- Page 1 SALT ELECTROLYSIS SYSTEM integrated pH/ORP controller D-40 D-10+ D-18+ D-25+ D-40+ OPERATION MANUAL...
-
Page 3: Table Of Contents
INDEX 1.- TECHNICAL SPECIFICATIONS …………………….………… 1.1. Dimensions…..……………………………..…………….. 1.2. Power supply specifications ……………………………. 1.3. Electrolysis cell specifications ………………………….. 1.4. pH controller specifications ………..…………………... 1.5. ORP controller specifications ………………………...… 1.6. pH/ORP electrode specifications …….………………… 2.- INSTALLATION INSTRUCTIONS …………………………….. 2.1. Power supply …………………………………………….. 2.2. - Page 4 7.- PRACTICAL ADVICES ………….…………………………… 8.- TROUBLESHOOTING …………….…………………………… 9.- WARRANTY ….…………….…………………………….……...
- Page 5 Dear customer: Thank you very much for purchasing our SALT ELECTROLYSIS SYSTEM for the treatment of swimming pool water. IDEGIS SALT ELECTROLYSIS SYSTEMS have been designed and manufactured taking into account the already existing specific necessities in the treatment of the swimming pool water.
-
Page 6: Technical Specifications
1.- TECHNICAL SPECIFICATIONS 1.1. DIMENSIONS 1.2. POWER SUPPLY SPECIFICATIONS Control: microprocessor Self-cleaning: electronic polarity reversal D-10+ D-18+ D-25+ D-40(+) Input (ac) 220 Vac / 50-60 Hz H07V/K Cable (ac) cable 3x1.0 mm 0.8 A 1.4 A 2.0 A 2.4 A Consumption (ac) Fuse 2 A (6x32 mm) -
Page 7: Electrolysis Cell Specifications
1.3. ELECTROLYSIS CELL SPECIFICATIONS Recommended salinity: 4-6 g/l (4000 – 6000 ppm) Electrodes: Titanium with SELF-CLEANING coating Max. recommended pressure: 1 Kg/cm [D-10+ ... D-25+] 3 Kg/cm [D-40(+)] Temperature: less than 40ºC Material: methacrylate-based polymer [D-10+ ... D-25+] polypropylene [D-40(+)] D-10+ D-18+ D-25+... -
Page 8: Installation Instructions
Beware of corrosive atmosphere formation due to pH decreasing solutions (specially, those ones based on hydrochloric acid "HCl". Do not install the IDEGIS SYSTEM near to any stores of these chemicals. We strongly recommend the use of chemicals based on sodium bisulphate or diluted sulphuric acid. -
Page 10: Electrolysis Cell
2.2. ELECTROLYSIS CELL The electrolysis cell is made of a transparent polymer in whose interior the electrodes are placed. The electrolysis cell must be always installed indoors and after the pool filter, and after any heating equipment that may be present (heat pumps, oil boilers, etc.). The installation of the cell should allow easy access to the installed electrodes by the user. - Page 11 • WARNING : if the in-out valves of the electrolysis cell are closed simultaneously, the flow detector will not work correctly, with the consequent risk of cell breakdown. Although this situation is extremely unusual, it can be easily avoided once the equipment has been installed, by locking at opened position the return valve to the swimming pool, so it cannot accidentally be manipulated.
-
Page 12: Ph/Orp Electrodes
2.3. PH/ORP ELECTRODES Install the pH electrode holders in the circuit through ½” saddles (not included with the equipment). Insert the electrodes into their corresponding holders. Next, tighten the holder until the electrode is properly fixed The electrodes must be installed in the holder so that it is guaranteed that the sensor located in their ends are always submerged in the water circulating... - Page 13 IMPORTANT: due to relatively high current intensity circulating do not modify or cut either the length or section of the supplied cables without making a previous consultation to an authorized IDEGIS distributor. The connection cable cell-power supply must necessarily be of the section recommended in this...
-
Page 14: System Description
3.- SYSTEM DESCRIPTION When an IDEGIS SALT ELECTROLYSIS SYSTEM is installed, a quantity of salt is dissolved into the swimming pool water. This salty water then passes through the electrolysis cell that is located in the plant room. When a weak electrical current is passed through the plates inside the electrolysis cell, chlorine is produced. -
Page 15: Power Supply Description
3.1. POWER SUPPLY DESCRIPTION ELECTROLYSIS SYSTEM Total (g): grams of chlorine generated since the connection of the unit (total count is reseted at 0:00 am). Set-point: shows the programmed chlorine production in grams/hour. Flow (g/h): shows the chlorine production expressed in grams of chlorine/hour. - Page 16 System Info: shows different system information and warnings Run key: press this key to RUN the selected program. Selection keys: allow to select the different configuration parameters of the system. Program key: press this key to access to program menus. Stop key: press this key to STOP the program.
- Page 17 CONTROL LINK: indicates if ORP controller is linked to the electrolysis control board. Indication LED of anomalous ORP value: alarm LEDs are activated automatically when the readings are outside the prefixed range (650-850 mV). For security reasons, the controller turns-off the control output when upper limit (850 mV) is exceeded.
-
Page 18: Remote Control
3.2. REMOTE CONTROL IDEGIS systems have a series of I/O terminals that allow the remote control of the system. These terminals may be accessed in the system mainboard (see figure below). TERMINAL DESCRIPTION OUTPUT CURRENT OUTPUT VOLTAGE ALARM Range: 0-60 mV Range: ±... -
Page 19: Electrolysis Cell Description
3.3. ELECTROLYSIS CELL DESCRIPTION D-40(+) D-10+ ... D-25+ References Description Model D-10+ D-18+ D-25+ D-40(+) Electrical contacts protector R-015-07 Closing nut R-015-06 Electrode holder R-015-05 Electrodes R-121 R-122 R-123 R-114 EPDM cell gasket R-015-08 Cell R-010 R-144... -
Page 20: Start-Up
4.- START-UP Check that the filter is 100% clean, and ensure that the swimming pool and the installation do not contain copper, iron or algae. Ensure that any heating equipment on the pool is suitable for use in salt water. Ensure that the swimming pool water is balanced. -
Page 21: Operation
5.1. ELECTROLYSIS SYSTEM 5.1.1. INITIALIZATION When initiating the IDEGIS system at first time, it will be necessary to program some system parameters following the flow-sheet shown below IMPORTANT: ORP control must be always selected (“YES”) if you want to run the IDEGIS... - Page 22 5.1.2. PROGRAMMING System configuration parameters may be modified following the next flow-sheet. IMPORTANT: ORP control must be always selected (“YES”) if you want to run the IDEGIS system in AUTOMATIC mode.
- Page 23 5.1.3. RUN ORP CONTROL NOT ACTIVATED (MANUAL MODE)
- Page 24 ORP CONTROL ACTIVATED (AUTOMATIC MODE)
-
Page 25: Integrated Ph Controller
Only pH values in the range 7.0 – 7.8 will be able to be input. 5.2.2. SELECTION OF THE PRODUCT TO DOSE (ACID or ALKALI) The IDEGIS SALT ELECTROLYSIS SYSTEM with INTEGRATED pH/ORP CONTROL has been factory set so that it can be used in the majority of existing pools without the need to modify the internal settings. -
Page 26: Integrated Orp Controller
The integrated ORP controller is supplied with the following default programming parameters. SET POINT = 750 mV IMPORTANT: 1. Before connecting the IDEGIS SYSTEM, check pH, alkalinity, stabiliser (cyanuric acid) and free chlorine levels are inside the recommended ranges: pH: 7.2 –7.6. - Page 27 PARAMETER Free chlorine + mV - mV Combined chlorine - mV + mV - mV + mV Stabiliser (isocyanuric acid)) - mV + mV TDS (total dissolved solids) - mV + mV Temperature + mV - mV 7. In case it was necessary to add stabiliser to the water, it should be taken into account that its employment in concentrations higher than 30-40 ppm produces a very significant decrease of the ORP values (mV) obtained for a given concentration of free chlorine.
- Page 28 5.3.1. SETPOINT PROGRAMMING o MANUAL MODE To fix the set point in a MANUAL way, maintain pressed the key “SET” (the superior display will show “- - -“ until it is heard a “beep”, then release the key. The first digit of the red display will light.
-
Page 29: Alarm And System Messages
5.4. ALARMS AND SYSTEM MESSAGES ALARM DIAGNOSTIC CONTROL SIGNAL STATUS Alarm REMOTE Remote stop has been activated STOP Stop Alarm -- ALARM -- No water flow or insufficient flow IMPORTANT: in-out valves of the NO FLOW electrolysis cell must be always Stop open Alarm... - Page 30 Alarm ORP control activated from the Stop system configuration menu ORP control? >YES ORP control Alarm System halted by the ORP Stop controller ORP control? >YES ORP control ALARM In all the previous cases, the ALARM led in the control panel will not blink The integrated pH controller has two ALARM LEDs, which are illuminated whenever a pH value outside the range 6.5 –...
-
Page 31: Maintenance
6.- MAINTENANCE 6.1. CHLORINE LEVEL CONTROL IN THE POOL In periods of warm weather, it may be necessary to extend the daily operation time of the salt chlorinator, since the generated chlorine decomposes more quickly in elevated water temperatures and with the increase of the solar radiation. Chlorine demand (the amount of chlorine required) also increases with the amount of swimmers using the pool (deriving in greater levels of organic matter). -
Page 32: Maintenance Of The Electrolysis Cell
– the electrodes do have a finite life. In order to optimise electrode lifetime, please consider the following: o Although all IDEGIS salt electrolysis units are SELF-CLEANING, a prolonged operation of the system at pH values over 7.6 in waters of high hardness can produce scale formation on the surface of the electrodes. -
Page 33: Ph Electrode Calibration
6.4. pH-ELECTRODE CALIBRATION The recalibration frequency of the unit will have to be determined in each particular application. However, we recommend carrying out it at least once a month during the period of use of the swimming pool. The integrated pH-controller has two calibration modes of the pH-electrode: “FAST”... - Page 34 6.4.2. “STANDARD MODE” “STANDARD” MODE allows the precise calibration of the pH-electrode using two calibration solutions of pH 7.0 and 4.0, however this method requires that the pH-electrode is removed from the installation. PROCEDURE: IMPORTANT: before closing the by-pass valves, press “STOP” in the Control Panel of the unit Extract the pH-electrode from the holder and wash it with tap water.
-
Page 35: Orp Electrode Calibration
NOTES ON CALIBRATION: If the calibration process is interrupted for whatever reason, the pH- controller will automatically leave the calibration mode if the intervention of the user is not detected in a few seconds. In this case, “E1” indication in green display will appear. -
Page 36: Maintenance Of The Ph/Orp Electrodes
Press “CAL” key for a few seconds, until the green display blinks and indicates “470”. Shake the electrode smoothly so that any water drops that may be adhered to the plastic body are removed and introduce it to the calibration solution (470 mV). Shake smoothly for a few seconds and press “CAL”... - Page 37 7.- PRACTICAL ADVICES PROBLEM DIAGNOSTIC SOLUTION Green water, slippery walls, green Presence of algae due to Make a shock treatment. depositions on walls… low free chlorine levels Increase free chlorine level up to 10 ppm and add flocculant Adjust pH to 7.2 - 7.6 Filter continuously during 8 hours.
- Page 38 Check electrodes “0” Chlorine Verify connections between power supply and the electrolysis cell <<< IDEGIS >>> Check salt concentration Info The power supply is not turned on Verify the system is properly connected to 220 V/50-60 Hz in the command box of the...
- Page 39 The controller always shows a high Cable connection to the Clean the contacts or replace value, or the reading is unstable. electrode is damaged the cable. The electrode has an air Hold the electrode in vertical bubble in the membrane area. position, with the tip down.
- Page 40 In the case of needing the substitution of the electrode package under Functional Warranty Conditions, IDEGIS will charge to the user the proportional part of the operating time passed (lower than 8.000 hours since installation) until the notification of the discrepancy.
- Page 41 NOTES...
- Page 42 NOTES...
- Page 44 Made in Spain by: Printed in Spain I.D. ELECTROQUIMICA, S.L. Polig. Ind. Atalayas, c./ Dracma R-19 E-03114 ALICANTE. Spain. Tel. (+34) 965101979 Fax (+34) 965107293 e.mail: info@idegis.es...
