Avenir
Brackets - IBM and DEC Amp Mounting Bracket
ELECTIVE ELEMENTS
BRACKET (NON-HANDED)
HANGER BRACKET
(LH SHOWN - RH TYPICAL)
"IBM" CABLE
CONNECT BOX
"DEC" CABLE
CONNECT BOX
"AMP" MOUNTING
BRACKET
CAUTION: For communication cables only. Not
intended for power supply cords or electrical wiring.
HANGER BRACKET
(LH SHOWN - RH TYPICAL)
"AMP" FLEXMODE
MODULE KIT
Page 1 of 3
939501507 Rev A
Advertisement
Related Manuals for Steelcase Avenir IBM
Summary of Contents for Steelcase Avenir IBM
- Page 1 “AMP” FLEXMODE MODULE KIT If you have a problem, question, or request, call your local dealer, or Steelcase Line 1 at 888.STEELCASE (888.783.3522) for immediate action by people who want to help you. (Outside the U.S.A., Canada, Mexico, Puerto Rico, and the U.S.
- Page 2 WOOD SCREW #8 x 1/2” SCREW HANGER BRACKET #10-24 x 5/8” (LH SHOWN - RH TYPICAL) HANGER BRACKET (LH SHOWN - RH TYPICAL) “IBM” CABLE CONNECT BOX Secure right or left hand bracket to back of cable connect box with (2) screws and hex nuts.
- Page 3 “AMP” FLEXMODE MODULE KIT “AMP” MOUNTING BRACKET INSTALLATION OF “AMP” MOUNTING BRACKET INTO ENERGY MANAGE- MENT CHANNEL Install “AMP” flexmode module kit into bracket and wire back of connectors. Clip “AMP” mounting bracket into cutout, at the bottom of energy management channel, (either end). “AMP”...
