Sawyer 284D User's Operation Manual

ADJUSTABLE TORCH ARM
About Us
We appreciate your business!
Congratulations on your new SAWYER product. We are proud to have
you as our customer and will strive to provide you with the best service
and reliability in the industry. This product is backed by our extensive
warranty and world-wide service network. To locate your nearest
distributor or service agency, please contact us at the phone number
and address listed on the bottom of each page.
You are in good company!
Sawyer Manufacturing Company is the world leader in the design and
manufacture of pipeline and welding equipment since 1948. Sawyer
equipment has become a standard in the industry and continues to set
the benchmark for quality and durability.
This user operation manual has been made to instruct you for the best
use and operation of your Sawyer product. Your satisfaction with our
products is our main goal. Please read this entire manual carefully
noting all tips, notes and warnings. Safety always comes first.
Parts Diagram
*Note: Torch not included*
! WARNING
WARNING:
Moving parts can snag
and pull. Keep loose items clear.
! WARNING
WARNING:
Refer to torch
manufacturer for safety settings.
Tools Needed for Assembly* Tools Needed for Assembly*
1/2" Wrench
*Not Included
C
!
D
!
E
Sawyer Manufacturing Company
7799 S. Regency Dr., Tulsa, OK 74131 USA
P 918.834.2550
sawyermfg.com
Adjustable Torch
Holder Manual
B
A
A. Mounting Frame
B. Ring (Torch Adjustment)
C. 37.5-0-37.5 Degree/Bevel Indicator
D. Knob (Position Adjustment)
E. Square Nut (Bevel Indicator)
F. Knob (Torch Holder Adjustment)
F
Manufacturing Company are guaranteed against
replacement of any parts found to be defective,
F 918.834.0318
info@sawyermfg.com
V1.2
Models 284D
For Band Type Beveling
Model 206D
Warranty
All products manufactured by or for Sawyer
defects due to faulty workmanship or materials
for twelve months from the date of purchase.
This guarantee is limited to the repair or
and no other liability, expressed, implied or
contingent is assumed.
