Summary of Contents for Morplan Edge Series
- Page 1 0330 44 55 666 London 020 7636 1887 Bristol 0117 964 3883 Glasgow 0141 429 0537 Birmingham 0121 333 1390...
- Page 2 edge range wall bay kit 1 60003 35cm 60cm 146cm 40cm 70cm Item Code Description 2510D 60055 Wood Shelf 70 x 35cm 9612 60018 Wall Plate With screws M5x10 TB 9653A 60022 Hanging Rail 60cm 9652 60021 End Connector 9600 60014 Upright 9615...
- Page 3 edge range wall bay kit 1 assembly guide place the base insert the connectors Place the wooden base (9625D) close to the wall, insert the square Insert end connectors (9652) in square holes of uprights. End connector collars (9615) and the uprights (9600 with black finned cap) is a single model for right and left, pay particular attention to direction of the thread.
- Page 4 edge range wall bay kit 2 60005 35cm 90cm 146cm 100cm 40cm Item Code Description 2512D 60057 Wood Shelf 100 x 35cm 9612 60018 Wall Plate With screws M5x10 TB 9653B 60023 Hanging Rail 90cm 9652 60021 End Connector 9600 60014 Upright 9615...
- Page 5 edge range wall bay kit 2 assembly guide place the base insert the connectors Place the wooden base (9625D) close to the wall, insert the square Insert end connectors (9652) in square holes of uprights. End connector collars (9615) and the uprights (9600 with black finned cap) is a single model for right and left, pay particular attention to direction of the thread.
- Page 6 edge range wall bay kit 3 60001 70cm 35cm 70cm 70cm 60cm 60cm 146cm 60cm 60cm 318cm 40cm Item Code Description 2510D 60055 Wood Shelf 70 x 35cm 9612 60018 Wall Plate With screws M5x10 TB 9653A 60022 Hanging Rail 60cm 9651 60020 Centre Connector...
- Page 7 edge range wall bay kit 3 assembly guide place the base insert the connectors Place the wooden bases (9625D) close to the wall, insert the square Insert end connectors (9652) and centre connectors (9651) in square collars (9615) and the uprights (9600 with black finned cap) holes of uprights.
- Page 8 edge range combination bay kit 1 60007 35cm 100cm 70cm 90cm 146cm 60cm 35cm 60cm 224cm 40cm Item Code Description 60051 Wood Shelf 60 x 35cm 2506D 2510D 60055 Wood Shelf 70 x 35cm 2512D 60057 Wood Shelf 100 x 35cm 9612 60018 Wall Plate...
- Page 9 edge range combination bay kit 1 assembly guide place the base insert the connectors Place the wooden bases (9625D/9626D) close to the wall, insert the Insert end connectors (9652) and centre connectors (9651) in square square collars (9615) and the uprights (9600/9601 with black finned cap) holes of uprights.
- Page 10 edge range combination bay kit 2 60009 35cm 100cm 100cm 90cm 180cm 90cm 35cm 60cm 254cm 40cm Item Code Description 60051 Wood Shelf 60 x 35cm 2506D 60057 Wood Shelf 100 x 35cm 2512D 60018 Wall Plate 9612 With screws M5x10 TB 9653B 60023 Hanging Rail 90cm...
- Page 11 edge range combination bay kit 2 assembly guide place the base insert the connectors Place the wooden bases (9625D) close to the wall, insert the square Insert end connectors (9652) and centre connectors (9651) in square collars (9615) and the uprights (9600/9601 with black finned cap) holes of uprights.
