Product introduction(round)
Knob (temperature)
Knob (wash)
Rear Wash Front Wash
TOILET FIT GUIDE:
Use this guide to choose the seat that will best fit your toilet
Measure the distance from the bolt holes to the front of the
A
toilet bowl to determine the shape.
45.5
49.5cm
B
The distance from the center of the bolt holes to the tank
must be at leat 3.17cm
≥3.17cm
Mounting plate
Hot water inlet
Cold water inlet
Quick release
button
(for women)
If
If A is 40.5-45cm, you need an O Shape Seat
40.5
45.0cm
BIDET SEAT INSTRUCTION
Function introduction
OFF
Hot
①
①
②
OFF
②
A
is 45.5-49.5cm, you need a V Shape Seat
A
Knob for cold/hot options
1) Clockwise--Cold water
Cold
2) Anti-clock wish--Hot water
Knob for cleaning
1) Position ①: Nozzle clean
2) Position ②: Rear cleaning
3) Position ③: Front wash for women
①
③
③
Advertisement
Table of Contents
Summary of Contents for Maro D'Italia FP208
- Page 1 BIDET SEAT INSTRUCTION Function introduction Product introduction(round) Knob for cold/hot options Mounting plate 1) Clockwise--Cold water Cold 2) Anti-clock wish--Hot water Knob (temperature) Hot water inlet Cold water inlet Knob (wash) Quick release Rear Wash Front Wash button (for women) ①...
- Page 2 Parts for installation Tools needed for installation T-adaptor washers T-adaptor washers Connector and nut Hot water seal (for cold water) (for hot water) (for tube) Towel Water Tube Stainless hose Plastic bolts&nuts Top mounting bolts Paper Screwdriver Mounting plate Sliding Plates(2pcs) Taflon tape (optional) 1.
- Page 3 3A. Fix mounting plate on toilet 3B. Fix mounting plate on toilet 1) Put mounting plate on toilet 1) Insert black rubber expansion tubes to the hole of toilet 2) Put sliding plates on mounting plate 2) Put the mounting plate on toilet 3) Put bolts and nuts to screw the mounting plate 3) Put sliding plates on the mounting plate 4) Put the stainless steel plate on the sliding plate...
- Page 4 5. Turn cold water supply off 6. Unscrew cold water supply Washer T-adaptor Stainless hose 7. Install t-adaptor 8. Turn hot water supply off...
- Page 5 9. Connect hot water tube Connector T-adaptor T-adaptor Nut Washer Tube 10. Checking leakage If not connect to hot water supply, screw the hot water seal. Turn on the water supply to check the water leakage...
- Page 6 11. Usage introduction Knob for cold/hot options 1) Clockwise--Cold water 2) Anti-clock wish--Hot water Cold Knob for cleaning ① 1) Position ①: Nozzle clean 2) Position ②: Rear cleaning 3) Position ③: Front wash for women ① ① ② ③ ③...
