UNPACKING THE KONA STAND
Unpacking the Kona stand
1
2
3
5
8
4
7
9
6
Unpack the stand in following order:
1.
Media support rollers
2.
Stand - cross beam
3.
Stand - vertical beams
4.
Bu ers media support rollers
5.
Stand - legs
6.
Caster wheels
7.
Bu er media support rollers support brackets
8.
Media support rollers brackets
9.
Screw kit
AP-76380 Rev 1.0
Advertisement
Related Manuals for MUTOH Kona
Summary of Contents for MUTOH Kona
- Page 1 UNPACKING THE KONA STAND Unpacking the Kona stand Unpack the stand in following order: Media support rollers Stand - cross beam Stand - vertical beams Bu ers media support rollers Stand - legs Caster wheels Bu er media support rollers support brackets...
- Page 2 ASSEMBLING THE KONA STAND Assembling the Kona stand Hexagon key Hexagon key Hexagon screw Hexagon screw Hexagon nut Anti-static Caster wheel 4 mm 2,5 mm M5x16 M5x12 brush 4 pcs. + 16 pcs. 12 pcs. 8 pcs. 3 pcs. Parkter screw st 4,2x16 16 pcs.
