50" 3-in-1 TV Console (XL50-6GB)
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if you are missing parts, do not return this
item to the Retailer Store. Please call our toll free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
1-866-942-5362
ONLINE: www.whalenfurniture.com
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
VAS Furniture Mfg. Inc.
8:30 a.m. - 4:30 p.m. PST, Monday - Friday
Video Instruction Guides
Go to http://whalen.showuhow.com to view step-by-step instructional
videos for assembling and installing your product. Enter the following
product number on the ShowUhow homepage.
XL50-6GB
EMAIL: parts@whalenfurniture.com
Factory No. 56-12089
LOT NUMBER:
DATE PURCHASED: /
/
Page 1
Advertisement
Related Manuals for VAS XL50-6GB
Summary of Contents for VAS XL50-6GB
- Page 1 LOT NUMBER: DATE PURCHASED: / 50” 3-in-1 TV Console (XL50-6GB) ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if you are missing parts, do not return this item to the Retailer Store. Please call our toll free customer service number and have your...
-
Page 2: Quality Guarantee
Model # XL50-6GB QUALITY GUARANTEE We are confident that you will be delighted with your VAS Furniture purchase. Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to 1 year from date of purchase. - Page 3 Model # XL50-6GB Parts and Hardware List for Table-top Please read completely through the instructions and verify that all parts listed are present before beginning assembly. A-Top Shelf Frame (1) B- Middle Shelf Frame (1) C- Bottom Shelf Frame (1)
- Page 4 Model # XL50-6GB Parts and Hardware List for Universal Wall Mount only Please read completely through the instructions and verify that all parts listed are present before beginning assembly. J- XYZ Mounting Frame (1) K- Monitor Bracket (2) L- Safety Bar (1) (7) - 2 1/2”...
- Page 5 Model # XL50-6GB Assembly Instructions for Table-top Note: Please do not fully tighten all bolts until you finish assembling all parts, then go back and fully tighten all bolts, this will make it easier during assembly of unit. 1. Unpack the unit and confirm that you have all the hardware and required parts listed.
- Page 6 Model # XL50-6GB Assembly Instructions for Table-top 4. Stand the unit upright. 5. Pick up Left Side Frame (E) and attach to the Middle & Bottom Shelf Frame (B & C). Insert & screw the 1 1/4” Bolts (3) with Washers (5 & 6) through the pre-drilled holes on front rail of shelf frame and 3/4"...
- Page 7 Model # XL50-6GB Assembly Instructions for Table-top 8. Go back and tighten all bolts with Allen Wrench provided. 9. In case of uneven floor, Floor Levelers are provided at the bottom of Left & Right Side Frame (E & F). Simply tilt the unit back and raise or lower floor leveler by hand to correct tilting as shown in detail #3.
- Page 8 Model # XL50-6GB Assembly Instructions for Table-top 10. Put the Suction Cups (1) firmly into top holes & metal tabs of three Shelf Frames (A, B & C) as shown in detail #4. 11. Place the Top Glass (G) & Glass Shelves (H) in place as shown in detail #4. Make sure the glass is properly centered and the black side of glass is down.
- Page 9 Model # XL50-6GB Assembly Instructions for Table-top 12. Position the assembled Table-top in your desired location against the wall. Now follow the instructions printed on the plastic bag in order to mount the Tipping Restraint Hardware Kit to the Spine properly. As shown in detail #5.
- Page 10 Model # XL50-6GB Assembly Instructions for Universal Wall Mount Installing XYZ Mounting Frame onto WOODEN WALL 14. The XYZ Mounting Frame (J) must be mounted to two Wood Studs at least 12” apart, using a high quality Stud Finder to locate the two adjacent studs. After you have located the studs, verify with a nail for added security.
- Page 11 Model # XL50-6GB Assembly Instruction for installing XYZ Mounting Frame onto BRICK, SOLID CONCRETE OR CONCRETE BLOCK 17. Use the XYZ Mounting Frame (J) as a template, mark six holes location on the wall, three in the top row and three in the bottom row of slots. Make sure that the holes are level and there is at least 6”...
- Page 12 Model # XL50-6GB Mounting Monitor Bracket to a television with a flat back Note: For televisions with a curved back or recessed back proceed directly to step #23. 20. Determine the correct diameter of the bolt your TV requires by hand threading them into the threaded insert on the back of the TV.
- Page 13 Model # XL50-6GB Mounting Monitor Bracket to a television with a curved / recess back 23. Determine the correct diameter of the bolt your TV requires by hand threading them into the threaded insert on the back of the TV. If you encounter any resistance, stop immediately. If you are unable to find the correct bolt consult a local hardware store.
- Page 14 Model # XL50-6GB Assembly Instructions 26. Once the Monitor Brackets (K) are attached onto the back of television, ask for assistance to lift the television up to the XYZ Mounting Frame (J). Place the hooks on Monitor Brackets over the Mounting Frame then lower them onto the bars of Mounting Frame. Proceed to center the television.
- Page 15 Model # XL50-6GB Assembly Instructions 28. Place assembled console under your TV set as shown at the right. TIPPING RESTRAINT HARDWARE Note: We have included one Tipping Restraint Hardware bag for this unit. When properly installed, this restraint can provide protection against the unexpected tipping of the unit due to small tremors, bumps or climbing.
