MOXXI PILATES CHAIR
ASSEMBLY MANUAL
AND
USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pilates Chair and is the answer not in the manual?

Questions and answers

Summary of Contents for Moxxi Pilates Chair

  • Page 1 MOXXI PILATES CHAIR ASSEMBLY MANUAL USER GUIDE...
  • Page 2 PART LIST Seat assembly x 1 Front legs x 2 Rear leg with Pedal arms x 1 Springs x 2 Front bar x 1 Pin Lock x 1 Bolts x 8 Bolts x 2 Nuts x 8 Eye-hole screws x 12 Instructional DVD x 1 Resistance Bands x 2 Pedal Covers x 2...
  • Page 3 Step 1: According to the illustration, assemble the front legs by attaching part 4 onto the front legs(part 3) using the bolts(part 8). Step 2: According to the illustration, attach the front legs to part 1 using the nuts and bolts.
  • Page 4 Step 3: According to the illustration, attach part 2 to part 1 using the nuts and bolts. Step 4: According to the illustration, attach part 5 onto both the seat assembly and the pedal arms on part 2.
  • Page 5 Step 5: According to the illustration, attach every part 9 into the side of the legs. Finally, tighten screws A and B and the assembly is completed.
  • Page 6 User Guide Seat Lock 1. Using Spin Seat Locked: To change position of seat from short to long position or long to short, pull seat lock straight down, turn seat to desired position and release seat lock back up; move seat back/forth so that the seat locks into place.
  • Page 7 Adjustment Hooks 4. Spring resistance: to change springs, remove spring hook from pedal arm hook and adjust. For less resistance, move it to the hook closest to the pedals. For more resistance, move it to the hook furthest from the pedals. 5.
