- Page 1 PRODUCT SANDOR Product code SANDOR PLUS SMA SANDOR PLUS SMA DOUBLE OPTIC PERIMETER BARRIER INSTALLATION AND MOUNTING MANUAL VERSION 2.6...
-
Page 2: Table Of Contents
19.1 Serial port connection for each barrier 20.Appendix E: single barrier with optical synchronism ……. ………………. ……………………..……. ………… ..32 21.Technical characteristics ………. ……………. ……………………………………………………………..……………. …… ..33 22.F.A.Q………………………………….………………….……………………………………………………………………….…………….34 23.Product disposal ………………………………. ………. …………………………. …………………..………. …………… 36 SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 3: Introduction
The system has been designed to detect intrusions and activate the alarm; it is not a device that prevents intrusion.Politec is not responsible for damage, injury or loss caused by accidents, theft, force majeure (including momentary lightning-induced overcurrent), abuse, improper or incorrect use, faulty installation or inadequate maintenance. -
Page 4: General Warnings
• Manufacturer's liability:Politec assumes no liability for failures resulting from incorrect installation; lack of maintenance, incorrect assembly or use. • Politec is also not liable for incorrect or incomplete operation of the product or failure to detect intrusion. • Warranty (summary of conditions):Politec guarantees its products for a period of 2 years from the production date.The warranty is applied to those purchasing directly from Politec;... -
Page 5: List Of Main Components
The package contains the following components and accessories. When opening the package, check that everything has been included. COMPONENT Aluminium profile Polycarbonate black cover Caps Transmitter \ Receiver optics MES9C Terminal board MES9012 Motherboard SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 6: Preparation For Installation
• Check that the surface chosen for the installation of the product is solid so as to ensure stable fixing and that it is adequately protected from possible impacts or atmospheric agents. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 7: Assembly/Fixing Examples
Pole mounting Wall mounting with Wall mounting with with SAN/PL brackets SAN/SD brackets SAN/PL pole brackets (recommended protection of sections along the wall) SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 8: Placement And Assembly
WARNING: Product warranty is invalid if there is any hole in the aluminium profile or any component SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 9: Evaluations Before Installation
TX and RX, thus ensuring a good amount of signal constantly, even in case of particular climatic conditions. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 10: Barrier Positioning
DO NOT place barriers close to roads: vehicle lights directed towards the RX could create disturbances DO NOT place barriers near automatic gates: photocell signals can create interference. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 11: Installation Examples
9.Installation examples 9.1 Barrier control All Politec products can be customised according to the installation needs, including column height and consequently the number of beams inside which can vary in different ways and work in parallel or crossing. The barriers can have both TX and RX inside, or they can be terminal barriers that have only TX or RX inside them. -
Page 12: Wiring
The sizing of the cables depends on the consumption of the columns and on the resistance of the cable itself according to the distances involved. The table shows the cable cross-sections and the relative distances to ensure optimum performance using the LAR22 power supply (12Vdc-2.5A/24Vac-300W) and a SANDOR PLUS SMA barrier (4TX + 4RX). CONDUCTOR CROSS-... -
Page 13: Connection Of Cables From Power Supply To Barrier
10.2 Connection of cables from power supply to barrier It is recommended to make a star-shaped connection to avoid excessive voltage drops on the power cables Power supply Power supply Power supply SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 14: Connections To The Terminal Board
(TX => RX) (- S.IN) (- S.OUT) (TX => RX) Not in use AME COAXIAL AME COAXIAL Not in use Not in use TRESSE COAXIAL TRESSE COAXIAL Not in use SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 15: Wire Synchronism
N.B.:It is also necessary to connect the power supply negative in common between the columns and to use shielded cables (2x0.22mm²) for the synchronisms preferably separated from the power supply, with the braid connected to the negative. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 16: Connection For Synchronism
Using a cable with a shielded 2X0.22mm² cross-section, connections up to 500 m can be made. In the event of joints, the braid and shield connections must also be restored. Sout Control unit Sout Sout Sout Control unit Sout Sout Control unit Sout SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 17: Barrier Alignment
It is sufficient to apply the filter only on the TX, there is no need to repeat the operation also on the SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 18: Alignment
The maximum alignment condition will be reached when the high intensity LEDs are on steady and the buzzer will emit a continuous sound, for this reason, it may be necessary to act with small movements also on the RX optic. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... - Page 19 TRANSMITTER optic with your hand: if the RECEIVER continues to give a continuous beep, it means that it sees another infrared source that must be turned off and eliminated. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6...
-
Page 20: Parallel Beam Calibration
WARNING: a too close a distance RX 4 TX 4 between the TX and RX columns does not allow calibration with the crossing function. RX 3 TX 3 RX 2 TX 2 RX 1 TX 1 SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 21: Optical Synchronism
N.B.:Optical synchronism requires greater attention during the installation phases, in particular, that the receiving column is not affected by other sources of IR light, such as other barriers of the same system, gate photocells etc. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 22: Basic Functions
12 DIP UNIT FOR CONFIGURATION • AND RANDOM: DIP 9 • AND ON BEAM 1-2: DIP 8 • BEAM 1 DEACTIVATION: DIP 7 • BEAM 1-2 DEACTIVATION: DIP 6 • DISQUALIFICATION FUNCTION: DIP 5 SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 23: Intervention Time Adjustment
(e.g. animal crossing). By adjusting the potentiometer clockwise, the intervention time decreases down to 50ms. In this condition, the alarm of a person crossing the barrier running at maximum speed is guaranteed. ALARM SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 24: Motherboard Components
SYNC Yellow TRIMMER Intervention time adjustment DISQ1 12 DIP SWITCH UNIT Function selector 4 DIP SWITCH UNIT TX Function selector 4 DIP SWITCH UNIT RX Function selector TAMPER Column tamper connection SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 25: Led Signal Operation
Normally off, when on the heating is active. SYNC LED The SYNC LED indicates by continuous flashing the correct LED confirming the operation of the wiring and functioning of the synchronisms between synchronism system transmitters and receivers. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 26: Characteristics Of Settings
In the ON position it closes the RS485 communication.To finish it is RS485 necessary to put ON only on the board of the furthest column of the entire line. LEDS In the ON position it activates the LEDs. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... - Page 27 If the disqualification function has been activated on DIP SWITCH 12 via DIP 5 in ON, in some cases and particular geographical areas, it may be useful to increase the sensitivity of the disqualification by setting jumper J7 to ON. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6...
-
Page 28: Appendix B: Optical Board Configuration
(SW4) on all optics and on the MES 9 C board. The voltage can be both AC and DC. N.B.:The settings relating to the addressing of the optics are already set by default. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 29: Receiver Optics
N.B.:The settings relating to the addressing of the optics are already set by default. N.B.:The barrier can result in an alarm even if the WEAK SIGNAL LED is off.The cause may be the lack of synchronism or a misaligned transmitter. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 30: Appendix C: Configuration With 3/2 Receivers
Set to ON DIP 6 of the 12 unit on the MES9012 motherboard Receivers side to exclude RX1 + RX2 2 3 4 5 6 7 8 9 10 11 12 SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 31: Appendix D: Serial Connection To The Adebus Concentrator
N.B.:It is possible to use the two additional wires of the bus cable for synchronism (red-black pair) 19.1 Serial port connection and synchronism for each barrier. MES9C board MES9C board Barrier 1 Barrier 2 Black Braid Adebus board Green White Adebus board SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 32: Appendix E: Single Barrier With Optical Synchronism
TX 1 TX 1 RX 1 RX 1 Column 1 Column 2 TX channel TX channel 2 3 4 2 3 4 RX channel RX channel 2 3 4 2 3 4 SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 33: Technical Characteristics
4TX or 4RX Total beams 12-24Vdc 12-24Vdc 12-24Vdc Power supply 80 mA 100 mA 135 mA Consumption Column 15W 24Vac 20W 24Vac 25W 24Vac internal with thermostat with thermostat with thermostat heaters SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... -
Page 34: F.a.q
For more precise alignment, position one side of the column cover in front of the lenses in order to have two surfaces interposed between TX and RX to double the attenuation of the beam. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6... - Page 35 For more precise alignment, position one side of the column cover in front of the lenses in order to have two surfaces interposed between TX and RX to double the attenuation of the beam. SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6...
-
Page 36: Product Disposal
Warning!- Local regulations can impose heavy penalties for incorrect disposal of these products. For technical support, contact your security systems distributor SANDOR PLUS SMA POLITEC | INSTALLATION MANUAL - VER.2.6...
