MuginUAV Viewpro U30TIR User Manual

Viewpro
U30TIR
30x Zoom EO + IR Dual Sensor Object Tracking Camera Gimbal
User manual
Contents
U30TIR Pinpoint-precision Gimbal
1. Gimbal introduction ................................................................................................................2
2. Object tracking function ..........................................................................................................2
3. Gimbal description ..................................................................................................................3
4. Packing list ...............................................................................................................................4
5. Gimbal dimension ....................................................................................................................4
6. Installing ..................................................................................................................................5
7. Mechanics@Electronic characteristics ....................................................................................5
8. Working characteristics ...........................................................................................................5
9. Gimbal's signal wire box ..........................................................................................................6
SONY EV7520 30x Starlight Camera
1. SONY EV7520 30x starlight camera .......................................................................................10
640 25mm Thermal Imager Parameter
1. 640 25mm Thermal imager Parameter.....................................................................................12
GPS InformationDisplay and Serial Port Control Wiring Diagram
1. GPS and connection of control box ........................................................................................13
2. GPS baud rate .........................................................................................................................13
3. GPS introduction .....................................................................................................................13
4. TTL serial port control wiring instructions .............................................................................13
Gimbal Introduction
U30TIR is a pinpoint-precision professional 3-axis gimbal which features high stability, small size,
light weight and low power consumption. The 3-axis gimbal based on FOC motor control
technology, adopts pinpoint-precision encoder in each motor.
