Summary of Contents for Secura ASD-500
- Page 1 ASD‐500 Soap Dispenser Drive Belt Repair Note: Be sure to turn the soap dispenser "off" or remove the batteries before starting the repair. Tools you will need: 1. Phillips screwdriver 2. Small flat head screwdriver ...
- Page 2 ASD‐500 Soap Dispenser Drive Belt Repair Place the soap dispenser on its back to locate the 4 Phillips head screws. ...
- Page 3 ASD‐500 Soap Dispenser Drive Belt Repair Unscrew and remove the 4 screws. ...
- Page 4 ASD‐500 Soap Dispenser Drive Belt Repair Use the small flat head screwdriver to carefully pry the base off. ...
- Page 5 ASD‐500 Soap Dispenser Drive Belt Repair The drive belt has slipped off of the pulley. ...
- Page 6 ASD‐500 Soap Dispenser Drive Belt Repair The drive belt is elastic, stretch it out enough to put it back into the pulley's notch. ...
- Page 7 ASD‐500 Soap Dispenser Drive Belt Repair There is also a gasket located in the base to keep the dispenser water resistant. Make sure you replace it. ...
- Page 8 ASD‐500 Soap Dispenser Drive Belt Repair Note: There are 2 different length screws. ...
- Page 9 ASD‐500 Soap Dispenser Drive Belt Repair Note: The short screws go here. Note: Be careful not to overtighten the screws when replacing them. ...
