EMC

40U-C Cabinet

Unpacking and Setup Guide

300-001-555

REV 05

September 3, 2014

This Unpacking and Setup Guide contains information about the EMC 40U-C cabinet.

Topics include:

Note

This document was accurate at publication time. Go to EMC Online Support

support.emc.com) to ensure that you are using the latest version of this document.

Before you start

.........................................................................................................2

Tools

required............................................................................................................2

Hardware

acclimation................................................................................................ 3

Steps to unpack and setup

Remove the ramp and shipping material from the

Remove the cabinet shipping

Attach the unloading

ramp.........................................................................................6

Roll the cabinet down the

Position and level the

cabinet.................................................................................... 9

Attach (optional)

brackets..........................................................................................9

Install the lower rack

bezel.......................................................................................11

Ground the

cabinet.................................................................................................. 11

Repackaging shipping material (2-piece ramp kits

If you need

help....................................................................................................... 15

cabinet............................................................................ 3

cabinet.......................................... 4

brackets.......................................................................5

ramp..................................................................................7

only)...........................................12

(https://

Table of Contents

Need help?

Do you have a question about the 40U-C and is the answer not in the manual?

Questions and answers

Summary of Contents for EMC2 40U-C

Page 1: Table Of Contents
40U-C Cabinet Unpacking and Setup Guide 300-001-555 REV 05 September 3, 2014 This Unpacking and Setup Guide contains information about the EMC 40U-C cabinet. Topics include: Note This document was accurate at publication time. Go to EMC Online Support (https:// support.emc.com) to ensure that you are using the latest version of this document.
Page 2: Before You Start
CL5427 Note The illustrations in this guide are examples only. Depending on what you ordered, your configuration may look somewhat different from what is shown here. Tools required 9/16-in. (14-mm) socket wrench Adjustable wrench Flat screwdriver Phillips screwdriver 40U-C Cabinet...
Page 3: Hardware Acclimation
Unpacking and Setup Guide Hardware acclimation Systems and components must acclimate to the operating environment before power is applied to them. Once unpackaged, the system must reside in the operating environment for up to 16 hours to thermally stabilize and prevent condensation. If the last 24 hours of the …and the OPERATING …then let the system or component...
Page 4: Remove The Ramp And Shipping Material From The Cabinet
CL4691 2. Do not pull a ramp down from the top. To release the ramp from the pallet, grasp the ramp, pull it straight back toward you, then pull it straight up to free it from the screws. 40U-C Cabinet...
Page 5: Remove The Cabinet Shipping Brackets
Unpacking and Setup Guide Rear Bracket Bracket Screws Rotated 90 EMC3552 3. Remove the plastic covering from the cabinet. Remove the cabinet shipping brackets Procedure 1. At the rear of the cabinet, remove the rear shipping bracket, by removing the bolts that go through the bracket to the rack and into the pallet.
Page 6: Attach The Unloading Ramp
Procedure 1. Insert the ramp brackets into the pallet notches in the rear of the pallet. Rear EMC2843 2. If your shipment includes a two-piece ramp, attach part A to the pallet and part B to part A. 40U-C Cabinet...
Page 7: Roll The Cabinet Down The Ramp
Unpacking and Setup Guide CL4692 Roll the cabinet down the ramp NOTICE Make certain the leveling feet are secured in the UP position before moving the cabinet. Secured feet allow the cabinet to roll off the ramp and into position. If you need to adjust the leveling feet, use an adjustable wrench and turn the feet clockwise to raise them to the UP position.
Page 8 WARNING Balance the cabinet from the sides; do not grasp the plastic bezels or other components on the front of the cabinet. DO NOT STAND IN FRONT OF THE CABINET EMC2846 40U-C Cabinet...
Page 9: Position And Level The Cabinet
Unpacking and Setup Guide Position and level the cabinet 1 3/8-in. EMC2847 Attach (optional) brackets We strongly recommend that you secure your cabinet to the floor with stabilizing brackets. Make sure the cabinet is in its final location before attaching the brackets, then use the supplied bolts and mounting holes to attach them to the cabinet and floor Figure 1 Anti-tip bracket (installed on the front of cabinet) CL4830...
Page 10 Figure 2 Anti-move bracket (installed on the front and back of cabinet) CL4832 Figure 3 Seismic bracket (installed on the front, back, and sides of the cabinet) CL4833 40U-C Cabinet...
Page 11: Install The Lower Rack Bezel
CL4829 Ground the cabinet Equipment correctly installed within the 40U-C cabinet is grounded through the AC power cables and connectors. In general, supplemental grounding is not required. If your site requires external grounding (for example, to a common grounding network beneath the site floor), you can use the grounding lugs provided on each of the cabinet’s...
Page 12: Repackaging Shipping Material (2-Piece Ramp Kits Only)
(Left) Ground lug CL4389 Repackaging shipping material (2-piece ramp kits only) Follow these steps to repackage the 40U-C shipping material: Procedure 1. Lay each of the outer sleeves flat, then fold it lengthwise before collapsing the three sections, as shown: CL4690 2.
Page 13 Unpacking and Setup Guide CL4697 Refer to the following illustration as you perform steps 3-5. 3. Place ramp section B upside-down on the pallet, then stack section A, right-side up. 4. Stack the two folded outer sleeves above the ramp sections. 5.
Page 14 If the cabinet was unpacked after delivery, refer to the contact number attached to the pamphlet for repacking. This contact is the carrier network for the initial shipment and they will follow the same process as for the initial shipments. 40U-C Cabinet...
Page 15: If You Need Help
Unpacking and Setup Guide If you need help For questions about technical support and service, contact you service provider. For questions about upgrades, contact your sales office. More information about this and other products is available on the EMC Online Support website at http://Support.EMC.com.
Page 16 EMC², EMC, and the EMC logo are registered trademarks or trademarks of EMC Corporation in the United States and other countries. All other trademarks used herein are the property of their respective owners. For the most up-to-date regulatory document for your product line, go to EMC Online Support (https://support.emc.com). 40U-C Cabinet...
