- Page 1 TVS-2V-HS1 H250 Military Handset with Frequency Hopping Code/Rolling Code Voice Scrambling Manual Revision: 2018-03-30 Rev B Covers Firmware Revisions: VS: 1.71 and newer Covers Hardware Revisions: TVS-2V-HS1: B...
-
Page 2: Hardware Specifications
SIGNALING INFORMATION The TVS-2V-HS1 offers the following signaling functions: ANI: When the PTT button is pressed the Handset will generate an ANI and sync to be decoded by Midian’s CAD-300 or DDU-300. ENI: When an emergency input is received through the optional lone worker/ man down feature the Handset will... -
Page 3: Product Programming
Note: Greater details of the TVS-2V series products can be found in the TVS-2 Series Technical Reference Manual. The TVS-2V-HS1 is programed via the MPS software and H250prog please reference the H250prog manual for setup instructions and location of connectors on the H250prog. -
Page 4: Audio Alignment
AUDIO ALIGNMENT Spkr In, Mic In, Spkr Out: These settings are internal levels to the TVS-2V-HS1 and have been set at the factory for best performance. They should not require adjustment. MIC Out: This is the only adjustment that should be made to the audio levels of the TVS-2V-HS1. If transmitter modulation is low this level should be increased one or two steps at a time, until full modulation has been reached. -
Page 5: Product Warranty Information
In this case it would be necessary to flip the power off and then back on so that the TVS-2V-HS1 handset comes up in the clear mode (indicated by 3 beeps). - Page 6 This page intentionally left blank...
- Page 7 U11:2 +3.3VDD TS-120/TS-130 LMC662 .47u VAE-1 .0068u VAN1 SHLD U2:1 .47u U2:2 220p LMV324 LMV324 DOCUMENT NAME VS-1xxx-HS1 MIDIAN ELECTRONICS, INC. CONN-A 100K 8.2K .001u 4.7u .001u .01u APPR SCHEMATIC VAN1 DATE: 2017-01-20 UPD BY: SHEET PROJECT NUMBER 7783 Copyright © 2017...
