Summary of Contents for XI AUDIO HP505
- Page 1 “ ” HP505 HP505 MINI XI Audio – HP505 INSTRUCTION Headphone PANEL MANUAL...
- Page 3 INTRODUCTION XI Audio HP-505 is a stereo headphone amplifier and control panel for broadcast studios. The HP-505 can be mounted directly on the desktop or can be flush mounted. The HP-505 works with all Axia devices that have an Axia GPIO port, but can be used with other broadcast systems as well.
-
Page 4: Getting Started
3 of the GPI RJ45. Headphone Connector 3.5mm This 3.5mm jack socket is located at the centre of the front panel above the volume control. It is connected to the headphone amplifier in parallel HP505 MINI INSTRUCTION MANUAL... - Page 5 DIP Switch 3: Enables/disables LED color programming mode (see table) DIP Switch 4: Determines which switch state programming mode is active on (DIP off = off color, DIP on = on color) (see table) LED BRIGHTNESS TABLE LED Brightness Level 100% HP505 MINI INSTRUCTION MANUAL...
- Page 6 SAMPLE CONNECTION - DRAWING HP505 MINI INSTRUCTION MANUAL...
- Page 7 The PoE socket allows the user to power the GPIO port to illuminate the Talkback, Mute or Mic HP505 from a PoE switch or PoE injector. It has an LEDs. input range of 36V to 57V (designed to work with Pin 1: Mic On Input standard 48V PoE).
- Page 8 SAMPLE CONFIGURATION WITH QOR FOR MAIN MICROPHONE HP505 MINI INSTRUCTION MANUAL...
- Page 9 SAMPLE CONFIGURATION WITH QOR FOR GUEST MICROPHONE HP505 MINI INSTRUCTION MANUAL...
- Page 10 SAMPLE CONFIGURATION WITH QOR Has to be a Talent Headphone HP505 MINI INSTRUCTION MANUAL...
- Page 12 XI Audio P.O. Box 99007 Newmarket, Auckland, New Zealand www.xi-audio.com Distributed by www.avc-group.net...
