Rokola Music Jukebox Digital RK4 Technical And User Manual

Digital mp3 player system for modernizing jukeboxes can include more than 9,000 song files
Hide thumbs

Advertisement

Quick Links

Download this manual
Rokola Music
Modernization of jukeboxes
Digital MP3 player system for modernizing Jukeboxes (can include more than 9,000 song files)
NSM
Model Minibox GP-4G
Year 1964
(93x76x50) cm
(Height x Width x Depth)
Made by: José Luís Oliveira
Electronic Engineer, IUPFAN 1981
Venezuela
CIV: 31.980
MODERNIZED MODEL: ________________________________
SERIA MODEL: ___________________________________
Copyright Rokola Music 2005-2019
Jukebox Digital RK4
T e c h n i c a l a n d U s e r M a n u a l
Rowe AMI
Model JBM 200
Model 100-78D "Celestia"
"Tropicana" Year 1964
(138x86x72) cm
Modernized equipment
Venezuela-Puerto Cabello Cell: +58 414-3453712
Seeburg
Year 1979
(136x80x60) cm
F i r s t E d i t i o n
(English Version)
"My sincere apologies for the spelling and
editorial errors made in this manual, the translation was
done with the help of Google and my limited knowledge
of English. Any comments will be very well received".
E-mail: oliveira71059.gmail.com
J u k e b o x
D i g i t a l
R K 4
Puerto Cabello, May 2019
Wurlitzer
Model 2300S
Year 1952
"Cadette" Year 1967
(129x85x71) cm
Printed in Venezuela by Rokola Music
File: Jukebox RK4EN.doc
E-mail: oliveira71059.gmail.com
Cell: +58-414-3453712
Apologies
Rowe AMI
Model CMM-1
(122x82x59) cm
