TimeTec Epicam E16S Quick Start Manual

w w w . e p i c a m e r a . c o m
Epicam E16S
Quick Start Guide
©
2018 Timetec Cloud Sdn Bhd. All rights reserved • 042018
PRODUCT APPEARANCE
Please refer to the following pictures for
more details regarding each port.
Micro SD
card slot
PIR (Sense IR
NOTE: To reset, long press for 8 seconds until light off; For WPS (WiFi Protected Setup), a quick press will suffice.
Smart Camera
Microphone
Ethernet port
(Wireless connection
Indicator light
mode is available as well)
IR LED
Reset/WPS
button
(WiFi Protected
Setup)
ray, trigger
alarm)
CAMERA & ACCESSORIES
1
2
Please refer to the following table for more details about indicator light status.
INDICATOR LIGHT STATUS
Red light stably on
Digital
Green light slow flashing
input/output
(Refer connection
mode)
Green light quick flashing
Power port
Green light stably on
Speaker
Red and green lights flash alternately
Red light slow flashing
Red light quick flashing
1
Device ×1
2
Quick Start Guide ×1
3
Screw Packet ×1
4
Power Adapter ×1
5
Installation Position Map x 1
5
3
4
DEVICE STATUS
Booting
Booting completed, awaiting WiFi
config, enter smart config status;
WiFi smart config in progress,
including WPS (WiFi Protected
Setup), management frame, etc.
WiFi connection succeeded,
operating normally.
Device upgrade
Network disconnected
Device fail to boot up; alarm or SD
card does not work
