Summary of Contents for Buffalo filter BOWA
- Page 1 Operator’s Manual BOWA- electronic Smoke Evacuation System with RFID Technology...
-
Page 2: Limited Warranty
Limited Warranty For a period of one (1) year following the date of delivery BOWA electronic warrants the BOWA Smoke Evacuation System against any defects in material or workmanship. BOWA electronic will repair or replace (at BOWA electronic’s option) the same without charge, provided that routine maintenance as specified in this manual has been performed using replacement parts approved by BOWA. - Page 3 Table of Contents Page 1.0 Introduction....................1 2.0 Inspection...................... 1 3.0 Operational Information................1 4.0 Warnings and Cautions................1- 2 5.0 Operating Instructions..................2-4 • Key Pad Diagram • Power ON/ OFF • Motor ON/ OFF • Suction Control • TURBO Mode •...
- Page 4 The BOWA Smoke Evacuation System has been designed with a high suction, high flow rate centrifugal action pump. The ultra quiet motor is used to draw the smoke plume from the surgical site through the vacuum tubing/hose into the BOWA filter where the surgical smoke is processed by 4 stages of filtration.
- Page 5 • Attempting to use any other filter or accessory not supplied by BOWA may cause damage and/or cause the system to be inoperable and will void the warranty.
-
Page 6: Power On/Off
B OWA E L E C T R ON I C B OWA E L E C T R ON I C BOWA F I L T E R HR : MN T i me R e ma i n i n g... -
Page 7: Motor On/Off
TURBO button again. FILTER LIFE REMAINING The exact number of hours and minutes remaining on the BOWA filter (in use) are displayed on the LCD screen. When the filter’s life is consumed, time remaining will indicate that there are 0 hours and 0 minutes remaining. This line will continually flash. When the filter life reaches this point, a new filter with time remaining should be inserted;... -
Page 8: Setting The Default Language
SERVICE When a service message appears, please c ontact BOWA Customer Service for instructions. Below are some examples of service screens that may appear. If this screen appears the system may be in need of If this screen appears there may be a problem with your service for the motor. - Page 9 (not dripping) with a mild detergent or surface disinfectant. PERIODIC INSPECTION The BOWA Smoke Evacuation System should be visually inspected at least once a year. This inspection should include: • Inspecting for damage to power cord •...
- Page 10 The following table outlines the specifications for the BOWA Smoke Evacuation System. Tubing 7/8” (22 mm) Actual Flow Rates: Normal: 25 CFM (708 lpm) Maximum Flow Setting Turbo: 35 CFM (991 lpm) Variable Flow Control 1 HP (0.75 kw) Continuous...
-
Page 11: Confidential Information
Customer Service before returning the system. Step 4: If you have the original packing for your BOWA Smoke Evacuation System, use it to properly return your unit. If you do not have the original packing material, ask Customer Service for advice on how to pack the unit for return shipment. - Page 12 BOWA will replace without charge any filter systems proved to have defects within one (1) year of the date of delivery for and provided BOWA has been given the opportunity to inspect the system alleged to be defective and the installation or use thereof.
