Guepard Networks GO1200ac Manual

Dual band 11ac/11n 1200 mbps ap/cpe outdoor wireless
Hide thumbs

Advertisement

Quick Links

Download this manual
GO1200ac Manual
1200 Mbps
Dual Band 11ac/11n
AP/CPE OUTDOOR WIRELESS
Model: GO1200ac
ADVANCED TECHNOLOGY
Professional Qualcomm Chipset
GO1200ac was integrated Qualcomm's chipsets. This is an 11ac 1200Mbps High Power Outdoor CPE/AP/
Router/WISP, wireless distance can be 500-1.000 meters (a pair CPEs). This Outdoor CPE with the next
genera on 802.11ac Wi-Fi standard combined 1200Mbps Wi-Fi speed over 2.4GHz (300Mbps) and 5GHz
(900Mbps) and equipped Gigabit WAN port, Gigabit Ethernet data rate can be taking care 40-80 end
users at the same me. Matching access demand to enjoy seamless HD movies, streaming, online
gaming, wireless security and other bandwidth-intensive tasks.
1 |
P a g e
www.guepardnetworks.com
