- Page 2 F2 as of the release date of this edition. Trademarks CHAUVET, the Chauvet logo and F2 are registered trademarks or trademarks of Chauvet & Sons, LLC (d/ b/a Chauvet and Chauvet Lighting) in the United States and other countries. Other company and product names and logos referred to herein may be trademarks of their respective companies.
-
Page 3: Table Of Contents
Mounting with Dual Function Rig Bar (Stacking) ......... Removing the Feet .................. Flat Wall Installation ................Spacers (Flat Wall Installation) ..............5. Joining Each F2 (Creating a Modular Design)......Vertically Joining the Panels..............Vertical Panel Connection ............... Horizontally Joining the Panels ............ - Page 4 Table of Contents 6. Connecting (Cabling) Each F2 ..........Testing Signal and Power Connections..........Using the F2 Test Button..............Connecting Power and Signal Cables ..........Connecting the Signal Between Joined Panels ........Custom Resolutions................. Signal Chain Rectangles ................. Connecting the Power Between Joined Panels........
-
Page 5: Before You Begin
Important installation or configuration information. The product may not function correctly if this information is not used. Useful information. The term “DMX” used throughout this manual refers to the USITT DMX512-A digital data transmission protocol. F2 User Manual Rev. 1 Page 1 of 33... -
Page 6: Safety Notes
LEDs, contributing to shorter lifespans if always used at full intensity. The average LED lifespan is 40,000 to 50,000 hours. To extend LED lifespan, maintain proper ventilation around the product, and limit the overall intensity. Page 2 of 33 F2 User Manual Rev. 1... -
Page 7: Introduction
Product Description The F2 is a 2.9 mm pixel pitch LED video panel equipped with a high contrast 1,500 NITS and a refresh rate of 3,840 Hz for crisp, high quality, imagery. This high-performance video panel is ideal for corporate events with text, high-res IMAG and any space with a shorter viewing distance. -
Page 8: Product Overview
Alignment Holes Female Speego Connections Alignment Magnets (x4) ® ® Seetronic Seetronic Alignment ® ® Powerkon Powerkon Conicals Alignment Alignment ® ® Seetronic Etherkon Bolts (x4) Magnets Signal Through Ports (x4) Page 4 of 33 F2 User Manual Rev. 1... -
Page 9: Pixels Per Panel
Introduction Pixels per Panel LED Module Each pixel is 1 tri-color LED. The following table provides the pixels per panel in each F2. For detailed specifications, refer to the Technical Specifications table at the end of this User Manual. Parameter... - Page 10 19.68 in 12 mm 500 mm 18.66 in 474 mm 17.48 in 444 mm 39.37 in 37.17 in 1000 mm 944 mm 14.21 in 361 mm 4 mm 5 mm 5.8 mm Page 6 of 33 F2 User Manual Rev. 1...
-
Page 11: Setup
3. Setup AC Power The F2 has an auto-ranging power supply and it can work with an input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 12: Mounting
The F2 can be assembled to provide any number of modular designs. The panels on the top can be securely hung from a truss or other stable surface. Always hang in a safe position with adequate space for ventilation, configuration, and maintenance. -
Page 13: Drb-F50Cm Dual Function Rig Bar Dimensions
DRB-F100CM Dual Function Rig Bar Dimensions Sold Separately 6.65 in 4.72 in 169 mm 120 mm 5.2 in 39.35 in 132 mm 999.6 mm 39.55 in 1,007.4 mm 2.36 in 60 mm F2 User Manual Rev. 1 Page 9 of 33... -
Page 14: Mounting With Dual Function Rig Bar (Hanging)
Connection) only after ensuring the alignment is correct. To detach the Rig Bar from the F2, reverse the previous steps. Tilt the panels away from each other to safely release the magnetic attachments. The alignment magnets on the F2 and Dual Function Rig Bar are designed to temporarily hold the weight of the panel to allow the user to properly align and tighten the panel into place. -
Page 15: Truss Installation
All Rig Bars in a panel assembly must be mounted individually to the mounting point! Adjacent Rig Bars will NOT support the attached weight! WARNING: This product should only be used by competent and qualified persons. F2 User Manual Rev. 1 Page 11 of 33... -
Page 16: Mounting With Dual Function Rig Bar (Stacking)
Do not release panel until the hanging hardware has been fully secured. Removing the Feet To remove the feet (alignment bolts) from the F2, twist them counter-clockwise with a 5 mm wrench until they come loose. 5 mm... -
Page 17: Flat Wall Installation
4 columns + 1 = 5 steel struts The illustrations above are examples only. Please refer to all applicable local codes and regulations for the proper installation of the product. F2 User Manual Rev. 1 Page 13 of 33... -
Page 18: Spacers (Flat Wall Installation)
When mounting to a flat wall, spacers greater than 5 mm thick must be used at each mounting point, between the panels and the struts, as in the diagram below. Spacer (>5 mm) Module M10 Bolt Steel Strut Page 14 of 33 F2 User Manual Rev. 1... -
Page 19: Joining Each F2 (Creating A Modular Design)
Vertically Joining the Panels Each F2 can be easily joined vertically to a truss using an optional rig bar and the 2 female Speego connections located at the top corners of each panel. Use the male Speego connections at the bottom of each panel to connect additional panels. -
Page 20: Vertical Panel Connection
Joining Each F2 (Creating a Modular Design) Vertical Panel Connection Use the following instructions to join panels vertically: Line up the alignment conicals at the top of each panel, and the alignment magnets at the top and bottom of each panel. -
Page 21: Horizontally Joining The Panels
Joining Each F2 (Creating a Modular Design) Horizontally Joining the Panels Each F2 can be easily joined horizontally using the Speego connections on the inside, upper and lower left sides of each panel. Horizontal Panel Connection Use the following instructions to join panels horizontally: Align each of the panels’... -
Page 22: Connecting (Cabling) Each F2
Using the F2 Test Button Each F2 has a Test button, used to ensure all LEDs are functional. Use the Test button on each panel to perform a self-test. If self-testing, you must perform the test individually for each F2. You do not need to connect to a signal or use software. -
Page 23: Connecting Power And Signal Cables
The following diagram is a recommended suggestion for simple signal connections between panels. Video Signal Signal Jumper Cable Etherkon connection to the first F2 in the series VIP Drive 43Nova 2 VIP Drive 83R Nova Video Signal Cable in from... -
Page 24: Signal Chain Rectangles
Each port of one of the above mentioned VIP Drive products can connect to 11 F2 panels. If more than 11 panels are used, more than 1 output port from the VIP Drive will be required. -
Page 25: Connecting The Power Between Joined Panels
The connections continue until all panels are connected. Connect power between the panels using the same procedure as the signal only using the Power Input and Power Output connectors. You must adhere to the power-linking specifications for each F2 model. Refer to the... -
Page 26: Led Module Care And Replacement
A and B Modules The F2 has 2 types of modules, designed to only plug in to the Service Module from one direction. Check the orientation of the LED LOT # label to determine whether the module is an A type (top half, connector down) or a B type (bottom half, connector up). -
Page 27: F2 Led Module Removal
Carefully tilt the module to pull it through to the rear, or have someone on the other side take it. Reverse the steps to install the replacement module. WARNING! The magnets on the modules are very powerful! Keep fingers clear when installing. F2 User Manual Rev. 1 Page 23 of 33... -
Page 28: Removing And Replacing The Led Masks
2x8 = 16 Masks per Module Rear Side - Clips (Shiny Surface) To replace one of the LED masks on an F2 LED module, follow the instructions below: Remove the module from the F2 (see F2 LED Module Removal). Gently lift the edges of the mask with a thin prying tool. -
Page 29: F2 Serviceability
Module The F2 service module can be accessed and serviced from either the front of the panel or the rear of the panel at any time, so panels can be serviced when access to either the front or the rear is restricted or impossible. - Page 30 F2 Serviceability To access the F2 service module from the rear of the panel, remove the 4 screws indicated in the diagram below. Use caution when removing these screws, as the cover of the service module will be detached from the panel frame. All components in the service module are attached to the cover.
-
Page 31: Typical F2 Installation (Hanging)
Open and examine the F2 road case to make sure you have received all products and accessories and that each one is in good condition. Step 2 Apply power and run the self-test for each F2 to ensure all LEDs and inside connections in each panel are working (optional). Step 3 Create a stable mounting surface (e.g., truss or other stable surface) for F2 mounting. -
Page 32: Operation
10. Operation Additional Hardware and Software In addition to the panels, you will need other hardware and software to design, build, and operate your F2 video wall system. The following table summarizes these additional items—some are required and others are optional. -
Page 33: Rotating The Video Panel Orientation
Operation Rotating the Video Panel Orientation When mounting F2 panels sideways (90° or 270°), their orientation must be set in the mapping software. To do this through NovaLCT: 1. Connect the VIP Drive being used to a computer with NovaLCT installed. - Page 34 The size of the Receiving Card will be changed accordingly from 168x336 to 336x168. If using the software to map a panel assembly, these values must be used as the Receiving Card parameters of the NovaLCT software. Page 30 of 33 F2 User Manual Rev. 1...
-
Page 35: Technical Information
As a rule, clean this product at least twice a month. Dust build-up reduces light output performance and can cause overheating. This can lead to reduced light source life and increased mechanical wear. To clean an F2, follow the recommendations below: 1. Unplug the panel from power. -
Page 36: Technical Specifications
-4 °F to 113 °F (-20 °C to 45 °C) Item Name (4-Pack Road Case) F2X4 Item Code (4-Pack Road Case) 23091599 UPC Number (4-Pack Road Case) 781462219475 UL 60950-1 CSA C22.2 No. 60950-1 E113093-1110 E113093-1125 Page 32 of 33 F2 User Manual Rev. 1... -
Page 37: Contact Us
Voice: +52 (728) 690-2010 Visit the applicable website above to verify our contact information and instructions to request support. Outside the U.S., U.K., Ireland, Benelux, France, Germany, or Mexico, contact the dealer of record. F2 User Manual Rev. 1 Page 33 of 33...
