Note: The Power LED connector has three holes but only two are used.
Power LED
USB 2.0 CABLE CONNECTION
Align the 9 pin USB connector with the blue USB connector. One pin of the
connector is missing, and one hole on the cable connector is filled. Align
the pins and gently press down until the connector is fully seated.
28
