Hardware Review
NetPort II Pin-Outs
Depending on the NetPort II variant the following pinout details apply
DB9F in RS232 Mode
(All models)
RJ45 Ethernet details
2. Hardware Installation
1. Connect a serial device to the NetPort II
2. Connect an Ethernet cable to the RJ45 port.
3. For standard NetPort II devices connect the power supply to
your unit using the PSU that was included in the packaging.
NetPort II Quick Start Guide
NetPort II Device Server (w/-
gender changer–ver. dependent)
DB9F in RS422/485 (4-Wire) Mode
(NetPort II 485 & PoE Models)
4. For the NetPort II PoE version, power is supplied to your unit over
an Ethernet interface using an 802.3af PoE compliant power source
such as a PoE mid-span or PoE Ethernet switch.
THIS COMPLETES THE HARDWARE INSTALLATION
Power Supply with regional
adapters – UK, EU, USA
DB9F in RS485 (2-Wire) Mode
(NetPort II 485 & PoE Models)
