Fishers Woodscraft Home Garden Pub Assembly Instructions Manual

Hide thumbs

Table Of Contents

Assembly Instructions

Home Garden Pub

The most important thing when assembling the pub is that the ground on which

the unit is to stand must be level. If the ground is not level the unit will not be

square and the unit cannot be correctly assembled.

Table of Contents

Need help?

Do you have a question about the Home Garden Pub and is the answer not in the manual?

Questions and answers

Summary of Contents for Fishers Woodscraft Home Garden Pub

Page 1 Assembly Instructions Home Garden Pub The most important thing when assembling the pub is that the ground on which the unit is to stand must be level. If the ground is not level the unit will not be square and the unit cannot be correctly assembled.
Page 2 Place the two floor sections on the base and but them up together. Take the rear panel and the first side panel and place into position on the floor so that they meet at the corner. Once they are in position and tight up to each other at the corner, screw together using the coach screws with a 10mm spanner or socket.
Page 3 This picture shows the three panels together with the roof support spar screwed into place. Now take the second rear panel and place into Position. The two rear panels can now be screwed together mak- ing sure that the frames are level with each other. If for whatever reason these don’t meet correctly (floor not level) a ‘G’...
Page 4 The two roof panels can now be placed into Position making sure that the top of each roof panel drops into the cutout at the top of the front and rear panels Moving to the inside screw the 75mm screws at an angle through one roof spar into the other spaced accordingly in 4 places.
Page 5 Place the bar top into place and screw into position from the underneath as shown. 3 holes 5 x 60mm screws Next take the bar header and place into position. This can only done by putting the header in on an angle as shown.
Page 6 The bar shelves can now be screwed Into place using the wood brackets as shown. 2 x 4 60mm per bracket. Fitting Of The Veranda. Place the two floor sections on the base making sure that they are level with each side of the building and butt up to the front on the building.
Page 7 Using the centre post as a support. Screw the veranda roof section into the roof of the unit making sure that the two spars on each roof section are level with each other. In other words so it looks like one continuous roof.
Page 8 Screw the support beam into place on both panels as Shown 4 x 5 x 40mm screws With the centre post in situ use a spirit level to make sure it is perfectly up right and screw the bottom blocks to hold into place.
