Summary of Contents for Smitson JM023-012A
- Page 1 Ｂａｂｙ Ｂａｓｓｉｎｅｔ ＪＭ０２３－０１２Ａ ＵＳＥＲ ＭＡＮＵＡＬ Smitson Jupiter Ltd Gillingham, United Kingdom www.smitsonjupiter.com info@smitsonjupiter.com...
- Page 2 Ａｄｕｌｔ ａｓｓｅｍｂｌｙ ｒｅｑｕｉｒｅｄ． Ｓｍａｌｌ ｐａｒｔｓ ｍａｙ ｐｒｅｓｅｎｔ ｃｈｏｋｉｎｇ ｈａｚａｒｄ ｐｒｉｏｒ ｔｏ ａｓｓｅｍｂｌｙ． Ｅｎｃｌｏｓｅｄ ｐｌｅａｓｅ ｆｉｎｄ ｓｉｍｐｌｅ ｓｔｅｐ－ｂｙ－ｓｔｅｐ ｉｎｓｔｒｕｃｔｉｏｎｓ ｔｏ ｈｅｌｐ ｙｏｕ ｑｕｉｃｋｌｙ ａｓｓｅｍｂｌｅ ｙｏｕｒ ｐｒｏｄｕｃｔｓ． Ｂｅｆｏｒｅ ｙｏｕ ｂｅｇｉｎ ｗｅ ｒｅｃｏｍｍｅｎｄ ｔｈａｔ ｙｏｕ ｆｏｌｌｏｗｉｎｇ ｔｈｅ ｓｔｅｐｓ ｂｅｌｏｗ： １． Ｐｌｅａｓｅ ｒｅａｄ ｔｈｅ ｉｎｓｔｒｕｃｔｉｏｎｓ ｔｈｏｒｏｕｇｈｌｙ． ２． Ｉｄｅｎｔｉｆｙ ａｌｌ ｐａｒｔｓ ａｎｄ ｈａｒｄｗａｒｅｓ． ３． Ｙｏｕ ｗｉｌｌ ｎｅｅｄ ｔｈｅ ｆｏｌｌｏｗｉｎｇ ｔｏｏｌｓ： Ｐｈｉｌｉｐｓ ｈｅａｄ ｓｃｒｅｗ ｄｒｉｖｅｒ Ｆｌａｔ ｈｅａｄ ｓｃｒｅｗ ｄｒｉｖｅｒ Ｈａｍｍｅｒ Ｄｏ Ｎｏｔ Ｕｓｅ Ｐｏｗｅｒ Ｄｒｉｌｌｓ ｏｒ Ｄｒｉｖｅｒｓ Ｔｏ ｐｒｏｔｅｃｔ ｙｏｕｒ ｐａｒｔｓ ｄｕｒｉｎｇ ａｓｓｅｍｂｌｙ ｐｌｅａｓｅ ｐｌａｃｅ ｔｈｅｍ ｏｎ ａ ｓｏｆｔ ｓｕｒｆａｃｅ． Ｔｏ ｃｌｅａｎ ｓｕｒｆａｃｅ ｕｓｅ ｏｎｌｙ ｗａｔｅｒ ｏｎ ａ ｄａｍｐ ｃｌｏｔｈ． Ｄｏ ｎｏｔ ｕｓｅ ｗｉｎｄｏｗ ｃｌｅａｎｅｒｓ ｏｒ ｃｌｅａｎｉｎｇ ａｂｒａｓｉｖｅｓ ａｓ ｉｔ ｗｉｌｌ ｓｃｒａｔｃｈ ｔｈｅ ｓｕｒｆａｃｅ ａｎｄ ｃｏｕｌｄ ｄａｍａｇｅ ｔｈｅ ｐｒｏｔｅｃｔｉｖｅ ｃｏａｔｉｎｇ．...
- Page 3 WARNING ! · FAILURE TO FOLLOW THESE WARNINGS AND THE ASSEMBLY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. · READ ALL INSTRUCTIONS BEFORE ASSEMBLING CRIB. KEEP INSTRUCTIONS FOR FUTURE USE. · UPON COMPLETION OF ASSEMBLY, MAKE SURE ALL SCREWS,BOLTS AND FASTENERS HAVE BEEN SECURELY TIGHTENED.
-
Page 4: Component Parts
HARDWARE AND TOOL DIAGRAM 2-1/8” Allen head bolt (8 pcs) Barrel nuts (10 pcs) ” e l l Lock nuts (2 pcs) ” (1 pc) (2 pcs) n: 5/8” screw (4 pcs) j: 5/8” screw i: Lat c h 2 (2 pcs) h: Latc h 1 (2 pcs) Castors... - Page 5 Note: don't tighten the bolts before finishing the last step. STEP# 1 Assemble latch(h&i)to the headbaord(A&B) by using5/8'' screw(j&n).Then asemble plastic block(m)horizontal to the headboard(A&B)by using 3/4'' screw(kk). Tighten screws usging a phillips-head screwdriver.Make sure that the latch on the bottom of each headbaord(A&B) are locked.
- Page 6 STEP# 3 Attach the mattress board(D)to the heardboard(A&B)by lock nuts(e). STEP# 4 Connect rail(C) to the headboard (A&B)by screws （a）and nuts(b).THEN FULLY tighten the bolts.
- Page 7 STEP# 5 Assemble castors(d&f)to the leg bottoms on the leg on headboard(A&B) by using bolt(p)and nut(o).2 castors(d)with brake are in the front .THEN add the mattress . WRENCH AND PHILLIPS--HEAD SCREWDRIVER REQUIRED FOR ASSEMBLY ----NOT INCLUDE STEP# 6 Select the desire level,and use both hand to lift up the mattress base ,then adjust the level to your require height of the 2 level.Slide in the bolt underneath the mattress board (D) to keep...
- Page 8 Follow bellow to fold the crib: 1.take out the mattress (F) 2.take out the mattress board (E) ① 3.unlock the latch on the headboard ② ① 4.fold the crib ②...
-
Page 9: Limited Warranty
LIMITED WARRANTY warrants its product to be free from defects in material and JM023-012A workmanship and agrees to remedy any such defect. This warranty covers 30 days from the date of original purchase. This warranty is valid only upon presentation of proof of purchase.
