check green power indicator is The appliance does not operate illuminated Product is Empty Refill product Thermostat or element faulty Replace thermostat or element 11.0 Disposal At the end of the appliance’s useful life, it should not be disposed of with household waste. -
Page 17: Spare/Replacement Parts List
12.0 Spare/Replacement Parts List Genuine replacement Burco parts must be fitted. If generic non-Burco parts are fitted, you may prevent your appliance from operating safely and in the most efficient manner and invalidate your warranty IR Sensor Version Foot Pedal Version... -
Page 18: Wiring Diagram
13.0 Wiring Diagram 13.1 IR Sensor Version The wiring diagram for the Burco Handwash Product Number 444448591 is shown below. Wiring should be replaced by the manufacturer, service agent or similar qualified person in order to avoid a hazard. This diagram is the property of Glen Dimplex UK Ltd. and is not to be reproduced or transmitted in any... -
Page 19: Foot Pedal Version
13.2 Foot Pedal Version The wiring diagram for the Burco Handwash Product Number 111715 is shown below. Wiring should be replaced by the manufacturer, service agent or similar qualified person in order to avoid a hazard. This diagram is the property of Glen Dimplex UK Ltd. and is not to be reproduced or transmitted in any... -
Page 20: Frequently Asked Questions (Faq's)
Aftersales Team on +44 [0]344 879 3588. Q. What Warranty does my water boiler have? A. Your Burco handwash will come with a 1-year parts and labour warranty. Please see the ‘Warranty’ section on page 6 for details. -
Page 21: Warranty Information
Burco – replacement with a functionally equivalent Burco product. The Burco Warranty Period is one calendar year from the date of purchase of your Burco product, or the date of delivery of the product, if later. The Burco Warranty is conditional upon you providing the original purchase receipt as proof of purchase. -
Page 22: Terms And Conditions
You must provide to Burco or its authorised agents on request the original receipt as proof of purchase and - if required by Burco - proof of delivery. If you are unable to provide this documentation, you will be required to pay for any repair work required. -
Page 23: Notes
17.0 Notes... - Page 24 Disregarding the instructions given in this manual in its entirety and any relevant regulations, standards and code of practice will void the guarantee of this product. Glen Dimplex reserve the right to revise products, literature and guarantee terms without prior notice due to a policy of continuous improvement To speak to customer services please contact: Glen Dimplex UK LTD.
