GLT-M003-DDCM
Application
The modem GLT-M003-DDCM connects the DDC4000
system of the operational plant to the cellular network.
The DDC4000 system, monitored by the cellular network,
can send messages and text messages (SMS).
Content
Important Information on Product Safety ...............................................................................................................2
Item........................................................................................................................................................................3
Technical Data.....................................................................................................................................................3
Accessories (included in delivery) .......................................................................................................................3
Connection...........................................................................................................................................................4
Installation..............................................................................................................................................................4
Connection Diagram ..............................................................................................................................................5
Connection Notes ..................................................................................................................................................5
Commissioning ......................................................................................................................................................6
Checking Whether PIN Protection is Enabled for a SIM Card...............................................................................6
Kieback&Peter GmbH & Co. KG
Tempelhofer Weg 50, 12347 Berlin/Germany
Telefon: +49 30 60095-0, Telefax: +49 30 60095-164
www.kieback-peter.de, info@kieback-peter.com
G
Product Description
GLT-M003-DDCM
Page
4.70-10.016-01-EN | 2019-12-10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Kieback&Peter GLT-M003-DDCM
- Page 1 Product Description GLT-M003-DDCM GLT-M003-DDCM Application The modem GLT-M003-DDCM connects the DDC4000 system of the operational plant to the cellular network. The DDC4000 system, monitored by the cellular network, can send messages and text messages (SMS). Content Page Important Information on Product Safety .......................2 Item..................................3...
- Page 2 This data sheet contains information on installing and commissioning the product “GLT-M003-DDCM”. Each person who carries out work on this product must have read and under- stood this data sheet. If you have any questions that are not resolved by this data sheet, you can obtain further information from the supplier or manufacturer.
- Page 3 Product Description GLT-M003-DDCM Item GLT-M003-DDCM Modem for controllers DDC4000, DDC4020e, DDC4040e and DDC420 for sending text messages over the cellular network. Modem for controllers DDC3000, DDC4000, DDC4020e, DDC4040e and DDC420 as an interface for the cellular network for transferring data to the GLT system.
- Page 4 Product Description GLT-M003-DDCM Connection Front side Slot fpr SIM card Release for SIM card Reverse side Connection for DDC Connection for power adapter Connection for antenna Installation CAUTION Electrical installation for connecting the device may only be carried out by qualified technicians.
- Page 5 Product Description GLT-M003-DDCM Connection Diagram 240 V AC Cellular network DDC system: DDC3000/DDC4000/DDC420 Connection Notes 230 V AC Antenna (item no. GLT2327.003) Power adapter (item no. GLT-M001-DDCM.001) Connection cable for BMS operator’s terminal /DDC4000 9-polig (item no. 2316.001) Connection cable for DDC system (item no. DDC2327.001)
- Page 6 The commissioning technician/engineer initiates remote data transmission. Further descriptions regarding the BMS and the DDC system can be found in the project planning documentation. ■ The GLT-M003-DDCM must be configured using ModemTool version 2.1 and higher. ■ Dialing only in data mode: AT DT N... ■...
