Thank you for purchasing a Cedar Table.
Please take the time to
identify all the parts prior to
assembly.
Please use Safety Eye wear and Gloves while
Assembling. Be sure to read and
follow all operating instructions for any tools
used during assembly.
Remember- NO SAW CUTTING IS REQUIRED!
Safety Points and Other Considerations
Our products are built for use based on proper
installation and normal residential use, on level
ground.
Please follow the instruction manual when
assembling your Cedar Picnic Table and retain
the manual for future maintenance purposes.
Weathering and Seasoning Characteristics
Western Red Cedar lumber, when exposed to the
elements, will turn a silvery grey color within 1
year. Seasoning splits in the surface of the wood
can also occur.
Many customers prefer the natural beauty of
cedar wood but if you prefer to limit these
characteristics from occuring, we recommend
staining or painting the wood prior to assembly.
Please do a rough sand using 100 grit sand
paper first.
-Have a regular maintenance plan to ensure all
components are screwed together tight.
In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support
Line @ 1-888-658-1658 within 30 days of the delivery of your purchase. It is our commitment to you
to courier replacement parts, free of charge, within 10 business days of this notification.
Replacement parts will not be provided free of charge after the 30 day grace period.
Toll Free 1-888-658-1658
Cedar Table - Model 24
Assembly Manual
Estimated Assembly Time for
the Cedar Table = 2 Hours
www.outdoorlivingtoday.com
Page 1
Cedar Table Dimensions:
A: Table Height = 30 3/4"
B: Table Width = 34" to 34 1/4"
C: Table Length = 66"
D: Bench Height = 17 1/2"
E: Bench Width = 11 1/4"
F: Bench Length = 66"
G: Overall Width = 64 3/4"
Important:
Once assembled, check and tighten
carriage bolts as required. Wood may
shrink over time causing the table to
loosen somewhat.
sales@outdoorlivingtoday.com
Revision #7
June 24, 2020
Advertisement
Summary of Contents for OLT Cedar Table 24
- Page 1 Cedar Table - Model 24 Revision #7 June 24, 2020 Assembly Manual Estimated Assembly Time for the Cedar Table = 2 Hours Thank you for purchasing a Cedar Table. Please take the time to identify all the parts prior to assembly.
- Page 2 Exploded View and Parts List for Cedar Table Carriage Bolts Important: When unpacking your Table from the shipping box, be sure to inventory all parts. If you discover missing or damaged pieces, please call our Toll Free Customer Support Line @ 1-888-658-1658 for fast and courteous Customer Service.
-
Page 3: Hardware Kit
CEDAR TABLE HARDWARE PACKAGE Hardware Kit (Provided) x 128 S1 - 2 1/2” Screws S2 - 1 1/4” Screws BR1 - Square Drive Bit BC1 - 5/16” Carriage Bolts NU1 - 5/16” Nuts WA2 - 5/16” Washers Y37 - 3” x 6” Reinforcement Bracket Y38 - Middle Reinforcement Bracket Tools Required (Not Provided) - Page 4 Bench Board with angled corners to the outside. Spacer Block (I) Bench Board with angled corners to the outside. Parts Start by inspecting all Bench Boards. There are 4 pieces with angle cut A - Bench Boards corners on 1 side. Lay 2 pieces down on a flat smooth surface. We suggest (1 1/2”...
- Page 5 Middle Bench Cleat Complete the 2nd Bench Assembly as per Step 2. Measure 33” from end to center point and attach Middle Bench Cleat (C) with 4 - 2 1/2” Screws. Complete attachment of all Cleat Screws. Complete 2nd Bench Assembly as previously described before moving forward. Spacer End Table Top 2 - 2 1/2”...
- Page 6 Locate 4 Legs and line up together. Determine the top end of Legs by measuring distance from the tip to the nearest pre-drilled hole. This measurement should be approximately 15 3/4”, but more importantly the greater of the two lengths indicates the top of the leg. Pre-drilled holes should line up together.
- Page 7 Align approximately with centre of table. End Leg Cleat 2 1/2” Screws Parts (Steps 7 - 8) Locate End Leg Cleats and Legs. Place End Leg Cleat beside Table Top J - End Leg Cleats Cleat, aligned with centre of table, and secure with 3 - 2 1/2” Screws. (1 1/2”...
- Page 8 Angle cuts of Cleat slope toward Bracket. Centered Middle Table Top Cleat Angle Bracket Parts Center Middle Reinforcement Bracket on Middle Table E - Middle Table Top Cleat Top Cleat as shown and attach with 2 - 1 1/4” Screws. (1 1/2”...
- Page 9 Hardware To further secure the Cleat / Angle Bracket Assembly, attach 2 - 2 1/2” Screws S1 - 2 1/2” Screws per side horizontally through the pre-drilled hole on the end of the Angle Bracket x 4 total and into the Middle Table Top Cleat. Important: Do not attach Angle Brackets until Step 13.
- Page 10 2 1/2” Screws Hardware Lift and position pre-built Benches from Step 3 onto Bench Supports S1 - 2 1/2” Screws as shown above. Screw End Bench Cleats into Bench Supports with x 12 total 3 - 2 1/2” Screws per side. Drill 1/8” pilot holes first to prevent wood from splitting.
- Page 11 Carefully flip completed Picnic Table over with your helper and place legs on firm level ground. Adjust as required. Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 11...
- Page 12 Congratulations on assembling your Cedar Table Note; The Cedar Table is shipped as an unfinished product. If exposed to the elements, the western red cedar lumber will weather to a silvery-gray color. If you plan on treating the wood, we recommend that you consult with a paint and stain dealer in your area for their recommendations.
