Prince PT2010 Owner's Manual

Table tennis table
Hide thumbs

Advertisement

Quick Links

Download this manual
USE THIS MANUAL ONLY!
A DIFFERENT MANUAL IS IN THE BOX,
DISCARD THE OTHER.
Escalade® Sports products may be manufactured and/or licensed under the following patents.
6120397, 5816957, 5769744, 5119741, 4911085, 4717157, D460140, D420563, 8414431
Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
O W N E R ' S M A N U A L
TABLE TENNIS TABLE
MODEL NO.
PT2010
2014 Escalade Sports
PT2010-00

Advertisement

loading
Need help?

Need help?

Do you have a question about the PT2010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Prince PT2010

Summary of Contents for Prince PT2010

  • Page 1 TABLE TENNIS TABLE A DIFFERENT MANUAL IS IN THE BOX, MODEL NO. DISCARD THE OTHER. PT2010 PT2010-00 Escalade® Sports products may be manufactured and/or licensed under the following patents. 6120397, 5816957, 5769744, 5119741, 4911085, 4717157, D460140, D420563, 8414431 2014 Escalade Sports...

  • Page 2: P R E - A S S E M B L Y T I P S

    P R E - A S S E M B L Y T I P S 1. Read this manual carefully before starting assembly. Read each step completely before beginning each step. 2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons before assembling or ordering parts. 3.

  • Page 3: Parts Required

    1. Attach Caster Wheels (P4 & P5) to T-Legs (P2). Slide a Caster PARTS REQUIRED: TOOLS REQUIRED: 2 - (P2) T-Leg 1- Crescent Wrench Wheel with Lock (P4) through upright (P2) and secure it with Cap 2 - (P4) Caster with lock 1- Channel Lock Plyers Nut (H3) as shown.
  • Page 4 PARTS REQUIRED: TOOLS REQUIRED: 2. Assemble Cross Tube (P6) to T-Leg assemblies from previous step. 1 - (P6) Cross Brace None Use Bolts (H7), Washers (H8) and Nuts (H9) but only finger 4 - (H7) M8 X 70mm Bolt tighten, these parts will be tightened in the next step. Be sure 4 - (H8) Flat Washer 4 - (H9) M8 Nut that the offset holes in T-Legs match each other and that the...
  • Page 5 PARTS REQUIRED: TOOLS REQUIRED: T-Leg 1 - (P1) Table Top Assembly 2- 10mm Wrench NOTE:  Shorter hole distance 2 - (H10) M6 X 65mm Bolt 1- 12mm Wrench Closest to the table 2 - (H11) M6 Nut 1- 13mm Wrench Bottom of Table Detail A Detail B...
  • Page 6 PARTS REQUIRED: TOOLS REQUIRED: 1 - (H12) M8 X 80mm Bolt 1- 12mm Wrench 1 - (H8) M8 Flat Washer 1- 13mm Wrench 1 - (H9) M8 Nut Note: Note: Install Bolt exactly as shown below, Do not insert Bolt with the washer and nut on the side on this side.
  • Page 7 PARTS REQUIRED: TOOLS REQUIRED: 2 - (P15) Linkage 2- 10mm Wrench 2 - (H14) Bushing 2 - (H13) M6 X 90mm Bolt 2 - (H11) M6 Nut Detail F Note: Attach Linkage (P15) to the inside face of T-Legs. 7. Attach Linkages (P15) to T-Legs as shown in Details F & Detail G Details G.
  • Page 8 8. Unlock the hinge by pushing down as shown and hold the T-leg in between the two casters. Fold the assembly down AT LEAST TWO (2) ADULTS ARE NEEDED TO carefully until it rests on the floor. COMPLETE THE REST OF THIS ASSEMBLY. WHEN FOLDING LEG ASSEMBLIES DOWN MAKE Note: SURE TO DISENGAGE THE HINGE FIRST.
  • Page 9 AT LEAST TWO (2) ADULTS ARE NEEDED TO SET THE TABLE ASSEMBLIES UPRIGHT! WHEN LIFTING AND ROTATING TABLE, HANDLE TOP ASSEMBLIES BY GRASPING ONLY THE TOPS THEMSELVES. DO NOT GRASP METAL LEGS, T-LEGS, LINKAGE , OR HINGES. THESE PARTS CAN MOVE AND COULD PINCH FINGERS OR HANDS CAUSING SERIOUS INJURY! ROTATE WITH T-LEGS FULLY LATCHED.
  • Page 10 10. With two people and the Latch engaged carefully rotate the table into the upright position as shown. Pay close attention and do not grasp any AT LEAST TWO (2) ADULTS ARE NEEDED TO moving parts (Legs, Hinges, Linkages) only grasp the sides of the table as SET THE TABLE ASSEMBLIES UPRIGHT! WHEN LIFTING AND ROTATING TABLE, HANDLE TOP shown.
  • Page 11 Replacement Parts List for Model Number PT2010 Key# Part # Description Qty. PT2010-P1 1” Table Top PT2010-P2 T-LEG PT2010-P3 WELDED LEG ASSEMBLY PT2010-P4 LOCKING CASTER WHEEL PT2010-P5 NON-LOCKING CASTER WHEEL PT2010-P6 CROSS BRACE TUBE PT2010-P7 SIDE RAIL PT2010-P8 MIDDLE RAIL...
  • Page 12 U N A S S E M B L E D P A R T S...
  • Page 13 P R E - A S S E M B L E D P A R T S...
