- 1 Ew Ingressi/Uscite
- 2 Montaggio EW600 Su Terminale EW / Assembly of Terminal EW600
- 3 Rimozione EW600 da Terminale EW / Removal from Terminal EW600
- 4 Collegamenti Elettrici / Electrical Connections
- 5 EW600N00C04 - I/O HIGH SPEED 4OUT – Push/Pull – Opto-Isolated
- 6 Function (Software Selectable)
- Download this manual
EW INGRESSI/USCITE
EW INPUT/OUTPUT
EW ENTRÉES/SORTIES
EW EINGABE/AUSGABE
EW ENTRADAS/SALIDAS
Dimensioni / Dimensions / Dimensions / Abmessungen / Dimensiones
EW600N
Rev. 0
Date: 17/06/2015
405.1300.235.0
Advertisement
Table of Contents
Summary of Contents for ESA AUTOMATION EW Series
- Page 1 EW INGRESSI/USCITE EW INPUT/OUTPUT EW ENTRÉES/SORTIES EW EINGABE/AUSGABE EW ENTRADAS/SALIDAS Dimensioni / Dimensions / Dimensions / Abmessungen / Dimensiones EW600N Rev. 0 Date: 17/06/2015 405.1300.235.0...
- Page 2 Montaggio EW600 su terminale EW / Assembly of terminal EW600 EW / Montage du EW600 sur terminaux EW / Montage des Terminals EW600 EW / Montaje del terminal EW600 EW Spegnere il EW / Switch off EW / Éteindre le EW / Das EW ausschalten / Apague el EW CLICK CLICK Rimozione EW600 da terminale EW / Removal from terminal EW600 EW / Retrait...
- Page 3 Collegamenti elettrici / Electrical Connections / Connexions électriques / Elektrische Anschlüsse / Conexiones Eléctricas Spring connector 0,14 – 1,5 mm 30 – 14 AWG 9 - 10mm...
- Page 4 Collegamenti elettrici / Electrical Connections / Connexions électriques / Elektrische Anschlüsse / Conexiones Eléctricas EW600N00C04 - I/O HIGH SPEED 4OUT – Push/Pull – Opto-isolated Frequency range: 200Hz...300KHz – Output current range: 5mA...10mA Function (software selectable) CW/CCW Pulse+Direction Pulse Direction 0VDC 0VDC Enable * Enable *...
