IOM 002
February 2018
INSTALLATION, OPERATING, & MAINTENANCE INSTRUCTIONS
Read these entire instructions carefully before installation or servicing.
GENERAL INFORMATION
Safe and efficient operation of industrial installations
requires not only complete knowledge of the
engineering and functioning of all machinery and
equipment but their continuous proper maintenance
as well. Improper operation or maintenance of one
single valve may affect the whole operation. To help
you achieve trouble-free valve performance, general
information is provided here for the optimum operation
and maintenance of your Quadrant steel ball valves
with floating ball design.
DESIGN
All Quadrant F1 series unibody-floating ball valves
are a one-piece body design. The valves are non-
directional and can be installed with either end
upstream.
These
valves
manufactured in accordance with ASME B16.34 and
API 608. Valves have flanges drilled and faced in
accordance with ANSI B16.5.
1. HANDLING VALVES BEFORE
MOUNTING/STORAGE
1.1 Prior to shipment, blind covers are placed on the
inlet and outlet of each Quadrant valve for
protection from mechanical damage as well as
for prevention of intrusion of dust and other
foreign objects into the valve bore during transit.
Do not remove these end protectors before
valves are mounted.
1.2 For valve storage, a dust free place is
recommended. Care should always be taken to
avoid damaging stems. Placing valves directly
3711 Melancon Road
Brou ssard, Lou isiana USA 70518
337-837-8650 ; 877-625-5858
F1 Unibody Flanged-End Ball Valve IOM for:
1/2"- 6" F1-CS & F1–SS – ANSI CLASS 150 & 300
are
designed
and
VALVE SOLUTIONS - Quadrant
on the ground or concrete floor is not
recommended. Under no circumstances should
valves be stored outdoors. Valves are shipped
in the open position to protect the ball surface.
1.3 When moving with a crane, valves should be
positively rigged around valve bodies and end
flanges. In no case should the crane wire be in
direct contact with valve stems or operational
gears.
1.4 The valve must never be stored in the partially
open position. The soft seat can be damaged if
the valve is left partially open for long periods. It
is recommended that the valve be stored in the
full open position to protect the ball and seats.
WARNING
SAFETY FIRST! FOR YOUR SAFETY,
TAKE THE FOLLOWING
PRECAUTIONS BEFORE REMOVING
THE VALVE ASSEMBLY FROM THE
LINE OR BEFORE ANY
DISASSEMBLY.
WHAT'S IN THE LINE?
Be sure you know what fluid is in the line. If there
is any doubt, double check with the proper
supervisor.
NOTICE
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quadrant F1 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Forum Quadrant F1 Series

  • Page 1 DESIGN is recommended that the valve be stored in the full open position to protect the ball and seats. All Quadrant F1 series unibody-floating ball valves are a one-piece body design. The valves are non- WARNING directional and can be installed with either end upstream.

  • Page 2: Valve Installation

    ends sealed, but during the transit, foreign material may be introduced into the bore. ARE YOU PROTECTED? 2.4 Inspect gasket contact faces on valve flanges for Wear any protective clothing and equipment any scratches or defects. Correct such normally required to avoid injury from the scratches or defects with sand paper.

  • Page 3: Disassembly Procedure

    3.4 When leakage is detected from body-insert joint, CAUTION: Ball valves generally torque the insert [2] to the specified torque in recommended for throttling service, where the fluid table 1. Refer to Sketch 1 flow or the edge of the ball bore may damage or deform plastic ball seats and cause leakage when they are fully closed.

  • Page 4: Inspection And Cleaning

    NOTE: Care should be taken when disassembling not to scratch the stem, ball, or the body interior. 5.15 Remove the body seal [7] from the insert [2]. All valve components should be kept isolated for Refer to Sketch 1 easier examination and reassembly. 5.16 Remove the stem [4] by pushing stem into the 5.6 Before disassembly, remove and collect residual body cavity.

  • Page 5: Test And Inspection

    diameters together then install the packing nut 7.3 Apply a thin layer of lubricant to the seat pocket in [12]. Tighten the packing nut evenly to the both the body [1] and insert [2]. Refer to Sketch 1 torque specified in table 2. Refer to Sketch 1 and Table 2.
  • Page 6 Table 1) Insert Torque (Ft-Lbs.) according to Valve Size 6” Valve Size 1/2” 3/4” 1” 1 1/2” 2” 3” 4" Torque 1179 1445 (Ft.-Lbs.) Table 2) Gland Bolting Torque Minimum Gland Valve Bolting Torque Size (In.-Lbs.) ¾” – 1” 1 ½” – 2” 2 ½”...
  • Page 7 Assembly Illustrations Sketch 1...
  • Page 8 Sketch 2...
  • Page 9 Quadrant Valve & Actuator – Valve Solution is a wholly owned subsidiary of Forum Energy Technologies. Quadrant ® is a registered trademark of FORUM ENERGY TECHNOLOGIES 3711 Melancon Road, Broussard, Louisiana 70518 (337) 837-8650 • (877) 625-5858 Forumvs.sales @f-e-t.com Contact your local Quadrant ® representative for more information about other Quadrant ® Brand flow control products, or learn more about other fine Quadrant ®...
