Follett 01054006 Installation Instructions

Electrical requirements
• Each unit requires a separate 15A circuit
Tools required
• #2 Phillips screwdriver
• 1/2" Wrench and 1/2" socket
Materials supplied
(16) 10-32 x1/2 pan-head screw (00902213)
(1) Right side stacking bracket (01041011)
• DO NOT TRANSPORT STACKED UNITS. Transporting stacked units can result in damage to units.
• DO NOT USE CASTERS ON STACKED UNITS. Attempting to use casters on stacked units could result in
personal injury or damage to the unit.
Installation
Before beginning installation
Follett's REF/FZR stacking kit may be used ONLY with REFs or FZRs
equipped with a STRAIGHT bottom kickplate (Fig. 1).
If your REFs or FZRs have recessed kickplates (Fig. 2), replace them
with the straight kickplates included with this kit.
Note on instructions:
TOP and BOTTOM refer to final stacked configuration
Installing levelers
1. Remove levelers from plastic bag packed inside unit.
2. Tip refrigerator back and screw levelers (Fig. 3) in all the
way to stop (they will extend 1/8" below base).
3. Adjust levelers as needed to level unit in both directions.
To access levelers, remove the lower front panel. Turn
levelers clockwise to extend levelers.
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
Performance Plus atop Performance Plus
Undercounter Refrigerator/Freezer Stacking Kit
(1)
(4)
(4)
(4)
(4)
(8)
(4)
(8)
(2)
CAUTION
recessed area
Installation Instructions
Left side stacking bracket (01041029)
Bracket,unit (00988428)
Bracket, wall (00988436)
5/16 Bolt (207476)
5/16 Nut (200457)
Flat washer (207005)
5/16 Lock washers (207475)
Extra kick plate screws (203460)
Straight kick plates (01067016)
Fig. 1 – Straight kickplate
Fig. 2 – Recessed kickplate
recessed area
Fig. 3
P/N 01054006
Order parts online:
www.follettice.com
01054022R03
