Spare Parts List - JBL FLIP 3 Service Manual

Spare Parts List

Level Pos. No. Part Number
01 5 54-NE0590-00001
01 5 54-NE0590-00002
01 6 02-FLP3D1-0HA
01 22 02-MIC025-XX0
002 U1 07-BTM880-00A
01 10 08-WB702U-FE0
01 17 08-WB702U-IN0
01 9 08-WB702U-KY0
01 21 08-WB702U-MA0
002 U10 13-BA4510-FVS2
002 R782,R783 13-ESDV12-C033
002 U9 13-MP2637-QFN3
002 U7 13-MP9428-QFN3
002 SW1 13-SD20TR-UTQ3
002 U5 13-SD35TR-0003
002 U2 13-TCA111-6TS3
002 U6 13-TPA313-0D22
01 cable 41-USB1000-UMC Cable 1M USB to Micro orange Type-C FLIP3 TL
01 2 42-015008-04001
01 BT Antenna 47-ANT136-XX0
01 7 49-373000-BAT5-M Li-ion polymer battery 3.7V 3000mAh FLIP3 TL
01 14 55-FLP3C1-0UHB1 USB cover Flip3 TL BLK
01 14 55-FLP3C1-0UHB2 USB cover Flip3 TL Gry
01 14 55-FLP3C1-0UHB3 USB cover Flip3 TL ORG
01 14 55-FLP3C1-0UHB4 USB cover Flip3 TL Red
01 14 55-FLP3C1-0UHB5 USB cover Flip3 TL Pink
01 14 55-FLP3C1-0UHB6 USB cover Flip3 TL BLU
01 14 55-FLP3C1-0UHB7 USB cover Flip3 TL Yel
01 14 55-FLP3C1-0UHB8 USB cover Flip3 TL Tea
01 13 55-FLP3H1-0UHB1 Main Stand Flip3 TL BLK
01 13 55-FLP3H1-0UHB2 Main Stand Flip3 TL Gry
01 13 55-FLP3H1-0UHB3 Main Stand Flip3 TL ORG
01 13 55-FLP3H1-0UHB4 Main Stand Flip3 TL Red
01 13 55-FLP3H1-0UHB5 Main Stand Flip3 TL Pink
01 13 55-FLP3H1-0UHB6 Main Stand Flip3 TL BLU
01 13 55-FLP3H1-0UHB7 Main Stand Flip3 TL Yel
01 13 55-FLP3H1-0UHB8 Main Stand Flip3 TL Tea
01 19 55-FLP3I1-0UH
01 16 56-FLP3H4-0HAB1 USB Bracket Flip3 TL BLK
01 16 56-FLP3H4-0HAB2 USB Bracket Flip3 TL Gry
01 16 56-FLP3H4-0HAB3 USB Bracket Flip3 TL ORG
01 16 56-FLP3H4-0HAB4 USB Bracket Flip3 TL Red
01 16 56-FLP3H4-0HAB5 USB Bracket Flip3 TL Pink
01 16 56-FLP3H4-0HAB6 USB Bracket Flip3 TL BLU
01 16 56-FLP3H4-0HAB7 USB Bracket Flip3 TL Yel
01 16 56-FLP3H4-0HAB8 USB Bracket Flip3 TL Tea
01 gift box 76-195240-0ATC1
01 gift box 76-195240-0ATC2
01 gift box 76-195240-0ATC3
01 gift box 76-195240-0ATC4
01 gift box 76-195240-0ATC5
01 gift box 76-195240-0ATC6
01 gift box 76-195240-0ATC7
01 gift box 76-195240-0ATC8
01 carton box 76-195250-0ATB1
01 1 02-FLP3H2-XX2B1 Grille assy Flip3 TL BLK
01 1 02-FLP3H2-XX0B2 Grille assy Flip3 TL Gry
01 1 02-FLP3H2-XX0B3 Grille assy Flip3 TL ORG
01 1 02-FLP3H2-XX0B4 Grille assy Flip3 TL Red
01 1 02-FLP3H2-XX0B5 Grille assy Flip3 TL Pink
01 1 02-FLP3H2-XX0B6 Grille assy Flip3 TL BLU
01 1 02-FLP3H2-XX0B7 Grille assy Flip3 TL Yel
01 1 02-FLP3H2-XX0B8 Grille assy Flip3 TL Tea
11
Description
Passive Radiator (Left) Flip3 TL
Passive Radiator (Right) Flip3 TL
Battery cover ass'y FLIP3 TL
MIC D4.0/2pin JST 1.5mm FLIP3 TL
Bluetooth Module BM880F3 FLIP3 TL
LED Board FLIP3 TL
USB Board FLIP3 TL
KEY Board FLIP3 TL
Main Board FLIP3 TL
IC BA4510FV SSOP-B8 operational amplifier FLIP3 TL
ESD Suppressor ESD0603V12C03 FLIP3 TL
IC MP2637 QFN-24 BATTERY CHARGER FLIP3 TL
IC MP9428 QFN-22 BOOST FLIP3 TL
IC SD20/TR UTQFN-1.8×1.4-10L SWITCH FLIP3 TL
IC SD35/TR 3.3V SOT23-5 LDO FLIP3 TL
TCA1116 TSSOP24 16-BIT I2C I/O EXPANDER FLIP3 TL
IC TPA3130D2(DAP) SOP32 AMP FLIP3 TL
Speaker Unit 1.5" full range FLIP3 TL
BT Antenna WA-F-LA-03-113 FLIP3 TL
Main Body Flip3 TL
Gift Box Flip3 TL BLK
Gift Box Flip3 TL Gry
Gift Box Flip3 TL ORG
Gift Box Flip3 TL Red
Gift Box Flip3 TL Pink
Gift Box Flip3 TL BLU
Gift Box Flip3 TL Yel
Gift Box Flip3 TL Tea
Carton Box Flip3 TL
QTY
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
