Summary of Contents for SPRiZZi DRINK MACHINE

  • Page 1 SPRiZZi Drink Machine User Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safe Usage & Warnings ......2 - 5 Unit Specifications ......6 - 7 Basic Set Up Instructions .

  • Page 3: Safe Usage & Warnings

    Water Reservoir. WARNING WARNING Use of Drink Machine Flavor Bullet lids and small in a manner other than removable parts of the machine which it is intended can can be hazardous if swallowed.
  • Page 4 SPRiZZi approved service representatives should For best opperation, plug repair. Do not attempt to Drink Machine into its open any part of the drink own outlet. machine not intended for use. When used by children, supervision is required.
  • Page 5 Risk of fire or electric shock. dioxide poisoning. In the event of Do not attempt to use if a CO leak, ventilate the area and Drink Machine or power cord seek medical attention. are damaged.

  • Page 6: Unit Specifications

    UNIT SPECIFICATIONS Fresh Water Reservoir – 1500 ml • Carbonated Reservoir – 500 ml • Operating Voltage - 12 VDC • Power Supply Voltage - 120 VAC • Serve Capacity @ >40F - 2000 ml • Recovery Time - 15 min •...
  • Page 7 Power Button Beverage Diffuser Drip Tray Water Reservoir Beverage Nozzle Canister Thermal Electric Chiller Water Line Adapter Countertop Lighting The SPRiZZi Drink Machine is available in several popular colors, so there is sure to be one that will match your style.

  • Page 8: Basic Set Up Instructions

    BASIC SET UP INSTRUCTIONS Before you begin using your dispenser there are a few things you should know. While these units do have a live water hook up function on them, we do not recommend the use without a water filter and water regulator. After removing unit from box, please ensure that all tape, sponges, and other packing materials are removed before first use.
  • Page 9 Place your unit on your counter, or other flat surface, where you will be using it for permenant use. You want a flat level surface to place your SPRiZZi Drink Machine, and ensure that the surface is clean anddry before placement.
  • Page 10 STEP PLUG IN YOUR DRINK MACHINE Plug your power supply into a 110 VAC outlet then plug in the power bayonet into the right side receptacle when you are looking at the back of the unit. IMPORTANT: When you plug your unit in, observe that the 2 LED lights on the front of the unit briefly upon plugging it in.
  • Page 11 Once it is filled, you will also hear 3 carbonating bursts and then green. the right side LED will be If your drink machine fails to power on, refer to the troubleshooting guide for assistance.
  • Page 12 STEP ALLOW WATER TO CHILL solid green, the water in the carbonator tank If the LED light is a is below 40 degrees Fahrenheit and is ideal for pouring. If it is flashing green, it is above 40F. Give it some time and it will chill below 35F.
  • Page 13 STEP ADD YOUR FLAVOR BULLET Remove the bullet wrapping around the top lid of the bullet then unscrew the cap. Next, open the bullet cavity door (which has the silver handle) and proceed to put the bullet into the cavity placing the center bayonet inside the bullet and screw it down firmly.
  • Page 14 STEP POUR A BEVERAGE Now, simply touch and release the left dispense button for an auto-pour non-carbonated drink, or the right button for an auto-poured carbonated drink. (The dispense buttons are non-moving and simply need to be touched to work.) NOTE: If you try to carbonate a non-carbonated flavor, you may experience much more...
  • Page 15 STEP ENJOY! Now just kick back, and enjoy all of your favorite carbonated and non-carbonated beverages. Don’t worry about shutting off the machine. The unit shuts off, but remains cooling after 10 minutes of non-use. The cooling will remain on until the unit reaches temperature.

  • Page 16: Cleaning Instructions

    CLEANING INSTRUCTIONS • Wipe down your Drink Machine once a day. It is recommended that your unit is off when wiping it down as you may inadvertently press the dispense buttons. • We also reccomend running a BevClean bullet once a week.

  • Page 17: Frequently Asked Questions

    FREQUENTLY ASKED QUESTIONS How long does it take my Sprizzi machine to get cold? • When using room temperature water, it can take up to 90 minutes. • When using 40 degree refrigerated water, it can take up to 30 minutes.
  • Page 18 Why is the left LED flashing green? • When left LED is flashing green, that indicates that there is only 10 oz or less of water in the reservoir. There is not enough water to pour a flavored drink. Why is the right LED flashing green? •...

  • Page 19: Troubleshooting

    If light is red when your unit is turned on, allow you unit to carbonate. • If unit does not carbonate and light is still red, replace CO If problems continue after taking recommended steps listed here, your drink machine may need to be serviced.
  • Page 20 Water or syrup is leaking under the machine. • Wipe the water/syrup under and around the unit. If you feel your drink machine requires service, please contact us by phone, or by email, using the methods listed on page 16.
  • Page 21 To Request Service on your SPRiZZi Drink Machine Please Contact Us at: 1-844-4-SPRiZZi customerservice@sprizzi.com...
