Summary of Contents for Moskinap KINOR-35N
- Page 1 MOVIE CAMERA «KINOR-35N» Technical specification and operating instruction in two parts Part 1 MKBI.202124.003 TO http://RafCamera.com © 2004 RafCamera, edited by David Norman...
-
Page 2: Table Of Contents
5. CONSTRUCTION AND OPERATION OF THE CAMERA ..........10 5.1. The kinematics of the “KINOR-35N” camera..............10 5.2. The optical schematics of the “KINOR-35N” camera............10 6. CONSTRUCTION AND PRINCIPLE OF WORK OF THE MAIN PARTS ......11 6.1. - Page 3 11.6. Mounting the matte box....................17 11.7. Mounting the video assist set ................... 18 11.8. Mounting the light metering device and preparation it for work ........18 11.9. Preparation of the batteries ....................18 11.10. Operating the network power supply unit ..............18 11.11.
-
Page 4: Introduction
The technical specification and operating instruction is intended to teach the operation and maintence of the movie cameras “KINOR-35N” model 9KSN and model 9KSN-M. It contains information necessary for full use of the technical aspects of the systems and correct operation of the camera. -
Page 5: Light Metering Device
- higher air temperature, °C Plus 40 98 at 25°C - maximum relative humidity, % Transporting temperature range, °C From minus 50 to plus 50 Dimensions of the camera with the 150m mag and 75mm lens, mm, no more than: - length - width - height... -
Page 6: Voltage Conversion Unit (Bpn)
Dimensions, mm, no more than - length - width - height Weight, kg, no more than 0.082 3.6. Voltage Conversion Unit (BPN) Power, V , 50±0.1Hz - of the input signal –11 - of the output signal, no more than 50±0.1 Frequency of the output signal, Hz Consumption current, A, no more than... -
Page 7: Configuration
4. CONFIGURATION 4.1. Configuration meets to the Table 1. Table 1 Quantity, pieces Name, index of the Document number Normal Wide-screen Note item version version Camera gear with the MKBI.203211.002 It contains: gear; electrical drive; film gate controlling device UR MKBI.421212.005 and ground glass for the normal frame;... - Page 8 with tools; ZIP set; compendium bracket (for the rods); tubule; two brackets for zoom and anamorphic lenses. Case (#2) MKBI.323369.095 Network Power Supply Unit; camera to BPS cable; BPS to network cable. Case (#3) MKBI.323369.088 50mm anamorphic lens; compendium; set of the brackets for the anamorphic lenses;...
- Page 9 light meter or video assist Video Assist set MKBI.468949.001 It contains: optical adapter, bracket, handle KTU25.000-01. Used together with the beam splitter MKBI.203571.001 Electrical focusing device 5KSN-KEP17/U1.1 TU19-533-84 Used together with the bridge plate MKBI.301714.002 Charger UZ TU19-421-83 Used for charging the batteries. Comes with the cable.
-
Page 10: Construction And Operation Of The Camera
Cinematic link if the motors with the cores is accomplished by the belts (31) and (36) through the pulleys (30), (35) situated on the shafts (IX) and (X). 5.2. The optical schematics of the “KINOR-35N” camera. The optical schematics of the camera provides the following features: generating the image of the objects by the lens on the film at the frame window;... -
Page 11: Construction And Principle Of Work Of The Main Parts
The lens (81) has two positions D and E determining the two magnification factors of the viewfinder. The magnification of the assembly of the long viewfinder (79) with the viewfinder (51) will be 5x and 10x. The magnification of the assembly of the long viewfinder (79) with the desqueezer will be 6x and 12x in the horizontal direction, and 3x and 6x in the vertical direction. -
Page 12: The Mags
The motor (107) (Picture 6) is installed on the other side of the camera. There are a fixed stop detector and a pulley (for transferring the movement form the motor (16) (Picture 3) to the claw mechanism (28) (Picture 5)) on the one end of the motor. Other end of the motor transfers the rotation to the single-blade shutter with 180°... -
Page 13: The Brackets
The two-side follow focus is shown at the Picture 11. Its construction is similar to the one-side follow focus. Main differences are the second focusing know (164) and mounting method (it is mounted onto the rods (154 ) (Picture 12a) of the bridge plate). -
Page 14: The Controller
The bracket (182) serves for mounting of the VKU. The bracket has a movable part to rotate the VKU in the vertical plane. To do this, loose the screw (183), set the VKU into desired position, and tight the screw again. 6.12. -
Page 15: The Thermo Regulator
6.18. The thermo regulator The thermo regulator is for the providing of the necessary temperature condition inside the camera and the mag upon lowering the air temperature below +5°C. It is standalone unit. It has following controls and indicators: The indicator of the power presence. The indicator of the camera heating. -
Page 16: The Safety Guidelines
ATTENTION! Do not use a tele lenses without bracket. Do not bend the film end during loading of the mag. 10. THE SAFETY GUIDELINES Observe the following things for safe operation of the camera. Do not do anything (repairing, testing, adjusting, fuse replacing etc.) with power on and during parts movement. Do not change any connection or units replacement during shooting. -
Page 17: Loading The Camera
11.3. Loading the camera Open the camera door (100) (Picture 5). Shift the clamping rollers (97). Shift the lever (88) of the side clamps in the film channel. Press the handle (102) and turn it to set the reg pin fork into leftmost position. Shift the reg pin out of the film channel pulling the lever (87) to the right. -
Page 18: Mounting The Video Assist Set
11.7. Mounting the video assist set Open the camera door (100) (Picture 5). Replace the mirror with the beam splitter. Insert the camera (180) (Picture 13) into the window of the plate (175) and secure it by two screws through the bracket. Mount the optical adapter (178) into the slot “V”... -
Page 19: Heating
11.12. Heating The heater is used when the air temperature drops below plus 5°C. Unscrew the screws of the bottom cover of the side wall (105) (Picture 6), and remove the cover. There is the jack under it. Install the adapter (112) instead of the cover, and secure it by the screws. Connect the output heater jack KSA to the CAMERA jack of the thermo regulator by the KSA-THERMOREG cable. -
Page 20: Maintenance
the belt Scratches or friction lines on Scale on the working surfaces Remove the scale and clean the film of the film channel. Dirt at the film track elements the film track elements ‘Salad’ in the camera Incorrect loading Reload camera camera (subsection 11.2 and 11.3) -
Page 21: The 300M Mag
14.5. Adjusting belts tension in mags. There is a slit in the plate of the mag mechanism to adjust tension of the take-up spool. In the 150m mag, this slit is covered with a cover secured with a single screw. To adjust tension: 1) loosen the screw in the slit;... -
Page 22: 14B. Depreservation And Re-Preservation
14a.2.3. Wrap the case into the paper before placing them into the bags. Use any of the following papers: - paraffined paper GOST 9569-79; - paraffined capacitor paper GOST 1908-82; - two-ply packing paper GOST 8828-75; - brown paper GOST 8273-75 sodden with temporary corrosion preventing agent. 14a.2.4. -
Page 23: Appendix
APPENDIX LIST OF THE PICTURES Picture 1. The camera Kinor-35H. General view........................25 Picture 2. The camera Kinor-35H. Right view..........................25 Picture 2a. The camera Kinor-35H with the 300m mag......................26 Picture 2b. The camera Kinor-35H with the 150m mag and the mag tilt..................26 Picture 3. - Page 24 The camera Kinor-35H. General view. Picture 1 The camera Kinor-35H. Right view. Picture 2...
- Page 25 The camera Kinor-35H with the 300m mag. Picture 2a The camera Kinor-35H with the 150m mag and the mag tilt. Picture is missing. Sorry. Picture 2b...
- Page 26 The camera Kinor-35H. Kinematics. Picture 3...
- Page 27 The camera Kinor-35H. Optical schematics. Picture 4...
- Page 28 The camera. Film track side view. Picture 5 The camera. Front view (side wall is removed). Picture 6...
- Page 29 The camera. Rear view (side wall is removed). Picture 7 The 150m mag. Picture 8...
- Page 30 The 300m mag. Picture 8a The viewfinders. Picture 9...
- Page 31 The one-side follow focus device. Picture 10 The two-side follow focus device. Picture 11...
- Page 32 The matte box bracket. Picture 12 The bridge plate set. Picture 12a...
- Page 33 The video assist set. Picture 13 Diagram of the loading the mag and the camera. Picture 14...
- Page 34 The scheme of the battery charging connections. Picture 15 The scheme of the battery deep charging connections. Picture 16 The scheme of the battery charging connections. Picture 17...
