Summary of Contents for Hamilton Hopper HSH
- Page 1 Hamilton Hopper Manual Document #101-0240 04/22/2013...
-
Page 2: Table Of Contents
Hamilton Hopper Wiring Harness ...................19 SMART HOPPER ...................... 20 Smart Hopper Assembly ......................21 Smart Hopper Assembly Chart ....................22 Smart Hopper Wiring Harness ....................23 HOPPER BOWL ......................24 Hopper Bowl Assembly ......................25 ..LIMITED WARRANTY AGREEMENT OF HAMILTON MANUFACTURING CORP. Document #101-0240 04/22/2013... -
Page 3: About This Manual
ABOUT THIS MANUAL This manual will provide the operator with important information about installing and maintaining the Hamilton Smart Hopper. To obtain assistance from the manufacturer, please call (800) 837-5561 or (419) 867-4858. When calling for assistance, it is very important to have serial numbers readily available. Please record these numbers in the spaces provided. -
Page 4: Introduction
I. Introduction The Hamilton Hopper was not only designed for large quantities of coins, it was also designed to withstand the most rugged of environments. The hopper contains minimal moving parts for reduced wear, virtually zero adjustments, and an all Lexan® and stainless steel construction to weather the harshest of environments. The Hamilton Hopper comes in many different configurations for dispensing a variety of coins and metal tokens. -
Page 5: Capacity
II. CAPACITY Hamilton Mfg. Corp. produces several different styles of Hoppers to meet the varying demands of Hamilton customers requirements. These Hoppers differ in holding capacity. The Hoppers are shown in the table below, where it is assumed that quarters are being dispensed. -
Page 6: Operation
Note: In several of Hamilton’s changers the main harness has a single quick disconnect connector that disables the hopper run switch. If the manual run switch is required connect connector, otherwise it is Hamilton’s recom- mendation that the connector should remain disconnected when hopper run switch is not required. -
Page 7: Loading And Unloading
IV. LOADING AND UNLOADING To Fill Hopper To fill the Hopper with coins, tilt the Hopper partially towards you and insert the Hopper Load Rivet through the hole in the Hopper bracket. (Refer to Diagram A on page 12). Pour coins into the top of the Hopper. Hop- per may also be removed to be filled as well. -
Page 8: Maintenance
V. MAINTENANCE The plastic parts in the Hopper are formed of Lexan®. GE’s recommendation for cleaning the plastic parts is to use normal household cleaners. DO NOT USE; gasoline, high alkaline solutions, benzene acetone, carbon tetrachloride, methyl ketone, muraitic acid, or electrical contact cleaner as THEY WILL DAMAGE THE PLASTIC. -
Page 9: Troubleshooting
VI. TROUBLESHOOTING SITUATION PROBABLE CAUSE CORRECTION Overpayment of Wash prices set incorrectly Check wash prices change HOPPER not counting coins Perform HOPPER RUN TEST (See page 11) Contact the manufacturer for assistance HOPPER does not run Coin or foreign material lodged in HOPPER Clear obstruction in HOPPER at all to pay back change... -
Page 10: Smart Hopper Troubleshooting
VII. Smart Hopper Troubleshooting Handheld Port: This port allows a user to connect the Handheld to the hopper and clear an error. Note: TXD: Sending Status of Hopper to Controller. The status can indicate that the hopper is idle or in an error state. The TXD status led indicator is Green. -
Page 11: Hopper Run Test
VIII. HOPPER RUN TEST The Hopper Run Test is a test that can be used to determine if a Hopper is counting coins correctly. Hamilton Hopper Obtain a large number of coins (500 if possible) that the Hopper is configured to dispense, and count them carefully to determine the exact number of coins. -
Page 12: Diagram A
Diagram A Document #101-0240 04/22/2013... -
Page 13: Smart Hopper Handheld
IX. SMART HOPPER HANDHELD This section will allow one to navigate through the handheld connected to a Smart Hopper to conduct one of the following processes; dispense coins, display counters, clear counters, or clear errors. Model: Smart Hopper Version: 2.02 Address 1 F1 Manual Run F2 Show Counters F3 Clear Counters F4 Maintenance Dispensing Coins... -
Page 14: Show Counters
Press F3 for Run 15 seconds Next screen displays: Run Motor 15 Seconds Motor is ON ESC=ABORT When motor stops. Next screen displays: Run Motor 15 Seconds Motor is OFF ESC=Back Show Counters Press F2 to display counters Next screen displays: Temp CNT = XXX Perm CNT = XXX Runtime = XXXXX Clear Counters Press F3 to clear counters Next screen displays: Clear Counters Are you sure (Y/N)? Press Y to clear counts Next screen displays: Counts Cleared! After a couple of seconds the screen will automatically go back to main menu Note: Clearing counts only clears the “Temp CNT” . The Perm CNT’s are non-resettable Press N to not clear counts The screen will automatically go back to main menu. Document #101-0240 04/22/2013... -
Page 15: Errors
Errors Press F4 for Maintenance Press F2 for Error Info Next page displays: Max Drops = 1 F2 Error History Max Drops: The maximum number of unexpected coins drops before triggering unexpected payout error Press F2 for Error History Next screen displays: ERR2 = X ERR3 = X ERR4 = X ESC=Back <=Page=> Selecting the right > advances to the next page Next page displays: ERR5 = X ERR6 = X ESC=Back <=Page=> ERR2 = Unexpected Coin Drop ERR3 = Hopper Coasting ERR4 = Hopper Timeout ERR5 = Drop Switch Stuck ERR6 = Watchdog Reset Press F3 to clear error Pressing F3 will automatically clear the error on the Hopper Document #101-0240 04/22/2013... -
Page 16: Hamilton Hopper
HAMILTON HOPPER Document #101-0240 04/22/2013... -
Page 17: Hamilton Hopper Assembly
Hamilton Hopper Assembly Document #101-0240 04/22/2013... -
Page 18: Hamilton Hopper Assembly Chart
Hamilton Hopper Assembly Chart Document #101-0240 04/22/2013... -
Page 19: Hamilton Hopper Wiring Harness
Hamilton Hopper Wiring Harness Document #101-0240 04/22/2013... -
Page 20: Smart Hopper
SMART HOPPER Document #101-0240 04/22/2013... -
Page 21: Smart Hopper Assembly
Smart Hopper Assembly Document #101-0240 04/22/2013... -
Page 22: Smart Hopper Assembly Chart
Smart Hopper Assembly Chart Document #101-0240 04/22/2013... -
Page 23: Smart Hopper Wiring Harness
Smart Hopper Wiring Harness Document #101-0240 04/22/2013... -
Page 24: Hopper Bowl
HOPPER BOWL Document #101-0240 04/22/2013... -
Page 25: Hopper Bowl Assembly
Hopper Bowl Assembly Document #101-0240 04/22/2013... -
Page 26: Limited Warranty Agreement Of Hamilton Manufacturing Corp
Seller further warrants all repair or service work performed by a factory trained representative or Hamilton Manufacturing Corp. for a period of ninety (90) days from the date the repair or service work was performed. Purchaser’s remedies and the liabilities and obligations of Seller herein shall be limited to repair or replacement of equipment as Seller may choose, and Seller’s obligation to... - Page 27 The limited warranty for repair and service work is conditioned upon the following: The subject equipment has not, in the Seller’s sole opinion, been sub- jected to: accident, abuse, misuse, vandalism, civil disobedience, riots, acts of God, natural disaster, acts of war or terrorism. The Seller shall not be liable for any expense incurred by Purchaser in- cidental to the repair or replacement of equipment and Purchaser shall assume full responsibility for any freight or shipping charges.
- Page 28 Hamilton Manufacturing Corp. 1026 Hamilton Drive Holland, OH 43528 Sales Phone: (888) 723-4858 Sales Fax: (419) 867-4850 Customer Service Phone: (800) 837-5561 Customer Service Fax: (419) 867-4857 Parts Phone: (866) 835-1721 Parts Fax: (419) 867-4867 Website: http://www.hamiltonmfg.com Email Addresses: service@hamiltonmfg.com sales@hamiltonmfg.com...
