Grandinroad 45478 Instructions

Please read all instructions carefully before assembling.
Care & Storage Instructions: Store product in its original package. Keep away from heat & moisture. For indoor use only.
Save instruction sheet for future reference.
This item, when assembled by the following instructions, should take 15 minutes to assemble. Please follow the step
by step guide and enjoy your Ultimate Animated Vampire!

Parts List:

A B
Base Shoes x 2
J K
Hands x 2 Left arm
PROP 65 WARNING:
!
A/C Adapter Specification: Handling the coated electrical wires of this product exposes you to lead, a chemical known to the State of California to cause cancer, birth defects or other reproductive harm.
Wash hands after use.
Input: 120V~ 60Hz
Output: 6VDC 800mA
Caution: changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Only use adapter with same
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
technical specifications.
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures; Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected. Consult the dealer or experienced radio/TV technician for help.

Assembly Instructions:

Note: You will need a Phillips Head Screwdriver (not included)
C
Q
B

STEP 1

NOTE: The longer end of the (A) Base goes
towards the front.
First, slide (B) Shoes onto the (A) Base and then
assemble the (C) Support Poles through the tops
of the (A) Shoes as shown, with the slots
housings of the upper poles facing outward.
Insert (Q) screws through (C) Support Poles and
tighten to secure.
Easy to Follow Instructions
# 45478 6' Ultimate Animated Vampire
C D
Support Poles Hip hoop
(upper have slots)
L M
Right arm Moving Arm
Crossbar
D
F
A

STEP 2

Lower (F) Pants over (C) Support Poles through
the leg openings & out through the top of the (F)
Pants. Attach the (D) Hip Hoop through the slots
on the upper (C) Support Poles as shown.
E F
Chest hoop Pants
(flat half
is front)
N O
Torso frame Shoulder
with attached motor support
O
N

STEP 3

Assemble the (N) Torso Frame onto the (C) upper
Support Poles as shown and insert (Q) screws
and tighten to secure. Pull up the (F) Pants over
the (D) Hip Hoop and route the power cord
through and out the bottom of the right pant leg.
Attach the (E) Chest Hoop through the slots
located on the Torso Frame, with the larger part
of the (E) Chest Hoop in front. Attach the (O)
Shoulder Support as shown.
G H
Jacket Cape
P Q
Head Screws x 8
Cotter Pin x 4
E

STEP 4

Lower the (G) Jacket down over the (N) Torso
Frame & (O) Shoulder Piece, and leave the back
of the (G) Jacket open.
I
Hat
R
A/C Adapter
2011 0602
