Summary of Contents for Martronic Engineering Laser Tech 304
- Page 1 Model 304 Machine Control System Operating Manual Martronic Engineering, Inc. 874 Patriot Drive, Unit D, Moorpark, CA 93021 Phone 805-583-0808 www.meilaser.com Made in the USA...
- Page 2 Table of Contents Getting Started ................1 Operating Modes ................1 Menu Items ..................2 Grading ..................3 Troubleshooting ................4 Specifications ................5...
- Page 3 Getting Started Push the SELECT button once to power the unit on. The display will show a 4 digit elevation. The SELECT button is also used to cycle through the 4 operating modes and turn the unit off. You will see a light next to the operating mode that is currently selected.
- Page 4 Menu Items It is important to check all your menu item settings before you use your system to ensure it will work properly. It is recommended to write down your individual settings for future reference. To enter the MENU ITEMS push and hold the SELECT button and then push the AUTOBLADE button.
- Page 5 Valve Type 00- Standard Valve - Blade Toggle Disables Auto Blade 01- Proportional Valve - Blade Toggle Disables Auto Blade 10- Standard Valve - Auto Blade button Disables Auto Blade 11- Proportional Valve - Auto Blade button disables Auto Blade (Default setting is 01) Survey Type 00- Manual data entry - (+) key records...
- Page 6 Troubleshooting Problem: Blade speed slow or erratic Cause: Menu Items 1 or 2 are set too low Solution: Refer to the Menu Items 1 and 2 in this manual to check and change the speed settings Cause: Laser Transmitter is not set on minimum required RPM Solution: Make sure the Laser is set to at least 600 RPM Problem:...
- Page 7 Problem: Erratic vertical movement Cause: Another Laser Transmitter providing additional signal Solution: Check for another Laser Transmitter on the job site Cause: Radical Elevation changes Solution: Slowdown in rough terrain Cause: Laser beam reflection Solution: Check for mirrored surfaces Problem: Hydraulics do not respond when AUTOBLADE button is pushed Cause:...
- Page 8 Revised 11/2019...
