GETTING STARTED

1. Charging the battery

• Connect the battery to the charger and plug
the charger into any standard electrical
outlet.
• The battery must continuously charge for
a minimum of four hours during its initial
charge period.
• After the initial charge, it should take
between 3 and 4 hours to recharge the
battery.
• The LED light on the charger will indicate
RED when the battery is being charged,
GREEN when the battery is nearly fully
charged, and it will go off when fully
charged.
6
M-CLIMA battery specifications
®
Type Lithium-ion
Model 11V2600
Rate 11.1V 2600 mAh 28.86Wh
Input 12.6V 2.5 A max
Output 12.6V~9V 2.5 A max
Gross Weight 6,2 oz (176 gm)
Dimensions 2,99" x 2,56" x 8,9"
(76 x 65x 22,5 mm)
