IMPORTANT: Record the Model No.(see carton) of your tub or shower enclosure for future reference.
READ THE INSTRUCTIONS CAREFULLY, familiarize yourself with all the parts as shown in the exploded view.
The exploded view will also provide a helpful reference when relating to the location of the various parts and how
they are mounted.
C 2011 Foremost Groups,Inc.
6241 Northwind Parkway Hobart, Indiana 46342
1-888-620-3667
www.foremostshowerdoors.com
Cove Neo-Angle Door
Installation Manual
Model No.
Advertisement
Table of Contents
Summary of Contents for Foremost Cove Neo-Angle Door
- Page 1 Cove Neo-Angle Door Installation Manual IMPORTANT: Record the Model No.(see carton) of your tub or shower enclosure for future reference. Model No. READ THE INSTRUCTIONS CAREFULLY, familiarize yourself with all the parts as shown in the exploded view. The exploded view will also provide a helpful reference when relating to the location of the various parts and how they are mounted.
- Page 2 PART LIST. TO OLS. WALL PLUG (6 pcs) SCREW 13/8" (6pcs) SCREW CAP (6pcs) SCREW (6pcs) FIXED CONNECT(2pcs) FIXED PIVOT(2pcs) FIXED CONNECT SCREW(8pcs) GASKET(16 pcs) (1 pcs) (1 pcs) HANDLE DOOR MAGNETIC PLASTIC DRILL MEASURE TAPE SILICONE RUBBER MALLET 1/8" 1/4"...
- Page 3 STEP 1 STEP 2 Mark the holes position Drill holes. When attaching your door to Fiberglass or Acrylic you must use a 1/8" drill bit and NO WALL ANCHORS. LEVEL PENCI L DRI LL STEP 3 STEP 4 Put wall anchor Fix wall jamb on the wall by screw SCREW DRI VERS...
- Page 4 STEP 5 STEP 6 Install Fixed panel to wall jamb Connect two fixed panels with fasten screws STEP 7 STEP 8 Put part on glass door Screw part...
- Page 5 STEP 9 STEP 10 Install towel bar Install magnet vinyl ,Side vinyl and bottom vinyl STEP 11 STEP 12 Connect wall jamb with fixed panel by screw ,then put cap CAULK ALL SIDES CAULK ALL SIDES...
