- Page 1 ALIEN TECHNOLOGY ® ALR-H460 User Guide ALR-H460...
- Page 2 Alien Technology, the Alien logo, Nanoblock, FSA, Gen2Ready, Squiggle, the Squiggle logo, Nanoscanner and other graphics, logos, and service names used in this document are trademarks of Alien Technology, LLC and/or its affiliated companies in the U.S. and other countries. All other trademarks are the property of their respective owners. U.S. Government approval required when exporting the product described in this documentation.
-
Page 3: Table Of Contents
OTG Network Connectivity ........................8 3 RFID T ...................... 9 HAPTER EADER Starting the ALR-H460 Demo Software ....................9 Inventory Utility ..........................10 Geiger Tag Utility..........................10 Tag Access Utility ..........................11 Basic Access Tab ............................. 12 Advanced Access Tab ..........................13 Tag Mask ............................ -
Page 5: About This Manual
This manual is written for personnel responsible for installing, configuring, and maintaining the Alien ALR-H460 handheld. This manual provides information about the features of the ALR-H460, and how to install, configure, operate, and maintain it. Before you operating ALR-H460, please read through and become familiar with the contents of this manual. Introduction The Alien ALR-H460 is a high performance and expandable Android-powered handheld terminal, with data capture, data processing, and wireless communication. -
Page 6: Precautions When Using The Handheld
Careless use or repair attempts may damage the unit or stored data and will void any • warranties. Alien is not responsible for this damage. If a problem occurs, do not try to repair or disassemble the product; please contact Alien • customer service. -
Page 7: Components And Features
HAPTER NTRODUCTION Components and Features Component Identification RFID/Barcode CPU Unit Pistol Grip Cradle Wall Charger Charging/Data Cable Plus: SIM card removal tool & strap ALR-H460 U UIDE DOC. CONTROL #8102538-000 REV A... -
Page 8: Handheld Components
Press and hold to turn the device on or off Auxiliary buttons to provide additional application- Left/Right SCAN Button specific functionality for custom programs. Left FUNCTION Button Scan buttons act the same as the pistol grip in the Alien RFID Demo. ALR-H460 U UIDE DOC. CONTROL #8102538-000 REV 01... -
Page 9: Device Specifications
128 GB User Environmental Characteristics Operating Temp. -10℃ to 50℃ Storage Temp. -40℃ to 70℃ Humidity 5%RH-95%RH（non-condensing） Drop Survival 1.0 m drop, 6 sides Sealing IP64 =/-15kV air discharge, +/-6 kV conductive discharge ALR-H460 U UIDE DOC. CONTROL #8102538-000 REV A... - Page 10 WPAN Bluetooth 4.0 BLE RFID / Barcode RFID (UHF) EPC Class1 Gen2 / ISO18000-6C Barcode Scanner 2D laser scanner (SE4710) Development Environment Alien SDK Programming Language Java Development Tool Android Studio ALR-H460 U UIDE DOC. CONTROL #8102538-000 REV 01...
-
Page 11: Chapter 2 Basic Functions
Chapter 2 Basic Functions Power and Battery The ALR-H460 battery system consists of a sealed 8,000 mAh internal Lithium-Polymer battery. Battery Charging Place the handheld into the Charging Cradle. Connect the adapter with the power cable to charge the device or connect it directly to the handheld. -
Page 12: Otg Network Connectivity
SIM 1 SIM 1 OTG Network Connectivity In addition to Wi-Fi, Bluetooth and Cellular communication, the ALR-H460 also supports OTG USB- LAN adapters for direct RJ45 network connectivity for DCHP and Static IPv4 connections. To enable Ethernet on H460, 1. Plug OTG compliant USB adapter (please note a USB 2.0 Type C type connector is required) into H460 (Note: OTG is NOT supported through the charge cradle) 2. -
Page 13: Rfid Tag Reader
Chapter 3 RFID Tag Reader Starting the ALR-H460 Demo Software Start Alien Demo Software by tapping on the icon in the OS Applications group. The main screen of the Alien demo application has buttons for each of its utilities, and a menu... -
Page 14: Inventory Utility
Start Search button. The reader continues to read tags until trigger is released or stop button is clicked. Click the red Close box at the top-right corner to return to the main screen. ALR-H460 U UIDE DOC. CONTROL #8102538-000 REV 01... -
Page 15: Tag Access Utility
TID bank is read-only, and contains information about the tag’s manufacturer, model, and basic capabilities. Alien Higgs tags contain bits in the TID bank that are guaranteed to be unique from one tag to the next. The User bank may not be present in all tag types, and when present, each tag provides different amounts of available user memory. -
Page 16: Basic Access Tab
Data may be edited in the field before writing reader to only read data from that field. it to the tag. The field turns white or red, depending on the success of the write operation. ALR-H460 U UIDE DOC. CONTROL #8102538-000 REV 01... -
Page 17: Advanced Access Tab
The Mask button restricts the reader to The APwd field is where to enter the only access one tag at a time. Access Password, for accessing tag memory that may have been locked. ALR-H460 U UIDE DOC. CONTROL #8102538-000 REV A... - Page 18 Note that the tag’s EPC starts at word #2 of the EPC bank. To write data to a memory bank, select the start Word Pointer to write to, and enter the hex-formatted data, then click the pencil/write button. ALR-H460 U UIDE DOC. CONTROL #8102538-000 REV 01...
-
Page 19: Tag Mask
The ALR-H460 allows the user to specify a tag mask, which is used transparently in each of the utility screens. The current mask is displayed at the top of each screen near the Mask button. -
Page 20: Tag Mask - Scan
After scanning. select a tag from the list and click the Set button. screen – start/stop the reader with the trigger or Scan button, and all tags in range To clear the mask, click the Clear button. are displayed. ALR-H460 U UIDE DOC. CONTROL #8102538-000 REV 01... -
Page 21: Tag Mask - Custom
EPC data and click mask, along with the data. Note numeric the Set button. keyboard automatically appears to enter data. ALR-H460 U UIDE DOC. CONTROL #8102538-000 REV A... -
Page 22: Tag Mask - Presets
– all separated by commas. For instance, a presets.txt file might look like this: 1, 32, 32, 3004ABCD, pallet 1, 32, 32, E2003821, higgs9 1, 32, 32, 00001211, cargo ALR-H460 U UIDE DOC. CONTROL #8102538-000 REV 01... -
Page 23: Tag Mask - Assets
EADER Tag Mask – Assets The Assets feature of the Alien demo application shows how you might associate an EPC code, barcode, or a picture to an actual physical asset. By linking those pieces of information, you can cross-reference a barcode scan with the EPC code on that product’s RFID tag, and see a picture of the asset each time the tag is read. - Page 24 (Load or Clear click on a particular field to edit it. the image). Click the Save button to save the changes, or the Cancel button to return without saving. ALR-H460 U UIDE DOC. CONTROL #8102538-000 REV 01...
-
Page 25: Rfid Settings
RFID Settings screen from the menu button at the top of the main screen. The RFID Settings screen also has useful device, hardware module, and software version information. Access the RFID Settings screen from the top Alien Demo screen. Configure the RFID reader’s transmit power, Save stores the current settings. -
Page 26: Chapter 4 Barcode Scanner
PPENDIX Chapter 4 Barcode Scanner The ALR-H460 comes equipped with a 2D barcode scanner. The Barcode demo application is accessible from the Alien Demo main screen. Press the Scan button or pull the trigger Starting the Barcode demo app, toward to read a barcode.
