- Page 1 USER MANUAL ETHERNET GATEWAY...
-
Page 3: How To Use This Manual
This user manual was compiled to offer a guide on the installation of SIRIO. For the installation of the devices, set-up of the opening and other operations not described herein, refer to the installation and configuration manuals, available in the download area of ISEO Zero1’s website, at: www.iseozero1.com The installation, initial set-up and changes to the setting, require the intervention of qualified staff, properly trained by ISEO Zero1. - Page 4 SIRIO Ethernet Gateway Ethernet connection Lockbus connection http://gamma.iseozero1.com/wp- content/uploads/2015/06/Ethernet- Gateway_00.pdf Sezione...
-
Page 5: Set Ip Address
SIRIO Set IP address The default IP address of an Ethernet Gateway (E.G.) is 192.168.1.1. To change the IP address you have to do: 1) set your network board IP address as 192.168.1.xx (2..254); 2) connect directly with a network cable the E.G. to your laptop; 3) to be able to set the parameters, put a jumper here 4) open the E.G. - Page 6 SIRIO Set LOCKBUS 1) From the E.G. user interface select PORT 0 (Locbus); 2) Set the Baud Rate as 57600; 3) Set the option ‘Make these the default settings’; 4) Save the configuration with SUBMIT button. Remove the jumper plugged before and the device is ready to use. Sezione...
- Page 7 Iseo Serrature s.p.a. Iseo Serrature s.p.a. Via San Girolamo 13 Via Don Fasola 4 25055 Pisogne (BS) 22069 Rovellasca (CO) Italy Italy Tel +39 0364 8821 Tel +39 02 96740420 Fax +39 0364 882263 Fax +39 02 96740309 iseo@iseo.com www.iseozero1.it...
