Creek Company 856 Assembly Instructions

ANCHOR DROP•MOTOR MOUNT
ROD HOLDER COMBO KIT
ITEM #856
FOR CREEK COMPANY ODC 816™, ODC SPORT™, SUPER SPORT™, SPORT XL™,
SUPER SPORT 9™, AND ODC 909™ PONTOON BOATS
ASSEMBLY INSTRUCTIONS
INCLUDES:
(2) Straight Nuts and Bolts
(1) Motor Mount w/ Anchor Line Pulley
(1) Anchor Line Storage Bag
(4) U-Bolts w/ Nuts
(1) Rod Holder
(1) Underseat Lift and Lock Anchor Drop System
with Extension Arms attached
Step 1. Attach Motor Mount to Cargo Deck using the 4 included U-Bolts. Raised transom should be at the back
(see figure 1).
Step 2. Attach Underseat Lift and Lock Anchor Drop System to Seat Support Frame Member by removing plastic
caps on square tubing of Seat Support Frame Member and inserting Extension Arms. Secure Extension Arms in
square tubing using supplied Nuts and Bolts or seat screws (not supplied with kit) if your boat has a plastic seat
(see figure 2).
Step 3. Attach Anchor Line Storage Bag to forward cross-tube of the Seat Support Frame Member using Straps
and Ladder locks attached to bag (see figure 3).
Step 4. Attach Rod Holder to frame where the Cargo Deck attaches to Right or Left Main Frame pieces by remov-
ing Snap Pin, putting Rod Holder in place and re-attaching Snap Pin (see figure 4).
We recommend putting the Motor Mount in the center of the Cargo Deck if you will be using the Anchor Drop
System so that your anchor line runs as straight as possible from the Motor Mount Anchor Line Pulley to the
Under-Seat Lift and Lock Anchor Drop System.
We Recommend the use of electric trolling motors only with this system. We also recommend 5/16" rope and a
twelve pound anchor for use with the Anchor Drop System.
If you have any questions please call The Creek Company at 970-879-5221 x 103 Monday through Friday 9am-
5pm Mountain time, or E-mail us at info@creekcompany.com.
Other accessories are available for your Pontoon Boat. Ask for them where you bought your Pontoon Boat,
or visit the Creek Company Store at www.CreekCompany.com
The Creek Company Ltd. , PO Box 773892, Steamboat Springs, CO 80477
970-879-5221 • fax 970-879-7577 • email: info@creekcompany.com
Specifications and other details subject to change without notice.
All Creek Company products are guaranteed against defects in material and workmanship for the life of the product to
the original owner. This does not cover damage due to misuse or normal wear and tear.
